| Marketing Description |
| The quad-core TS-431X3 provides four drive bays for high-capacity storage with expandable memory up to 8GB RAM to meet data backup, recovery, and virtualized storage needs of SMBs. The built-in 10GbE SFP+ port provides high bandwidth for intensive data transmission. The TS-431X3 also features a 2.5GbE RJ45 port and a 1GbE RJ45 port for enhancing team file sharing and collaboration efficiency. The TS-431X3 provides comprehensive local, off-site, and cloud backup and the secure Snapshot technology to help create a reliable backup and disaster recovery plan. In the event of a system crash or accidental file deletion, you can quickly restore the system to its normal state. |
| Product Features |
-
High-speed 10GbE and 2.5GbE connectivity
Powered by an Annapurna Labs AL-314 quad-core 1.7GHz processor with 4GB DDR3L RAM (expandable to 8GB), the TS-431X3 features one 10GbE SFP+ port, one 2.5GbE RJ45 port and 1GbE, allowing you to enjoy higher transfer speeds using existing CAT5e or CAT6 RJ45 cables in your network environment.
-
Multi-point file backup, access, and sync
HBS (Hybrid Backup Sync) consolidates data backup, recovery, and synchronization coupled with high-speed 10GbE and 2.5GbE connectivity of the TS-431X3, allowing you to easily backup or sync data to another QNAP NAS, remote server, or cloud storage to build a reliable disaster recovery solution. Qsync turns the TS-431X3 into a secure, high-capacity data center for file synchronization. Any file uploaded to the TS-431X3 will be made available for all linked devices, such as computers, laptops, and mobile devices. You can also sync shared folders or create team folders to enhance team collaboration.
-
Boost productivity with QNAP applications
QNAP File Station provides centralized file management allowing you to view and manage files on your TS-431X3 and other storage sources or devices. Qfiling helps automate file organization, and Qsirch can make your file searches faster.
-
Protect your sensitive data with file encryption
When sharing sensitive or confidential files on your TS-431X3, you can enhance data security by using File Station to encrypt them into .qenc files and set a password.
-
Protect data against malware with snapshots
Snapshots help protect your data by fully recording the NAS system state and metadata. If a file is accidentally deleted or modified, you can use snapshots from Storage & Snapshots Manager or File Station to quickly restore files to its previously-recorded state. QNAP snapshots are block-based and only record changed data. Not only does this save storage space, but it also reduces time required to back up and restore data. The TS-431X3 supports up to 64 snapshots per volume/LUN, and up to 256 snapshots in total.
-
Take full control of NAS system status and data security
Notification Center consolidates all QTS system events and alerts, providing you with a single-app solution for notifications. Security Counselor can evaluate and recommend TS-431X3 security settings to improve NAS security.
-
Host container applications
Container Station integrates both LXC and Docker lightweight virtualization technologies. You can download apps from the built-in Docker Hub, easily import or export container apps, manage access controls, and rapidly deploy application services across several platforms including the cloud, servers, and PCs.
|
| General |
| Device Type |
NAS server |
| Host Connectivity |
Gigabit Ethernet / 2.5 Gigabit Ethernet / 10 Gigabit Ethernet |
| Total Storage Capacity |
0 GB |
| Installed Devices / Modules Qty |
0 (installed) / 4 (max) |
| Width |
16 cm |
| Depth |
21.9 cm |
| Height |
16.9 cm |
| Weight |
2.01 kg () |
| Built-in Devices |
Led panel |
| Processor / Memory |
| Processors Installed |
1 x Annapurna Labs Alpine AL-314 1.7 GHz |
| Number of Cores |
Quad-Core |
| Max Supported Qty |
1 |
| RAM |
4 GB (installed) / 8 GB (supported) - DDR3 |
| Flash Memory Installed |
512 MB |
| Storage Controller |
| Type |
RAID |
| Interface Type |
SATA 6Gb/s |
| RAID Level |
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD, RAID 5 hot spare, RAID 6 hot spare, RAID 10 hot spare |
| Networking |
| Data Link Protocol |
10Mb LAN, 100Mb LAN, 1GbE, 2.5GbE, 10GbE |
| Network / Transport Protocol |
TCP/IP, PPTP, L2TP, IPSec, iSCSI, SMTP, FTP, DHCP, SMB, DDNS |
| Remote Management Protocol |
SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH |
| Network Services Compatibility |
Microsoft Active Directory (AD), Apple Bonjour Protocol, File Level Security (ACLs), DDNS, Microsoft CIFS, Network File System (NFS), FTP, FTPS, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), SFTP |
| Features |
VPN support, LDAP support, wake on LAN (WOL), Syslog support, print server, IPv6 support, proxy server, backup server, Trivial File Transfer Protocol (TFTP) support, iTunes server, Jumbo Frames support, DHCP server, FTP server, SMS alert, UPnP Media Server, IPv4 support, surveillance station, DLNA Media Server, Apple Time Machine compatible, DHCP client, cloud backup, VPN Server, Apple AirPlay |
| Encryption Algorithm |
SSL, TLS, 256-bit AES |
| Compliant Standards |
DLNA CERTIFIED, UPnP |
| Security DVR |
| IP Cameras Supported |
5000 |
| Expansion / Connectivity |
| Expansion Bays |
4 (total) / 4 (free) x hot-swap - 2.5" / 3.5" |
| Interfaces |
1 x Ethernet 1000Base-T - RJ-45
3 x USB 3.2 Gen 1 - Type A
1 x Ethernet 10Gb - SFP+
1 x 2.5 Gigabit Ethernet - RJ-45 |
| Miscellaneous |
| Cables Included |
1 x network cable |
| Features |
Security lock slot (cable lock sold separately), audible alarm, built-in cooling fan, hardware encryption |
| Security Slot Type |
Kensington security slot |
| Compliant Standards |
AES-256 |
| Included Accessories |
Flat head screws (for 2.5" HDD), flat head screws (for 3.5" HDD), 2 x hard drive security key, power cable |
| Power |
| Power Device |
External power adapter |
| Voltage Required |
AC 120/230 V |
| Power Provided |
90 Watt |
| Software / System Requirements |
| Storage Operating System |
QNAP QTS 4.4.2 |
| OS Required |
UNIX, Apple MacOS X 10.10 or later, CentOS 7.0, IBM AIX 7, Microsoft Windows 7 / 8 / 10, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2019, Oracle Solaris 10, Red Hat Enterprise Linux 6.6, SuSE Linux 12 or later, Ubuntu 14.04 |
| Dimensions & Weight (Shipping) |
| Shipping Weight |
3.47 kg |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
5 - 95% (non-condensing) |
