| Marketing Description |
| The HP Pro Mini 400 provides users with the commercial-grade performance, security, and the flexible deployment capabilities needed for small workspaces. This ultra small form factor PC is powered by an Intel processor and protected with always-on security you can trust. |
| Product Features |
-
Advanced Intel processor
Accomplish everything from minor tasks to complex projects with the advanced Intel processor.
-
Flex ports for easy expansion
Configure or expand your Mini your way with flex ports for legacy or clean desk connectivity.
-
Work with peace of mind
HP Wolf Security for Business creates a hardware-enforced, always-on, resilient defense. From the BIOS to the browser, above, in, and below the OS, these constantly evolving solutions help protect your PC from modern threats.
|
| General |
| Type |
Personal computer |
| Bundled Services |
HP 2 years Next Business Day Onsite Hardware Support for Desktops |
| Product Form Factor |
Tower |
| Sensors |
HP Tamper Lock |
| Embedded Security |
Trusted Platform Module (TPM 2.0) Security Chip |
| Localisation |
Language: English / region: Europe |
| Processor / Chipset |
| CPU |
Intel Core i5 (12th Gen) 12400 |
| Clock Speed |
2.5 GHz |
| Max Turbo Speed |
4.4 GHz |
| Number of Cores |
6-core |
| CPU Qty |
1 |
| Max CPU Qty |
1 |
| L2 cache |
7.5 MB |
| CPU Upgradability |
Upgradable |
| Processor Main Features |
Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache |
| Cache Memory |
| Installed Size |
L3 Cache - 18 MB |
| Cache Per Processor |
18 MB |
| RAM |
| Installed Size |
8 GB (installed) / 64 GB (max) |
| Technology |
DDR4 SDRAM - non-ECC |
| Effective Memory Speed |
3200 MHz |
| Rated Memory Speed |
3200 MHz |
| Form Factor |
DIMM 288-pin |
| Slots |
2 (Total) / 1 (empty) |
| Features |
Unbuffered |
| Configuration Features |
1 x 8 GB |
| Hard Drive |
| Type |
SSD - M.2 2280 |
| Capacity |
1 x 512 GB |
| Interface Type |
PCI Express |
| Features |
NVM Express (NVMe) |
| Storage Controller |
| Type |
1 x SATA |
| Channel Qty |
3 |
| Optical Storage |
| Type |
No optical drive |
| Monitor |
| Monitor Type |
None. |
| Graphics Controller |
| Graphics Processor |
Intel UHD Graphics 730 |
| Video Interfaces |
HDMI, DisplayPort |
| HDCP Compatible |
Yes |
| Audio Output |
| Sound Output Mode |
Stereo |
| Max Sampling Rate |
192 kHz |
| Compliant Standards |
High Definition Audio |
| Input Device |
| Type |
Mouse, keyboard |
| Keyboard |
| Keyboard Name |
HP 125 |
| Interface |
USB |
| Localization & Layout |
International English |
| Mouse |
| Mouse Name |
HP 125 |
| Interface |
USB |
| Networking |
| Ethernet Controller |
Intel I219-LM |
| Wireless LAN Supported |
Yes |
| Wireless NIC |
Realtek RTL8852BE |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax, Bluetooth 5.2 |
| Remote Management Protocol |
SNMP 2 |
| Features |
Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az |
| Expansion / Connectivity |
| Bays |
1 (total) / 1 (free) x external 5.25" Slim Line
2 (total) / 2 (free) x internal 3.5" |
| Slots |
1 (total) / 1 (free) x PCIe 4.0 x16
1 (total) / 1 (free) x PCI
1 (total) / 1 (free) x PCIe 4.0 x1
1 (total) / 1 (free) x M.2 Card - 2230 (PCIe x1 mode (for wireless module))
1 (total) / 0 (free) x M.2 Card - 2280 (PCIe x4 mode (for internal storage)) |
| Interfaces |
1 x headphones/microphone (1 in front) (CTIA and OMTP headset support)
3 x USB 3.2 Gen 2 (3 in front)
1 x USB-C 3.2 Gen 2 (1 in front)
1 x audio line-out/line-in
1 x DisplayPort 1.4a
1 x HDMI
2 x USB 2.0 (wake functionality)
3 x USB 3.2 Gen 1
1 x LAN (Gigabit Ethernet) |
| Miscellaneous |
| Theft/Intrusion Protection |
Security lock slot (cable lock sold separately), padlock loop, chassis intrusion sensor |
| Security Slot Type |
Kensington security slot |
| Compliant Standards |
FCC Class B certified, ICES-003, CCC, FIPS 140-2 Level 2, RoHS, WEEE, KCC Class B, Common Criteria EAL4+, VCCI Class B, low halogen, CAN/CSA-C22.2 No. 62368-1, UL 62368-1, IEEE 1680.1-2018 |
| Power |
| Device Type |
Power supply |
| Voltage Required |
AC 90-264 V (50/60 Hz) |
| Power Factor Correction |
Yes (active) |
| Operating System / Software |
| OS Provided |
FreeDOS |
| Sustainability Information |
| ENERGY STAR Certified |
Yes |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - parts and labour - 1 year - on-site |
| Dimensions & Weight |
| Width |
15.5 cm |
| Depth |
30.8 cm |
| Height |
33.7 cm |
| Weight |
5.31 kg |
| Dimensions & Weight (Shipping) |
| Shipping Width |
40 cm |
| Shipping Depth |
49.9 cm |
| Shipping Height |
28.7 cm |
| Shipping Weight |
8.4 kg |
| Environmental Parameters |
| Min Operating Temperature |
5 °C |
| Max Operating Temperature |
35 °C |
| Humidity Range Operating |
5 - 90% (non-condensing) |
