B6 nano
The best charger in nano size
The product SkyRC B6 nano is a new version of the most popular series of chargers - B6. The manufacturer has further reduced the size of the charger, increasing its capabilities. A great, artistic design, a built-in Bluetooth module allowing full control from the app and modern touch buttons are just some of the amenities offered.
Incredible power
The B6 nano model has a highly optimized structure and software, which gives it a surprisingly large capacity. The device has a charging power of up to 320W with a current of up to 15A. The black screen and touch button contribute to a better visual perception.
High speed microprocessor
The high-speed 32-bit ARM Cortex M4F processor enables data processing at 20 times higher speed. Using leading solutions, the charger has great noise reduction capabilities and a wide voltage range from 2.5V - 5.5 V. To take full advantage of the product's capabilities, it is necessary to connect it to a 9-32V power source with a power of 380W or more.
Effective cooling
The temperature of the unit is maintained by a high-speed fan with a speed of 16,000 revolutions per minute. Air is drawn from the fan into the aluminum cooling panel.
Intuitive app for Android and iOS
Thanks to the SkyCharger app, which also supports the Polish language, you can wirelessly update the charger's software using your smartphone. The application is easy to use and allows you to set all the necessary parameters.
SCAN TO GO
Due to the increasing number of battery types and the increasing variety of parameters, their configuration can be difficult and each of them requires individually adapted parameters. The revolutionary SCAN TO GO feature allows you to scan a QR code that will contain all the boot configuration information. We create the code in the SkyCharger application, then print it out and, after sticking it on the battery, scan it - the charging or discharging process will start automatically.
Others
The set contains
|
Specifications
|
- Charger B6 nano
- Power cable with XT60 tip
- User manual
|
- Weight: 130g
- Dimensions: 76 x 85 x 37mm
- External Sockets: XH Balancer 2-6S, Battery, DC Power
- Input voltage: DC 9-32V
- Voltage reading range: 0.1-26.1V
- Max. charging power: 320W
- Max. discharge power: 5W
- Charging current range 0.1-15A
- Discharge current range 0.1-3A
- Battery voltage PB 2-20V
- LiPo/LiFe/Lilon/LiHV number of charged cells 1-6 S
- NiMH/NiCd number of charged cells 1-15 S
|
eFuel 380W
For the most demanding portable chargers
SkyRC's new eFuel power supply is designed for DC mobile chargers with high charging power. The device converts standard alternating current from any electrical outlet in the world (100-240V) into 24V direct current with a power of up to 16A. The device is compatible with the SkyRC e4Q and SkyRC B6 Nano chargers.
Security and reliability
A set of various protections ensures extreme safety in operation - protection against output circuit short-circuit, over-current, over-temperature, over-voltage and power supply overload. The cooling system automatically activates the fan when the device temperature rises to 50°C. The LED turns red.
Active PFC
Active power correction (PFC) reduces interference in the AC power supply. Changing the waveform of the input current allows to improve the power and, as a result, to achieve a higher energy efficiency of the product.
Proven quality
Each eFuel 380W unit undergoes dozens of tests far exceeding industry standards. Drop, tilt, vibration, wear, high and low temperature tests are carefully carried out, so we can be sure that we are getting the highest quality unit.
Others
The set contains
|
Specifications
|
|
|
- Weight: 1620g
- Dimensions: 165 x 139 x 59.5mm
- Input voltage: AC 100-240V
- Frequency: 50-60Hz
- Output voltage: 24V DC ± 0.5V
- Output current: 16A
- Pulse output voltage: 300mV
- Energy efficiency: 88%
- Power factor: 0.98
- Overload protection: 17A ± 1A
- Protection against overheating: up to 80℃
- Operating temperature: 0° - 40°C
- Operating humidity: 0-90%
|
