| Marketing Description |
| The HP Elite 800 Tower PC delivers the high performance that advanced users need, with support for complex programs and rendering, as well as demanding graphics content. Featuring an Intel processor and fast memory and storage, this computer is perfect for your demanding tasks. |
| Product Features |
-
Stunning performance
The dynamic performance of an Intel processor makes it easy to manage large projects.
-
Connect multiple screens
Stay on top of all your workflows with three native video port connections.
|
| General |
| Platform Technology |
Intel vPro Platform |
| Type |
Personal computer |
| Product Form Factor |
Tower |
| Sensors |
HP Tamper Lock |
| Embedded Security |
Trusted Platform Module (TPM 2.0) Security Chip |
| Localisation |
Language: English / region: Europe |
| Bundled with |
HP Wolf Pro Security Edition (1 year) |
| Processor / Chipset |
| CPU |
Intel Core i7 (13th Gen) 13700 |
| Clock Speed |
2.1 GHz (P-core) / 1.5 GHz (E-core) |
| Max Turbo Speed |
5.2 GHz (P-core) / 4.1 GHz (E-core) |
| Number of Cores |
16-core |
| CPU Qty |
1 |
| Max CPU Qty |
1 |
| L2 cache |
24 MB |
| CPU Upgradability |
Upgradable |
| Processor Main Features |
Intel Turbo Boost Technology |
| Chipset Type |
Intel Q670 |
| Cache Memory |
| Installed Size |
L3 Cache - 30 MB |
| Cache Per Processor |
30 MB |
| RAM |
| Installed Size |
16 GB (installed) / 128 GB (max) |
| Technology |
DDR5 SDRAM |
| Effective Memory Speed |
4800 MHz |
| Rated Memory Speed |
4800 MHz |
| Form Factor |
DIMM 288-pin |
| Slots |
4 (Total) / 3 (empty) |
| Features |
Unbuffered |
| Configuration Features |
1 x 16 GB |
| Hard Drive |
| Type |
- M.2 2280 |
| Capacity |
1 x 512 GB |
| Interface Type |
PCI Express |
| Features |
NVM Express (NVMe) |
| Optical Storage |
| Type |
No optical drive |
| Monitor |
| Monitor Type |
None. |
| Graphics Controller |
| Graphics Processor |
Intel UHD Graphics 770 Dynamic Video Memory Technology |
| Video Interfaces |
HDMI, DisplayPort |
| HDCP Compatible |
Yes |
| Audio Output |
| Sound Output Mode |
Stereo |
| Max Sampling Rate |
192 kHz |
| Compliant Standards |
High Definition Audio |
| Input Device |
| Type |
Mouse, keyboard |
| Keyboard |
| Keyboard Name |
HP 320K |
| Interface |
USB |
| Localization & Layout |
International English |
| Mouse |
| Mouse Name |
HP 128 |
| Technology |
Laser |
| Networking |
| Ethernet Controller |
Intel I219-LM |
| Wireless LAN Supported |
Yes |
| Wireless NIC |
Intel Wi-Fi 6E AX 211 |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 |
| Remote Management Protocol |
SNMP 2 |
| Features |
Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), MU-MIMO Support, PXE 2.1 support, dual stream (2x2) |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.11d, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11h, IEEE 802.11e, IEEE 802.11k, IEEE 802.3az, IEEE 802.11r, IEEE 802.11v |
| Expansion / Connectivity |
| Bays |
2 (total) / 2 (free) x internal 3.5"
2 (total) / 2 (free) x external 5.25" Slim Line |
| Slots |
1 (total) / 0 (free) x M.2 Card - 2230 (for WLAN)
2 (total) / 1 (free) x M.2 Card - 2280 (for internal storage)
2 (total) / 2 (free) x PCIe 3.0 x1
1 (total) / 1 (free) x PCIe 3.0 x16 (x4 mode)
1 (total) / 1 (free) x PCIe 4.0 x16 |
| Interfaces |
3 x USB 2.0 (3 rear) (two of them with wake functionality)
3 x USB 3.2 Gen 1
4 x USB 3.2 Gen 2 (4 in front) (one of them is fast-charging)
1 x USB-C 3.2 Gen 2x2 (1 in front) (charging)
2 x DisplayPort 1.4a (2 rear)
1 x headphones/microphone (1 in front) (CTIA headset support)
1 x audio line-out/line-in (1 rear)
1 x LAN (Gigabit Ethernet) (1 rear)
1 x HDMI (1 rear)
1 x DisplayPort |
| Miscellaneous |
| Theft/Intrusion Protection |
Security lock slot (cable lock sold separately), padlock loop, chassis intrusion sensor |
| Security Slot Type |
Kensington security slot |
| Compliant Standards |
FCC Class B certified, CSA, UL, CCC, FIPS 140-2 Level 2, RoHS, WEEE, Common Criteria EAL4+, CECP, low halogen |
| Manufacturer Selling Program |
HP Smart Buy |
| Power |
| Device Type |
Power supply |
| Voltage Required |
AC 90-264 V (50/60 Hz) |
| 80 PLUS Certification |
80 PLUS Platinum |
| Power Factor Correction |
Yes (active) |
| Operating System / Software |
| OS Provided |
Windows 11 Pro English |
| Software |
HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Client Catalogue (free download), HP Driver Packs, HP Setup Integrated OOBE, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Sure Run, HP Sure Recover, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, HP Client Management Script Library (free download), HP Desktop Support Utilities, HP Tamper Lock, HP Image Assistant Gen5 (free download), HP Easy Clean, HP Smart Support, HP Manageability Integration Kit (free download), HP Connect for Microsoft Endpoint Manager, HP Patch Assistant (free download), HP Services Scan, HP Sure Start |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - parts and labour - 1 year - on-site |
| Dimensions & Weight |
| Width |
15.5 cm |
| Depth |
30.8 cm |
| Height |
33.7 cm |
| Weight |
6.15 kg |
| Dimensions & Weight (Shipping) |
| Shipping Width |
40 cm |
| Shipping Depth |
49.9 cm |
| Shipping Height |
28.7 cm |
| Shipping Weight |
8.87 kg |
| Environmental Parameters |
| Min Operating Temperature |
10 °C |
| Max Operating Temperature |
35 °C |
| Humidity Range Operating |
10 - 90% (non-condensing) |
