| Marketing Description |
| The Lenovo PM883 Entry solid state drive offers a blend of performance, reliability, and efficiency, making it an ideal choice for both enterprise and personal use. With a capacity of 480 GB, it provides ample space for your data storage needs. The drive features 3D V-NAND Technology, ensuring durability and reliability even under heavy use. Its advanced ECC engine and dynamic thermal guard protection safeguard your data, while the low power consumption helps reduce energy costs. Whether you're looking to upgrade your personal computer or enhance your enterprise storage solution, the Lenovo PM883 Entry solid state drive delivers on performance and security. |
| Product Features |
-
Enhanced durability
Equipped with 3D V-NAND Technology and dynamic thermal guard protection, this solid state drive is designed to withstand the rigors of heavy use while maintaining peak performance.
-
High-speed performance
With an internal data rate of up to 550 MBps for reading and 520 MBps for writing, coupled with a low average latency of 40 μs, this drive delivers swift, efficient data access and transfer.
-
Reliable data integrity
Features such as an advanced ECC engine, end-to-end data protection, and power loss data protection ensure your data is safe and secure, minimizing the risk of data loss.
-
Efficient power consumption
Optimized for efficiency, the drive consumes only 2.3 watts during read operations and 2.9 watts during write operations, reducing energy costs and contributing to a greener environment.
|
| General |
| Device Type |
Solid state drive - hot-swap |
| Capacity |
480 GB |
| Form Factor |
2.5" |
| Interface |
SATA 6Gb/s |
| Features |
Advanced ECC Engine, End-to-end data protection, 3D V-NAND Technology, power loss data protection, Dynamic Thermal Guard protection, S.M.A.R.T. |
| Width |
70 mm |
| Depth |
100 mm |
| Height |
7 mm |
| Weight |
58 g |
| Performance |
| Drive Writes Per Day (DWPD) |
0.8 |
| SSD Endurance |
683 TB |
| Internal Data Rate |
550 MBps (read) / 520 MBps (write) |
| 4KB Random Read |
98000 IOPS |
| 4KB Random Write |
24000 IOPS |
| Average Latency |
40 μs |
| Reliability |
| MTBF |
2,000,000 hours |
| Non-Recoverable Errors |
1 per 10^17 |
| Expansion & Connectivity |
| Interfaces |
1 x SATA 6 Gb/s |
| Compatible Bay |
2.5" |
| Power |
| Power Consumption |
2.3 Watt (read)
2.9 Watt (write) |
| Software & System Requirements |
| OS Required |
Microsoft Windows Storage Server 2012 R2, Microsoft Windows Server 2016, Red Hat Enterprise Linux 6.9 (64-bit), Red Hat Enterprise Linux 7.3, Red Hat Enterprise Linux 7.4, Red Hat Enterprise Linux 7.5, SuSE Linux Enterprise Server 11 SP4 x64 Edition, SuSE Linux Enterprise Server 12 SP2, SuSE Linux Enterprise Server 12 SP3, VMware ESXi 6.0 update 3, VMware ESXi 6.5, VMware ESXi 6.5 update 1, VMware ESXi 6.5 update 2, VMware ESXi 6.7 |
| Miscellaneous |
| Compliant Standards |
UL, TUV, FCC, C-Tick, BSMI, KCC |
| Dimensions & Weight (Shipping) |
| Shipping Width |
13.3 cm |
| Shipping Depth |
17.4 cm |
| Shipping Height |
6.3 cm |
| Shipping Weight |
433 g |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - replacement - 1 year |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
70 °C |
| Humidity Range Operating |
8 - 85% (non-condensing) |
| Shock Tolerance (operating) |
1500 g @ 0.5 ms |
| Compatibility Information |
| Designed For |
Lenovo ThinkAgile VX Certified Node 7Y94 (2.5")
Lenovo ThinkAgile VX3320 Appliance 7Y93 (2.5")
Lenovo ThinkAgile VX3520-G Appliance 7Y94 (2.5")
Lenovo ThinkAgile VX3720 Appliance 7Y92 (2.5")
Lenovo ThinkAgile VX7520 Appliance 7Y94 (2.5")
Lenovo ThinkSystem SD530 (2.5")
Lenovo ThinkSystem SN550 (2.5")
Lenovo ThinkSystem SN850 (2.5")
Lenovo ThinkSystem SR250 7Y51 (2.5")
Lenovo ThinkSystem SR530 (2.5")
Lenovo ThinkSystem SR550 (2.5")
Lenovo ThinkSystem SR570 (2.5")
Lenovo ThinkSystem SR590 (2.5")
Lenovo ThinkSystem SR630 (2.5")
Lenovo ThinkSystem SR650 (2.5")
Lenovo ThinkSystem SR850 (2.5")
Lenovo ThinkSystem SR860 (2.5")
Lenovo ThinkSystem SR950 (2.5")
Lenovo ThinkSystem ST250 7Y45 (2.5")
Lenovo ThinkSystem ST550 (2.5"), 7X10 |
