| Marketing Description |
| Does your data center need a secure, performance driven dense server that you can confidently deploy for virtualization, database, or high-performance computing? The HPE ProLiant DL360 Gen10 server delivers security, agility and flexibility without compromise. |
| Product Features |
-
Robust performance
Equipped with Intel Xeon Silver processors and DDR4 SDRAM, the HPE ProLiant DL360 Gen10 delivers reliable and high-speed performance for demanding applications.
-
Flexible scalability
With support for up to 2 processors and advanced server scalability, this server is designed to grow with your business needs, ensuring a future-proof investment.
-
Efficient management
Integrated Lights-Out 5 (iLO 5) remote management controller offers advanced management capabilities, simplifying server setup, health monitoring, and maintenance.
-
Optimized for environments
Compliant with ASHRAE Class A3 and A4 standards, the server is designed to operate efficiently in a wide range of temperature and humidity conditions, ensuring reliability in various environments.
-
Enhanced expandability
Features include a microSD card slot (internal) for additional storage or OS boot purposes and flexible expansion slots, providing ample room for future upgrades and expansions.
|
| General |
| Type |
Server |
| Product Form Factor |
Rack-mountable - 1U |
| Built-in Devices |
Led panel |
| Server Scalability |
2-way |
| Hot-Swap Bays Qty |
8 |
| Localisation |
Region: Worldwide |
| Processor / Chipset |
| CPU |
Intel Xeon Silver 4208 |
| Clock Speed |
2.1 GHz |
| Max Turbo Speed |
3.2 GHz |
| Number of Cores |
8-core |
| CPU Qty |
1 |
| Max CPU Qty |
2 |
| CPU Upgradability |
Upgradable |
| Processor Main Features |
Hyper-Threading Technology, Intel Turbo Boost Technology 2 |
| CPU Socket |
FCLGA3647 Socket |
| Chipset Type |
Intel C621 |
| Cache Memory |
| Installed Size |
L3 Cache - 11 MB |
| Cache Per Processor |
11 MB |
| RAM |
| Installed Size |
32 GB (installed) / 1.5 TB (max) |
| Technology |
DDR4 SDRAM - Advanced ECC |
| Effective Memory Speed |
2400 MHz |
| Rated Memory Speed |
2933 MHz |
| Memory Specification Compliance |
PC4-23466 |
| Form Factor |
DIMM 288-pin |
| Slots |
24 (Total) / 23 (empty) |
| Features |
Registered, Online Spare Memory, dual rank, mixing of different types of memory modules is not supported, slots 13 - 24 are available in two-processor configuration only, 6-channel memory architecture |
| Configuration Features |
1 x 32 GB |
| RAM Supported |
3 TB Load-Reduced - ECC
1.5 TB registered - ECC
192 GB Non-Volatile - ECC |
| Hard Drive |
| Type |
No HDD |
| Storage Controller |
| Type |
1 x RAID |
| Controller Interface Type |
SAS 12Gb/s |
| Storage Controller Name |
Broadcom MegaRAID MR416i-a |
| Buffer Size |
4 GB |
| Optical Storage |
| Type |
No optical drive |
| Card Reader |
| Type |
Card reader |
| Supported Flash Memory Cards |
microSD |
| Monitor |
| Monitor Type |
None. |
| Graphics Controller |
| Video Memory |
16 MB |
| Video Interfaces |
VGA |
| Networking |
| Ethernet Ports |
4 x Gigabit Ethernet |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol |
SNMP 3, IPMI 2.0, SMASH CLP |
| Remote Management Controller |
Integrated Lights-Out 5 |
| Features |
Wake on LAN (WoL), PXE support |
| Expansion / Connectivity |
| Bays |
1 (total) / 1 (free) x external Universal Media Bay
8 (total) / 8 (free) x hot-swap 2.5" SFF |
| Slots |
1 (total) / 1 (free) x PCIe 3.0 x16 - three-quarter-length, full-height
1 (total) / 1 (free) x PCIe 3.0 x8 - low-profile
1 (total) / 1 (free) x FlexibleLOM - three-quarter-length, full-height (low-profile)
1 (total) / 1 (free) x microSD Card (internal)
1 (total) / 1 (free) x PCIe x16 - full-height |
| Interfaces |
1 x HPE iLO - Type A (1 in front)
1 x HPE iLO - RJ-45 (1 rear)
5 x USB 3.0 (1 front, 2 rear, 2 internal)
1 x VGA (1 rear)
4 x LAN (Gigabit Ethernet) - RJ-45 (4 rear) |
| Miscellaneous |
| Included Accessories |
CPU standard heatsink, 5 x standard fans, SFF Easy install rails |
| Compliant Standards |
AES, FIPS 140-2, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1 |
| Power |
| Device Type |
Power supply - hot-plug |
| Power Redundancy |
Optional |
| Power Redundancy Scheme |
1+1 (with optional power supply) |
| Installed Qty |
1 |
| Max Supported Qty |
2 |
| Voltage Required |
AC 100-240 V (50/60 Hz) |
| Power Provided |
800 Watt |
| Operating System / Software |
| Software |
HPE Server UEFI |
| Sustainability Information |
| ENERGY STAR Certified |
Yes |
| ENERGY STAR Version |
3.0 |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - parts and labour - 3 years - on-site - response time: next business day |
| Dimensions & Weight |
| Width |
43.46 cm |
| Depth |
70.7 cm |
| Height |
4.29 cm |
| Weight |
13.04 kg |
| Environmental Parameters |
| Min Operating Temperature |
10 °C |
| Max Operating Temperature |
35 °C |
| Humidity Range Operating |
8 - 90% (non-condensing) |
