| Marketing Description |
| AXIS thermal network camera is easy to install and can easily be integrated with the existing security systems, to reach an unobstructed field of view. |
| Product Features |
-
Thermal imaging
Detect and verify in challenging conditions, without compromising privacy.
-
Electronic image stabilization
Minimize the impact of vibration and shaking.
-
Axis Zipstream technology
Save bandwidth and space without sacrificing valuable information.
|
| General |
| Device Type |
Thermal network camera |
| Form Factor |
Bullet |
| Camera Mount Type |
Positioning unit mount |
| Connectivity Technology |
Wired |
| Width |
10.5 cm |
| Depth |
30.9 cm |
| Height |
10.5 cm |
| Weight |
2 kg |
| Localisation |
Argentina, Australia, China, Japan, Brazil, United Kingdom, United States, Europe |
| Camera |
| Type |
- fixed - outdoor - weatherproof |
| Digital Video Format |
MJPEG, H.264, AVC, MPEG-4 Part 10 |
| Max Digital Video Resolution |
640 x 480 |
| Motion Detection |
Yes |
| Frame Rate (max) |
30 frames per second |
| RAM |
512 MB |
| Flash Memory |
256 MB |
| Features |
Sharpness control, brightness control, contrast control, image mirror, heater, Privacy Mask Function, NAS-Ready, password protection, Variable Bitrate (VBR), Zipstream technology, ONVIF (Profile S) support, ONVIF (Profile G) support, image overlay, Pixel Counter Support, digest authentication, IP address filtering, electronic image stabilisation, exposure zone, guard tour, HTTPs encryption, thermal sensitivity 50 mK (NETD), signed firmware, Adaptive Bitrate (ABR), VAPIX support, compression, text overlay, 180° image rotation, memory card encryption, user access log, centralised certificate management, brute force delay protection, Multi-Bitrate (MBR), control queue, 1833m human detection, 5623m vehicle detection, 458m human recognition, 1406m vehicle recognition, 229m human identification, 703m vehicle identification |
| Image Sensor |
| Type |
Uncooled Micro bolometer |
| Lens Construction |
| Type |
Fixed focal |
| Focal Length |
60 mm |
| Lens Iris |
F/1.25 |
| Min Focus Distance |
91 m |
| Horizontal Field of View (degree) |
10 |
| Interfaces |
| Network Interface |
Ethernet 10Base-T/100Base-TX |
| Network Protocols |
DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, SSH, SSL, QOS, IGMPv2, IGMPv3, CIFS, SRTP, SFTP, LLDP, USGv6, MQTT |
| Expansion / Connectivity |
| Ports |
LAN/power - RJ-45
Serial RS-485/RS-422 |
| Supported Memory Cards |
microSD Card, microSDHC Card, microSDXC Card |
| Miscellaneous |
| Included Accessories |
Terminal block connectors, Torx T20 screw driver |
| Compliant Standards |
EN55024, IEC 60529 IP66, EN 61000-6-1, EMC, ICES-003 Class A, EN 61000-6-2, IEC 60068-2-27, FCC Part 15 B Class A, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-52, EN 50121-4, IEC 62236-4, VCCI Class A, EN 50581, RCM, EN 55022 Class A, KN35, NEMA250 Type 4X, KN32 Class A, EN 62368-1, IEEE 802.3af, IEEE 802.3at, AS/NZS CISPR22 Class A, NIST SP500-267, MIL-STD 810F 521.3, IEC 60068-2-6 Class 4M4, IEC 60721-3-4 Class 4K3 |
| Colour |
White, NCS S 1002-B |
| Power |
| Power Requirements |
DC 8 - 28 V / AC 20 - 24 V / PoE Plus Class 3 |
| Software / System Requirements |
| Software Included |
Windows decoder 1-user licence, AXIS Fence Guard, AXIS Video Motion Detection, AXIS Loitering Guard, AXIS Motion Guard |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 5 years |
| Environmental Parameters |
| Min Operating Temperature |
-40 °C |
| Max Operating Temperature |
60 °C |
| Relative Humidity (operating) |
10 - 100% RH (condensing) |
