| Marketing Description |
| Inspire joy on your desk with the clean connectivity of the HP E24d G4 Advanced Docking Monitor. Add your everyday accessories at the display, then add your PC with just one USB-C cable. |
| Product Features |
- Instantly turn on your display and laptop, even when the lid is closed, with a single button on the display
- Clear your clutter by mounting your HP EliteDesk Mini Desktop PC directly behind the display and powering it through USB-C
- Work comfortably with adjustable tilt, height, and swivel settings
- Use pivot rotation to conveniently customize portrait or landscape views on multiple displays
- Filter blue light emission and shift colors to a warmer spectrum for more comfortable viewing with HP Low Blue Light mode
- Manage your display and make it work for you
|
| General |
| Display Type |
LED-backlit LCD monitor / TFT active matrix |
| Energy Class |
Class E |
| Energy Consumption per Year |
26 kWh |
| Diagonal Size |
23.8" |
| Built-in Devices |
Microphone, USB 3.0/USB-C hub |
| Panel Type |
IPS |
| Aspect Ratio |
16:9 |
| Native Resolution |
Full HD (1080p) 1920 x 1080 at 60 Hz |
| Pixel Pitch |
0.2745 mm |
| Pixel Per Inch |
92.5 |
| Brightness |
250 cd/m² |
| Contrast Ratio |
1000:1 / 5000000:1 (dynamic) |
| Colour Gamut |
72% NTSC (CIE 1931), 83% NTSC (CIE 1976) |
| Response Time |
5 ms (grey-to-grey) |
| Vertical Refresh Rate |
50 - 60 Hz |
| Horizontal Refresh Rate |
30 - 80 kHz |
| Horizontal Viewing Angle |
178 |
| Vertical Viewing Angle |
178 |
| Screen Coating |
Anti-glare, Haze 25% |
| Backlight Technology |
LED backlight |
| Colour Temperature |
6500K |
| OSD Languages |
Chinese (traditional), Chinese (simplified), English, French, Italian, Portuguese, Spanish, Dutch, Japanese |
| Features |
Infrared user sensor, HDCP, Low Blue Light Mode, Flicker Free technology, Mercury free, 8-bit gamma, arsenic-free glass, 3 Side Borderless Design, Windows 10 Hello |
| Colour |
Black |
| Dimensions (WxDxH) |
53.94 cm x 4.85 cm x 49.44 cm - with stand |
| Weight |
6.86 kg |
| Connectivity |
| Interfaces |
HDMI (HDCP)
USB-C upstream/DisplayPort Alt Mode with Power Delivery
DisplayPort
Headphone/microphone combo jack
USB-C downstream
USB 3.0 upstream
4 x USB 3.0 downstream
Network (RJ-45)
DisplayPort output |
| Mechanical |
| Display Position Adjustments |
Height, pivot (rotation), swivel, tilt |
| Tilt Angle |
-5/+20 |
| Swivel Angle |
60 |
| Rotation Angle |
180 |
| Height Adjustment |
150 mm |
| VESA Mounting Interface |
100 x 100 mm |
| Miscellaneous |
| Features |
Security lock slot (cable lock sold separately), detachable stand, VESA interface support |
| Included Accessories |
VESA bracket |
| Cables Included |
1 x HDMI cable - 1.8 m
1 x DisplayPort cable - 1.8 m
1 x USB 3.1 Gen 1 cable - 1.8 m |
| Backlight Life |
30,000 hours |
| Compliant Standards |
Plug and Play, TUV GS, VCCI, BSMI, NOM, TUV S, CB, CCC, PSB, FCC, ISO 9241-307, KCC, WEEE, cTUVus, MEPS, E-Standby, CEC, KC, CECP, CEL, EAC, ISC, BIS, low halogen |
| Localisation |
English / Europe |
| Security Slot Type |
Kensington security slot |
| Power |
| Input Voltage |
AC 120/230 V (50/60 Hz) |
| Power Consumption (On mode) |
17.9 W |
| Power Consumption SDR (On mode) |
17.9 kWh/1000h |
| Power Consumption (Typical) |
70 Watt |
| Power Consumption Stand by |
0.5 Watt |
| Software / System Requirements |
| Included Software |
HP Display Assistant |
| OS Required |
Microsoft Windows 7, Windows 8, Windows 10 |
| Dimensions & Weight |
| Dimensions & Weight Details |
Without stand - width: 53.94 cm - depth: 4.85 cm - height: 32.33 cm - weight: 4.1 kg |
| Dimensions & Weight (Shipping) |
| Shipping Width |
64.6 cm |
| Shipping Depth |
26.9 cm |
| Shipping Height |
43.8 cm |
| Shipping Weight |
11.5 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - parts and labour - 3 years |
| Environmental Parameters |
| Min Operating Temperature |
5 °C |
| Max Operating Temperature |
35 °C |
| Humidity Range Operating |
20 - 80% (non-condensing) |
