| Marketing Description |
| The Cisco Catalyst 9400 is Cisco's lead modular enterprise switching access platform built for security, IoT and cloud. This switch series forms the foundational building blocks for SD-Access - Cisco's leading enterprise architecture. The platform provides unparalleled investment protection with a chassis architecture that is capable of supporting up to 9Tbps of system bandwidth and unmatched power delivery for high density IEEE 802.3BT (60W PoE). Redundancy is now table stakes across the portfolio. |
| Product Features |
-
Robust environmental adaptability
Designed to operate efficiently across a wide range of humidity (10 - 95% non-condensing) and temperature conditions, ensuring reliability from -5°C to 45°C for operational temperatures and -40°C to 70°C for storage. This adaptability makes the Cisco Catalyst 9400 Series Line Card suitable for varying environmental conditions, ensuring consistent performance and longevity.
-
Comprehensive compliance
Meets a broad spectrum of standards including AS/NZS 60950-1, CAN/CSA-C22.2 No. 60950-1, and several CISPR, EN, FCC, ICES, IEC, IEEE, RoHS, and UL certifications. This extensive compliance underscores the line card's adherence to international safety, electromagnetic compatibility, and environmental regulations, making it a reliable component for any network infrastructure.
-
Advanced networking capability
With its plug-in module form factor, the Cisco Catalyst 9400 Series Line Card is engineered for seamless integration into network hubs and switches. It supports advanced networking features, enhancing the performance, scalability, and reliability of enterprise networking infrastructures.
|
| General |
| Device Type |
Switch - 48 ports |
| Enclosure Type |
Plug-in module |
| Ports |
48 x 10/100/1000 |
| Power Over Ethernet (PoE) |
UPOE |
| PoE Budget |
60 W |
| Jumbo Frame Support |
9216 bytes |
| Features |
PAgP support, Energy Efficient Ethernet, PTP, TrustSec support |
| Compliant Standards |
IEEE 802.3, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1ae, IEEE 802.1as, IEEE 802.3at, IEEE 802.3az |
| Expansion / Connectivity |
| Interfaces |
48 x 1000Base-T RJ-45 |
| Miscellaneous |
| Compliant Standards |
CISPR 22 Class A, EN 61000-3-2, EN 61000-3-3, AS/NZS 60950-1, ICES-003 Class A, Laser Class 1, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, EN 300 386 V1.6.1, EN 55022 Class A, IEEE 1588, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1 |
| Software / System Requirements |
| OS Required |
Cisco IOS XE 16.6 or later |
| Dimensions & Weight |
| Width |
4.06 cm |
| Depth |
37.9 cm |
| Height |
37 cm |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - replacement - lifetime - response time: next business day |
| Environmental Parameters |
| Min Operating Temperature |
-5 °C |
| Max Operating Temperature |
45 °C |
| Humidity Range Operating |
10 - 95% (non-condensing) |
| Min Storage Temperature |
-40 °C |
| Max Storage Temperature |
70 °C |
| Humidity Range Storage |
10 - 95% (non-condensing) |
| Compatibility Information |
| Designed For |
P/N: C9404R, C9404R=, C9404R-10A, C9404R-1A, C9404R-48U-BDL-EDU, C9404R-48U-BNDL-1A, C9404R-48U-BNDL-1E, C9404R-48U-BNDL-A, C9404R-48U-BNDL-E, C9407R, C9407R-10A, C9407R-1A, C9407R-96U-BDL-EDU, C9407R-96U-BNDL-1A, C9407R-96U-BNDL-1E, C9407R-96U-BNDL-A, C9407R-96U-BNDL-E, C9407R-P, C9410R, C9410R-1A, C9410R-96U-BDL-EDU, C9410R-96U-BNDL-1A, C9410R-96U-BNDL-1E, C9410R-96U-BNDL-A, C9410R-96UBNDLA-RF, C9410R-96U-BNDL-E, C9410R-P |
