| Marketing Description |
This fully integrated, technical printing solution offers high-productivity, smart features, document security and easy operation.
The SureColor SC-T7700D is a technical printer that's been designed for various applications, including: precise line definition, color accuracy, and security for AEC/CAD/GIS plans and drawings; bright color and high speed production for POS posters in retail; and precision, color replication, and security for public sector printing. |
| Product Features |
-
Complete document solution
The SC-T7700D includes enhanced IT and security features. This is particularly useful for designers, architects and construction companies who print detailed plans and drawings, while protecting confidential documents. Collaboration is further improved, and workloads managed more efficiently, through central management tracking applications.
-
Fast and feature-rich
High productive output speeds are achieved with the PrecisionCore MicroTFP printhead, Variable Sized Droplet technology and Nozzle Verification technology.
-
Compact footprint - versatile design
The SureColor SC-T7700D design is both contempered and compact. It fits into most working environments because of its flat and unobtrusive design, which is space saving and practical.
-
Highly detailed prints, every time
Whether printing detailed architectural, engineering and construction (AEC) CAD prints, or POS posters for retail, the SureColorSC-T7700D's output is both precise and vibrant. The printer features an Epson PrecisionCore MicroTFP printhead and 6-colour UltraChrome XD3 all pigment inks, which include a red ink to broaden the overall color gamut.
-
Business solutions
The SureColor SC-T7700D is supported by industry-leading software providers for production enhancement and managed print systems.
|
| General |
| Printer Type |
44" large-format printer - ink-jet - colour |
| Printer |
| Inkjet Technology |
Epson PrecisionCore MicroTFP |
| Ink Palette Supported (Colours) |
6-ink - cyan, magenta, yellow, red, photo black, matte black |
| Nozzle Configuration |
6 x 1600 nozzles |
| Minimum Ink Droplet Size |
3.5 pl |
| Ink Cartridge Configuration |
6 cartridges (1 each: cyan, magenta, yellow, red, photo black, matte black) |
| Ink Type |
Epson UltraChrome XD3 Ink |
| Built-in Devices |
Touch screen |
| Connectivity Technology |
Wireless |
| Interface |
USB 2.0, Gigabit LAN, Wi-Fi(ac) |
| AirPrint Enabled |
Yes |
| Max Resolution (B&W) |
2400 x 1200 dpi |
| Max Resolution (Colour) |
2400 x 1200 dpi |
| Language Simulation |
EPSON ESC/P Raster, HP GL/2, HP RTL, PDF 1.7, PostScript 3 |
| Colour Management Features |
ICC Color Profiles |
| Printer Features |
Nozzle Detection Technology, auto take up reel |
| RAM |
| RAM Installed (Max) |
4 GB |
| Media Handling |
| Max Media Size |
Roll (111.8 cm) |
| Max Media Size (Custom) |
1118 mm |
| Media Sizes |
Roll (43.1 cm), Roll (60.9 cm), Roll (111.8 cm), Roll (91.4 cm), A0 (841 x 1189 mm), A1 (594 x 841 mm), A2 (420 x 594 mm), A3 (297 x 420 mm), A4 (210 x 297 mm), A5 (148 x 210 mm), B0 (1000 x 1414 mm), JIS B1 (728 x 1030 mm) |
| Borderless Photo Sizes |
Roll (25.4 cm), Roll (43.1 cm), Roll (60.9 cm), Roll (111.8 cm), Roll (91.4 cm) |
| Media Thickness Range |
0.1 mm - 0.8 mm |
| Media Feeders |
1 x automatic - 2 roll - Roll (111.8 cm) |
| Networking |
| Security Protocols & Features |
IPsec, AES-128, AES-256, LDAP, SSL, TLS, WPA3 |
| Expansion / Connectivity |
| Connections |
1 x USB 2.0
1 x Gigabit LAN - RJ-45 |
| Miscellaneous |
| Included Accessories |
2 x maintenance boxes |
| Consumables Included |
1 x ink tank (photo black)
1 x ink tank (matte black)
1 x ink tank (cyan)
1 x ink tank (yellow)
1 x ink tank (magenta)
1 x ink tank (red) |
| Features |
Bluetooth interface, Trusted Platform Module (TPM), card authentication, Automatic exposure control (AEC), auto-switching |
| Power |
| Power Device |
Power supply - internal |
| Voltage Required |
AC 100-240 V |
| Frequency Required |
50/60 Hz |
| Power Consumption Operational |
70 Watt |
| Power Consumption Stand by |
0.3 Watt |
| Software / System Requirements |
| OS Required |
Microsoft Windows XP / Vista / 7 / 8 / 8.1 / 10 / 11, Microsoft Windows Server 2003, Microsoft Windows Server 2008 (32/64-bits), Apple macOS 11 or later, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016 |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 2 years - on-site |
| Environmental Parameters |
| Sound Emission (Operating) |
49.6 dBA |
| Dimensions & Weight |
| Width |
184.8 cm |
| Depth |
49.9 cm |
| Height |
97.5 cm |
| Weight |
155 kg |
| Dimensions & Weight (Shipping) |
| Width (Shipping) |
75 cm |
| Depth (Shipping) |
200 cm |
| Height (Shipping) |
121.5 cm |
| Weight (Shipping) |
196.98 kg |
