| Marketing Description |
| Running the QTS hero operating system that incorporates ZFS, the QTS hero NAS TS-h977XU-RP supports near-limitless snapshots, SnapSync, block-level inline data deduplication, and inline data compression. It helps your business achieve reliable service-level agreement performance, whether in mission-critical file server, virtualization server, VDI, collaborative video editing, or efficient file backup and recovery applications. |
| Product Features |
-
Dual-channel memory to deliver power-smart performance
The TS-h977XU-RP supports dual-channel DDR4 memory and four Long-DIMM slots. When using paired memory modules, the TS-h977XU-RP can leverage the power of dual-channel architecture to boost performance. You can also customize the memory configuration of the TS-h977XU-RP, making it an ideal and cost-efficient storage solution for environments including virtualization that contain dynamically changing workloads.
-
Top-class hardware engineering with high I/O expandability
The TS-h977XU-RP features outstanding hardware and expandable architecture, enabling optimal performance and flexibility to meet business application diversification demands.
-
ZFS-based QTS hero operating system enhances NAS performance and data integrity
The QTS hero operating system combines the app-based QTS with a 128-bit ZFS file system to provide flexible storage management, comprehensive data protection, and optimized performance to tackle the complexity and performance demands of modern IT. From storage management, virtualization, to collaborative media workflows, QTS hero streamlines your business-critical tasks.
-
10GbE connectivity optimizes high-speed data transfer
The TS-h977XU-RP provides two Gigabit RJ45 ports, two 10GbE SFP+ ports, and comes with a dual-port 10GbE RJ45 expansion card pre-installed in a PCIe slot. The sufficient 10GbE connectivity improves overall network performance to streamline bandwidth-demanding applications, such as virtualization, large file sharing, and high-speed backup and recovery.
-
SSD caching to accelerate IOPS performance
The TS-h977XU-RP features an HDD and SSD hybrid structure, allowing you to leverage the benefits of both hard drives and SSDs to provide high storage capacity and high performance. Adding an SSD cache to the TS-h977XU-RP is an easy way to increase IOPS performance and reducing storage volume latency. It is perfect for IOPS-demanding applications, including databases and virtualization, and can significantly improve overall workflows.
|
| General |
| Device Type |
NAS server |
| Host Connectivity |
Gigabit Ethernet / 10 Gigabit Ethernet / 10Gbps SFP+ |
| Enclosure Type |
Rack-mountable - 1U |
| Total Storage Capacity |
0 GB |
| Installed Devices / Modules Qty |
0 (installed) / 4 (max) |
| Width |
48.26 cm |
| Depth |
50.554 cm |
| Height |
4.33 cm |
| Weight |
8.62 kg () |
| Processor / Memory |
| Processors Installed |
1 x AMD Ryzen 7 3700X 3.6 GHz |
| Number of Cores |
8-core |
| Max Supported Qty |
1 |
| Max Turbo Speed |
4.4 GHz |
| RAM |
32 GB (installed) / 128 GB (supported) - DDR4 |
| Flash Memory Installed |
5 GB |
| Storage Controller |
| Type |
RAID |
| Interface Type |
SATA 6Gb/s |
| RAID Level |
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD, RAID 5 hot spare, RAID 6 hot spare, RAID 60, RAID 10 hot spare, RAID TP |
| Networking |
| Data Link Protocol |
1GbE, 10GbE, 10 GigE optical |
| Remote Management Protocol |
SNMP 2, SNMP 3 |
| Network Services Compatibility |
Microsoft Active Directory (AD), Apple Bonjour Protocol, File Level Security (ACLs), Microsoft CIFS, FTP, Server Message Block (SMB), Apple File Protocol (AFP) |
| Features |
ALERT notification, LDAP support, VLAN support, wake on LAN (WOL), Syslog support, Access Control List (ACL) support, iTunes server, Jumbo Frames support, DLNA Media Server, Apple Time Machine compatible, VPN Server, Apple AirPlay, anti-virus protection, Link Aggregation, Google Drive support, Chromecast support, port trunking, Microsoft Azure support, Amazon S3 support, Amazon Glacier suport, Qsirch, deduplication (volume and LUN), snapshot (folder and LUN), compression (volume and LUN) |
| Encryption Algorithm |
AES-NI |
| Compliant Standards |
UPnP |
| Expansion / Connectivity |
| Expansion Bays |
4 (total) / 4 (free) x hot-swap - 2.5" / 3.5" |
| Expansion Slots |
1 (total) / 0 (free) x PCI Express 3.0 x16 |
| Interfaces |
2 x Ethernet 1000Base-T - RJ-45
1 x USB 3.1 Gen 2 - Type A
4 x USB 3.0 - Type A
2 x Ethernet 10Gb - SFP+
2 x Ethernet 10Base-T - RJ-45 |
| Miscellaneous |
| Cables Included |
2 x network cable
2 x 10GBase-T cable |
| Features |
Audible alarm, built-in 3 cooling fans, dual boot |
| Included Accessories |
16 x flat head screws (for 3.5" HDD), 36 x flat head screws (for 2.5" HDD), 2 x power cables |
| Power |
| Power Device |
Internal power supply |
| Installed Qty |
2 |
| Max Supported Qty |
2 |
| Power Redundancy |
Yes |
| Power Redundancy Scheme |
1+1 |
| Voltage Required |
AC 120/230 V |
| Power Consumption Operational |
76.43 Watt |
| Power Provided |
300 Watt |
| Software / System Requirements |
| Storage Operating System |
QNAP QTS hero |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
5 - 95% (non-condensing) |
| Sound Emission |
43.8 dBA |
