| Marketing Description |
| Along with the already great Plus switch features, GS316EP enhances your business networking experience even more with exciting new features. Advanced PoE controls, including power allocation override, remote enable/disable/power cycle, PoE scheduling and more, ensure simple power management of PoE connected devices. |
| Product Features |
-
Efficient power management
With a generous PoE budget of 180 W and PoE+ support across 15 ports, this switch ensures efficient power distribution for connected devices, eliminating the need for additional power sources.
-
Robust security features
Equipped with features like DHCP snooping, Denial of Service (DoS) protection, and password protection, the GS316EP provides a secure networking environment to prevent unauthorized access and network attacks.
-
Comprehensive network management
Manageable via DHCP or HTTP, this switch offers advanced network management capabilities, including VLAN support, Quality of Service (QoS), and IGMP snooping, for optimized traffic prioritization and bandwidth management.
-
High-capacity and performance
With a 28 Gbps bandwidth and support for up to 4K MAC address entries, the GS316EP delivers high-speed data transmission and efficient handling of traffic, suitable for growing business needs.
-
Durable and flexible design
Designed for both desktop and wall-mountable setups, this fanless switch operates silently while ensuring reliability with a high MTBF of 784,742 hours, making it ideal for any office environment.
|
| General |
| Device Type |
Switch - 16 ports - Managed |
| Enclosure Type |
Desktop, wall-mountable |
| Subtype |
Gigabit Ethernet |
| Ports |
15 x 10/100/1000 (PoE+) + 1 x SFP |
| Power Over Ethernet (PoE) |
PoE+ |
| PoE Budget |
180 W |
| Performance |
Bandwidth: 28 Gbps |
| Capacity |
Buffer memory (kBytes): 192
VLANs supported: 64
Multicast groups: 128 |
| MAC Address Table Size |
4K entries |
| Jumbo Frame Support |
10000 bytes |
| Routing Protocol |
IGMP, IGMPv2, IGMPv3 |
| Remote Management Protocol |
DHCP, HTTP |
| Features |
QoS, IGMP snooping, DoS protection, VLAN support, loop prevention, loopback detection, Broadcast Storm Control, port mirroring, fanless, PoE scheduling, uninterrupted PoE, store and forward, EEE, WRR, VLAN Tagging, port-based VLAN, Link Aggregation, port trunking, block unknown multicast, DHCP client, DSCP support, CoS, ToS, full duplex mode, flow control, password protection, cable test, rate limit |
| Compliant Standards |
IEEE 802.3at, IEEE 802.3az, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af |
| Status Indicators |
Link/activity/speed, PoE, power, system, PoE max |
| Expansion / Connectivity |
| Interfaces |
15 x 1000Base-T RJ-45 PoE+ - 30 W
1 x 1000Base-X SFP |
| Power |
| Power Device |
External power adapter |
| Miscellaneous |
| Included Accessories |
Wall mounting kit, rubber feet |
| MTBF |
784,742 hours |
| Compliant Standards |
FCC Part 15 Class B, EN 55032, EN55024, VCCI, ACMA, CSA, KC, BSMI |
| Dimensions & Weight |
| Width |
28.6 cm |
| Depth |
10.2 cm |
| Height |
2.7 cm |
| Weight |
883 g |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 5 years
Limited warranty - power supply - 2 years
Limited warranty - phone consulting - 90 days with product registration |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
90% (non-condensing) |
| Min Storage Temperature |
-20 °C |
| Max Storage Temperature |
70 °C |
| Humidity Range Storage |
95% (non-condensing) |
