| Marketing Description |
| The QuTS hero NAS TS-h2483XU-RP is powered by an Intel Xeon E processor with up to 128GB DDR4 Error Correcting Code (ECC) memory to deliver server-grade performance with dependable reliability. Running the ZFS-based QuTS hero operating system, the TS-h2483XU-RP supports near-limitless snapshots, real-time SnapSync, block-level inline data deduplication, and inline data compression. The TS-h2483XU-RP helps your business achieve reliable service-level agreement performance, whether as a mission-critical file server, virtualization server, VDI, collaborative video editing, or efficient file backup and recovery applications. |
| Product Features |
-
Intel Xeon E processor delivers extraordinary performance
Powered by an Intel Xeon E-2236 3.4GHz processor (Burst up to 4.8 GHz), the TS-h2483XU-RP has enormous processing power to drive virtual machine performance. Combined with 128GB DDR4 ECC memory and a redundant power supply, the TS-h2483XU-RP delivers cost-effective server-grade performance for complex multitasking and dependable reliability in enterprise IT environments.
-
Server-grade hardware: sturdy and expandable
The TS-h2483XU-RP features outstanding hardware and expandable architecture, enabling optimal performance and flexibility to meet business application diversification requirements.
-
10GbE connectivity for high-speed data transfer
The TS-h2483XU-RP provides four Gigabit RJ45 ports and also supports 10GbE connectivity with a pre-installed dual-port 10GBASE-T network expansion card and a dual-port 10GbE SFP+ SmartNIC to satisfy bandwidth-demanding applications (including virtualization, large file sharing, and high-speed backup and recovery). QNAP also offers numerous options of managed and unmanaged 10GbE switches with 10GbE SFP+/RJ45 and Multi-Gigabit NBASE-T support, assisting organizations in implementing high-speed, secure and scalable network environments.
|
| General |
| Device Type |
NAS server |
| Host Connectivity |
Gigabit Ethernet / 10 Gigabit Ethernet / 10Gbps SFP+ |
| Enclosure Type |
Rack-mountable - 4U |
| Total Storage Capacity |
0 GB |
| Installed Devices / Modules Qty |
0 (installed) / 24 (max) |
| Width |
48.104 cm |
| Depth |
67.202 cm |
| Height |
17.615 cm |
| Weight |
20.67 kg () |
| Processor / Memory |
| Processors Installed |
1 x Intel Xeon E-2236 3.4 GHz |
| Number of Cores |
6-core |
| Max Supported Qty |
1 |
| Max Turbo Speed |
4.8 GHz |
| RAM |
128 GB (installed) / 128 GB (supported) - DDR4 |
| Features |
ECC |
| Flash Memory Installed |
5 GB |
| Storage Controller |
| Type |
RAID |
| Interface Type |
SATA 6Gb/s |
| RAID Level |
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD, RAID 5 hot spare, RAID 6 hot spare, RAID 60, RAID 10 hot spare, RAID TP |
| Networking |
| Data Link Protocol |
1GbE, 10GbE, 10 GigE optical |
| Remote Management Protocol |
SNMP 2, SNMP 3 |
| Network Services Compatibility |
Microsoft Active Directory (AD), Apple Bonjour Protocol, File Level Security (ACLs), Microsoft CIFS, FTP, Server Message Block (SMB), Apple File Protocol (AFP) |
| Features |
ALERT notification, LDAP support, VLAN support, wake on LAN (WOL), Syslog support, Access Control List (ACL) support, iTunes server, Jumbo Frames support, DLNA Media Server, Apple Time Machine compatible, VPN Server, Apple AirPlay, anti-virus protection, Link Aggregation, Google Drive support, Chromecast support, port trunking, Microsoft Azure support, Amazon S3 support, Amazon Glacier suport, Qsirch, deduplication (volume and LUN), snapshot (folder and LUN), compression (volume and LUN) |
| Encryption Algorithm |
AES-NI |
| Compliant Standards |
UPnP |
| Expansion / Connectivity |
| Expansion Bays |
24 (total) / 24 (free) x hot-swap - 2.5" / 3.5" |
| Expansion Slots |
1 x PCI Express 3.0 x8
1 x PCI Express 3.0 x4
3 x PCI Express 2.0 x4 |
| Interfaces |
4 x Ethernet 1000Base-T - RJ-45
4 x USB 3.2 Gen 2 - Type A
2 x USB 3.2 Gen 2 - Type C
2 x Ethernet 10Gb - SFP+
2 x Ethernet 10Base-T - RJ-45 |
| Miscellaneous |
| Cables Included |
2 x network cable
2 x 10GBase-T cable |
| Features |
Audible alarm, built-in 3 cooling fans, dual boot |
| Included Accessories |
96 x flat head screws (for 2.5" HDD), 96 x flat head screws (for 3.5" HDD), 2 x power cables |
| Power |
| Power Device |
Internal power supply |
| Installed Qty |
2 |
| Max Supported Qty |
2 |
| Power Redundancy |
Yes |
| Power Redundancy Scheme |
1+1 |
| Voltage Required |
AC 120/230 V |
| Power Consumption Operational |
168.97 Watt |
| Power Provided |
800 Watt |
| Software / System Requirements |
| Storage Operating System |
QNAP QTS hero |
| Dimensions & Weight (Shipping) |
| Shipping Weight |
28.56 kg |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
5 - 95% (non-condensing) |
| Sound Emission |
28.7 dBA |
