| Marketing Description |
| The NETGEAR M4250 switch series was developed and engineered for audio / video professionals with dedicated service and support. M4250 has been built from the ground up for the growing AV over IP market. AV codecs generally use 1 Gbps or 10 Gbps per stream and the AV Line of M4250 targets the widespread 1 Gbps codecs. PoE++ and rear-facing ports ensure a clean integration in AV racks. M4250 switch comes pre-configured for standard audio and video signals. When requirements are more specific, an AV user interface offers customization with port-based profiles. For audio Dante, Q-SYS and AES67 profiles are available. For video the M4250 offers profiles for NVX, SVSI, Q-SYS, NDI, Dante, as well as audio / video / control mixed profiles. |
| Product Features |
-
Enhanced security
With support for SSL 3.0 and TLS 1.2, the NETGEAR M4250-10G2XF-PoE++ ensures secure network communications, safeguarding sensitive data from potential threats.
-
Robust connectivity
Featuring 10/100/1000 Base-T ports with 8 PoE++ capabilities and 2 10GBase-X SFP+ ports, this switch offers versatile connectivity options for a wide range of devices and high-speed networking requirements.
-
Advanced networking
Equipped with Layer 3 switching capabilities and a comprehensive set of features such as DHCP snooping, VLAN support, and Quality of Service (QoS), the NETGEAR M4250-10G2XF-PoE++ facilitates efficient network traffic management.
-
High performance
With a switching capacity of 60 Gbps and firewall throughput of 44.64 Mpps, this switch delivers high-speed data processing and transmission, ensuring optimal network performance.
-
Reliable operation
Designed for durability and reliability, the NETGEAR M4250-10G2XF-PoE++ operates effectively in a wide range of environmental conditions, supported by its side to side airflow and robust temperature management.
|
| General |
| Device Type |
Switch - 12 ports - L3 - Managed |
| Enclosure Type |
Side to side airflow rack-mountable 1U |
| Subtype |
Gigabit Ethernet |
| Ports |
10 x 10/100/1000 (8 PoE++) + 2 x 10 Gigabit SFP+ |
| Power Over Ethernet (PoE) |
PoE++ |
| PoE Budget |
720 W |
| Performance |
Switching capacity: 60 Gbps
Firewall throughput (64-byte packet size): 44.64 Mpps
Latency (1 Gbps): < 2.14 µs
Latency (10 Gbps): < 0.84 µs |
| Capacity |
VLANs supported: 4093
ARP entries: 4000
Multicast entries (IPv4): 512
Multicast entries (IPv6): 128
Jumbo frame size: up to 12000
IGMP multicast groups: 2000
MSTP instances: 16
PVST instances: 32 |
| MAC Address Table Size |
16K entries |
| Routing Protocol |
RIP, IGMP, IGMPv2, IGMPv3, MLDv2, static IPv4 routing, static IPv6 routing, PIM-DM, PIM-SM, PIM-SSM |
| Remote Management Protocol |
CLI, SNMP, HTTPS, Telnet, SSH, RADIUS, TACACS+, RMON 1, RMON 2, RMON 9 |
| Encryption Algorithm |
TLS 1.2, SSL 3.0 |
| Features |
16MB packet buffer, RSPAN, PIM, DHCP server, policy based routing, LLDP-MED, MVRP, STP support, RSTP, BPDU, STRG, VLAN support, GVRP, GMRP, LACP, LAG, Private VLAN, DHCP snooping, DAI, IP source guard, DHCP relay, AAA, sFlow, QoS, DoS attack prevention |
| Compliant Standards |
IEEE 802.1ak, IEEE 802.1as, IEEE 802.1Qat, IEEE 802.1Qav, IEEE 802.3az, IEEE 802.1ab (LLDP), IEEE 802.1AX, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| Processor |
X ARM A9: 1.25 GHz |
| RAM |
2 GB |
| Flash Memory |
256 MB |
| Status Indicators |
Link/activity, PoE, speed |
| Expansion / Connectivity |
| Interfaces |
10 x 10/100/1000 Base-T RJ-45 8 ports (PoE++)
2 x 10GBase-X SFP+
1 x management (Gigabit LAN) RJ-45
1 x console RJ-45
1 x USB Type A
1 x console (USB) Type C |
| Power |
| Power Device |
Internal power supply |
| Installed Qty |
1 |
| Power Consumption Operational |
26.3 Watt |
| Power Consumption Stand by |
18 Watt |
| Miscellaneous |
| Included Accessories |
Mounting brackets, 2 x SFP slot caps, foot pad set |
| Cables Included |
Console cable
USB-C to USB-A cable |
| Rack Mounting Kit |
Included |
| Compliant Standards |
IEEE 1588, AN/NZS 60950.1:2015, ANSI C63.4:2014, AS/NZS CISPR32:2013 Class A, CCC, CISPR 32:2012, CNS 13438 Class A, CNS 14336-1, EN 55024:2010, EN 55032:2012+AC:2013 Class A, EN 60950-1:2006+A1:2010+A11:2009+A2:2013+A12:2011, EN 61000-3-2:2014 Class A, EN 61000-3-3:2013, FCC CFR47 Part 15 B Class A, GB 4943.1-2011, GB/T9254-2008 Class A, ICES-003:2016 issue 6 Class A, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, IEC60950/EN60950, VCCI-CISPR 32:2016 Class A, YD/T993-1998 |
| Localisation |
Europe |
| Dimensions & Weight |
| Width |
44 cm |
| Depth |
25.7 cm |
| Height |
4.32 cm |
| Weight |
3.83 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - lifetime |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
45 °C |
| Humidity Range Operating |
90% (non-condensing) |
| Min Storage Temperature |
-20 °C |
| Max Storage Temperature |
70 °C |
| Humidity Range Storage |
95% (non-condensing) |
