| Marketing Description |
| Designed for high-volume label printing, the Brother TJ series is capable of printing more than a thousand labels a day. The durable label printers offer rapid print speeds and large ribbon capacity- making them perfect for any industrial printing application. |
| Product Features |
-
Versatile barcode compatibility
Supports a wide range of barcodes including Aztec code, QR code, and UPC, ensuring seamless integration into various industries and applications.
-
High-speed printing
Achieves a maximum printing speed of 305 mm/s, making it ideal for high-volume printing tasks in demanding environments.
-
Robust connectivity options
Features multiple connectivity interfaces including LAN, USB 2.0, USB host, and serial, offering flexible connection solutions for different setups.
-
Advanced media handling
Accommodates rolls up to 11.4 cm in size, supporting a variety of media sizes and types for diverse printing needs.
-
Exceptional print quality
Delivers sharp, clear prints with a maximum resolution of 300 DPI, suitable for producing detailed labels and barcodes.
|
| General |
| Printer Type |
Label printer - direct thermal / thermal transfer - monochrome |
| Printer |
| Print Speed |
Up to 305 mm/sec - max speed |
| Connectivity Technology |
Wired |
| Interface |
LAN, serial, USB host, USB 2.0 |
| Max Resolution (B&W) |
300 dpi |
| Language Simulation |
EPL2, ZPL II, DPL, FBPL-EZD |
| Features |
Label detection sensor |
| Barcodes |
Code 128, EAN-128, Interleaved 2 of 5, Industrial 2 of 5, Code 39, EAN-13, EAN-8, Code 93, UPC-A, UPC-E, Postnet, MSI, Plessey, China Post, ITF-14, EAN-14, Code 11, Telepen, PLANET, Code 49, LOGMARS, CODABLOCK, GS1 DataBar, MaxiCode, Aztec code, PDF417, QR code, MicroPDF417, TLC39, Codabar |
| RAM |
| RAM Installed (Max) |
256 MB |
| Flash Memory |
| Flash Memory |
512 MB |
| Media Handling |
| Media Type |
Continuous labels |
| Max Media Size |
Roll (11.4 cm) |
| Max Media Size (Custom) |
114 mm |
| Media Sizes |
Roll (11.4 cm) |
| Max Printing Width |
104 mm |
| Max Printing Length |
11430 mm |
| Networking |
| Networking |
Print server |
| Expansion / Connectivity |
| Connections |
1 x RS-232 - 9 pin D-Sub (DB-9)
1 x USB 2.0
1 x LAN - RJ-45
1 x USB host |
| Miscellaneous |
| Cables Included |
1 x USB cable |
| Software / System Requirements |
| Software Included |
Bartender UltraLite (free download), Software Development Kit (SDK) |
| OS Required |
Linux, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Windows 8.1, Microsoft Windows 7, Windows 10, Android 5.0 or later, Apple iOS 9 or later, Apple MacOS X 10.11.x or later |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 3 years |
| Dimensions & Weight |
| Width |
27.6 cm |
| Depth |
50.2 cm |
| Height |
41.2 cm |
| Weight |
18.93 kg |
