| Marketing Description |
| This affordable and compact box camera delivers 2 MP resolution with superb image quality even in low light conditions. Designed as a visible deterrent, it helps discourage trespassing and other unwanted activities. |
| Product Features |
-
More bang for your buck
This affordable Axis M-line camera includes a built-in microphone and audio recording, letting you hear and register sound in a fixed area. Thanks to support for PoE and redundant DC power, you get flexible installation, and your data is safeguarded in the event of a power outage. Axis Zipstream with support for H.264/H.265 significantly reduces bandwidth and storage requirements. Furthermore, it comes with AXIS object analytics preinstalled, so you can detect and classify humans and vehicles.
-
Great image quality even in low light
With 2 MP resolution at up to 30 fps, AXIS M1135 Mk II delivers superb video quality even in low light conditions. Featuring Axis lightfinder it offers images in true colors even in low light. And, with Axis forensic WDR you get clarity even when there's both dark and light areas in the scene.
-
Designed for deterrence
Designed to act as a deterrent, AXIS M1135 Mk II lets potential offenders know you're watching and helps prevent unwanted activities. This compact box camera provides a clearly visible, fixed angle of view, making it easy to see exactly where the camera's pointing and allowing you to record both audio and video in a precisely defined area. And, thanks to edge-to-edge technology it can be connected to Axis speakers, such as an Axis ceiling speaker.
|
| General |
| Device Type |
Network surveillance camera |
| Audio Support |
Yes: two-way audio via edge-to-edge technology, built-in microphone |
| Audio Formats |
LPCM, AAC-LC, G.711, G.726, ADPCM, OPUS |
| Form Factor |
Box |
| Connectivity Technology |
Wired |
| Width |
7 cm |
| Depth |
14.8 cm |
| Height |
4.6 cm |
| Weight |
205 g |
| Localisation |
Argentina, Australia, Brazil, China, Europe, Japan, United Kingdom, United States |
| Camera |
| Type |
Colour - Day&Night - fixed |
| Digital Video Format |
H.264, MPEG-4 Part 10, AVC, H.265, MPEG-H Part 2, HEVC, MJPEG |
| Max Digital Video Resolution |
1920 x 1080 |
| Motion Detection |
Yes |
| Video Modes |
1080p |
| Exposure Range |
2 sec - 1/33500 sec |
| Minimum Illumination |
0.15 lux - colour - F1.4 - 50 IRE
0.03 lux - B&W - F1.4 - 50 IRE
0.1 lux - colour - F1.4 - 30 IRE
0.02 lux - B&W - F1.4 - 30 IRE |
| Digital Video Capture Resolution |
1920 x 1080, 160 x 90 |
| Frame Rate (max) |
30 frames per second |
| RAM |
1 GB |
| Flash Memory |
512 MB |
| Features |
IR Corrected lens, Forensic WDR, Lightfinder technology, Machine learning processing unit (MLPU), 180° image rotation, 270° image rotation, 90° image rotation, auto gain control, brightness control, colour control, compression, contrast control, Corridor mode, distortion correction function, exposure control, exposure zone, infrared cut filter, sharpness control, white balance, fine tuning of behavior at low light, aspect ratio correction, text overlay, image overlay, Privacy Mask Function, image mirror, digital PTZ function, simplex audio, Axis device ID, Axis Edge Vault, brute force delay protection, digest authentication, HTTPs encryption, IP address filtering, password protection, secure boot, secure keystore, signed firmware, user access log, VAPIX support, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, Pixel Counter Support, human detection, Vehicle Detection, NAS-Ready |
| Image Sensor |
| Type |
2 MP PS RGB CMOS 1/2.9" |
| Lens Construction |
| Type |
CS-mount - vari-focal |
| Optical Zoom |
3.5 x |
| Focal Length |
3 mm - 10.5 mm |
| Lens Iris |
F/1.4 auto iris (DC) |
| Horizontal Field of View (degree) |
33 - 90 |
| Vertical Field of View (degree) |
19 - 49 |
| Interfaces |
| Network Interface |
Ethernet 10Base-T/100Base-TX |
| Network Protocols |
IPv4, IPv6, USGv6, ICMP, HTTP, HTTPS, TLS, QOS, FTP, SFTP, CIFS, SMB, SMTP, Bonjour, UPnP, SNMP 1, SNMP 2c, SNMP 3, DNS, DDNS, NTP, RTSP, RTP, SRTP, TCP/IP, UDP/IP, IGMP, IGMPv2, IGMPv3, RTCP, DHCP, ARP, SOCKS, SSH, LLDP, CDP, MQTT, Syslog, Zeroconf |
| Expansion / Connectivity |
| Ports |
LAN/power - RJ-45
Audio line-in/microphone - 3.5 mm jack
Digital input/output - terminal block |
| Supported Memory Cards |
microSD Card, microSDHC Card, microSDXC Card |
| Miscellaneous |
| Included Accessories |
AXIS T91A11 stand (white) |
| Compliant Standards |
PVC-free, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, EMC, EN 55032 Class A, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM, AS/NZS CISPR 32 Class A, KS C 9832 Class A, KS C 9835, CAN/CSA-C22.2 No. 62368-1, IEC/EN/UL 62368-1, EN 50581, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, NIST SP500-267 |
| Colour |
White, NCS S 1002-B, black, NCS S 9000-N |
| Power |
| Power Requirements |
DC 10 - 28 V / PoE Plus Class 3 |
| Software / System Requirements |
| Software Included |
Windows decoder 1-user licence, AXIS Object Analytics, AXIS Video Motion Detection |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 5 years |
| Environmental Parameters |
| Min Operating Temperature |
-20 °C |
| Max Operating Temperature |
50 °C |
| Relative Humidity (operating) |
10 - 85% RH (non-condensing) |
