General |
Printer Type |
17" large-format printer - ink-jet - colour |
Printer |
Inkjet Technology |
Epson Micro Piezo |
Ink Palette Supported (Colours) |
10-ink - photo black, matte black, cyan, light cyan, yellow, vivid magenta, vivid light magenta, violet, grey, lieht gray |
Nozzle Configuration |
180 nozzles (black), 180 nozzles (per colour) |
Minimum Ink Droplet Size |
1.5 pl |
Ink Type |
Epson UltraChrome PRO10 |
Built-in Devices |
LCD touch screen |
Preview Screen Size |
4.3" |
Connectivity Technology |
Wireless |
Interface |
Gigabit LAN, USB 3.0, USB 2.0, Wi-Fi |
Max Resolution (B&W) |
5760 x 1440 dpi |
Max Resolution (Colour) |
5760 x 1440 dpi |
Image Enhancement Technology |
EPSON Variable-sized Droplet Technology |
Cutter |
Yes |
Media Handling |
250-sheet input tray |
RAM |
RAM Installed (Max) |
256 MB |
Media Handling |
Max Media Size |
Roll (43.2 cm) |
Max Media Size (Custom) |
432 mm |
Media Sizes |
Roll (43.2 cm), A2 (420 x 594 mm), Roll A2 plus (43.2 cm), A3 (297 x 420 mm), A3 Plus (330 x 480 mm), A4 (210 x 297 mm), ANSI A (Letter) (216 x 279 mm) |
Media Thickness Range |
0.08 mm - 1.5 mm |
Total Media Capacity |
250 sheets |
Media Feeders |
1 x manual - 1 roll - Roll (43.2 cm) Input tray: 1 - 250 sheets - A2 (420 x 594 mm) |
Networking |
Networking |
Print server |
Expansion / Connectivity |
Connections |
1 x USB 2.0 1 x USB 3.0 1 x Gigabit LAN |
Miscellaneous |
Included Accessories |
Cleaning sheets |
Consumables Included |
1 x ink cartridge (photo black) - 80 ml 1 x ink cartridge (matte black) - 80 ml 1 x ink cartridge (cyan) - 80 ml 1 x ink cartridge (light cyan) - 80 ml 1 x ink cartridge (yellow) - 80 ml 1 x ink cartridge (vivid magenta) - 80 ml 1 x ink cartridge (vivid light magenta) - 80 ml 1 x ink cartridge (grey) - 80 ml 1 x ink cartridge (light grey) - 80 ml 1 x ink cartridge (violet) - 80 ml |
Power |
Power Device |
Power supply - internal |
Voltage Required |
AC 100-240 V |
Frequency Required |
50 - 60 Hz |
Power Consumption Operational |
52 Watt |
Power Consumption Stand by |
20 Watt |
Power Consumption Sleep |
5 Watt |
Software / System Requirements |
OS Required |
Apple MacOS X 10.9.5 or later, Microsoft Windows 7 / 8 / 8.1 / 10 (32/64 bits), Microsoft Windows Server 2008 (32/64-bits), Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012 (64-bit), Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Microsoft Windows Server 2022 |
Manufacturer Warranty |
Service & Support |
Limited warranty - 1 year - on-site |
Environmental Parameters |
Sound Emission (Operating) |
47 dBA |
Dimensions & Weight |
Width |
86.3 cm |
Depth |
76.6 cm |
Height |
40.6 cm |
Weight |
52 kg |
Dimensions & Weight (Shipping) |
Width (Shipping) |
91.2 cm |
Depth (Shipping) |
103.2 cm |
Height (Shipping) |
59.3 cm |
Weight (Shipping) |
65.85 kg |
