| Marketing Description |
| The M10 series offers small and smart cameras, ideal for securing locations such as small businesses, boutiques, restaurants, hotels or residences. The cameras offer great image quality and professional monitoring capabilities. |
| Product Features |
-
Functional and smart design
The M10 series offers small and smart cameras, ideal for securing locations such as small businesses, boutiques, restaurants, hotels or residences. The cameras offer great image quality and professional monitoring capabilities.
-
High-performance compression and streaming capabilities
The M10 network cameras offers built-in microphone and speaker to record sound or announce message as well as an integrated PIR motion sensor to detect movement even in the dark.
|
| General |
| Device Type |
Network surveillance camera |
| Camera Mount Type |
Wall mount, corner mount |
| Connectivity Technology |
Wired, wireless |
| Width |
10.6 cm |
| Depth |
6 cm |
| Height |
3.7 cm |
| Weight |
126 g |
| Camera |
| Type |
Colour - Day&Night - fixed |
| Digital Video Format |
H.264 |
| Max Digital Video Resolution |
1920 x 1080 |
| Video Modes |
1080p |
| Exposure Range |
1/32500 sec - 1/28000 sec |
| Minimum Illumination |
0.25 lux - colour - F2.0 - 50 IRE
0.05 lux - B&W - F2.0 - 50 IRE
0 lux - IR |
| Infrared LEDs |
Yes |
| Infrared Distance |
10 m |
| Digital Video Capture Resolution |
1080p |
| Frame Rate (max) |
30 frames per second |
| RAM |
512 MB |
| Flash Memory |
256 MB |
| Features |
IR filter, sharpness control, white balance, colour control, brightness control, contrast control, image mirror, Wide Dynamic Range (WDR), AXIS Video Hosting System (AVHS), built-in antenna, Privacy Mask Function, active tampering alarm, password protection, IR Corrected lens, Variable Bitrate (VBR), Zipstream technology, exposure control, Pixel Counter Support |
| Image Sensor |
| Type |
CMOS 1/3" |
| Lens Construction |
| Type |
M12 mount - fixed focal |
| Focal Length |
2.8 mm |
| Lens Iris |
F/2.0 fixed iris |
| Horizontal Field of View (degree) |
110 |
| Vertical Field of View (degree) |
61 |
| Interfaces |
| Video |
RGB |
| Network Interface |
Ethernet 10Base-T/100Base-TX, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11a |
| Network Protocols |
DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, SSL, QOS, CIFS, SNMP 2 |
| Expansion / Connectivity |
| Ports |
LAN/power - RJ-45
USB (power only) - Micro-USB Type B |
| Supported Memory Cards |
microSD Card, microSDHC Card, microSDXC Card |
| Miscellaneous |
| Included Accessories |
Stand, mounting bracket |
| Compliant Standards |
EN 61000-3-2, EN 61000-3-3, EN55024, ICES-003 Class B, EN 61000-6-1, FCC Part 15 B, EMC, EN 61000-6-2, FCC Part 15 E, TELEC, VCCI Class B, KN24, EN 300 328, EN 301489-1, EN 301489-17, RSS-247, KN35, EN 55032 Class B, EN 301 893, IEC/EN/UL 60950-1, IEC/EN 62471, AS/NZS CISPR32 Class B |
| Colour |
White |
| Power |
| Power Requirements |
DC 4.75 - 5.25 V |
| Power Device |
4.4 Watt |
| Software / System Requirements |
| Software Included |
AXIS Video Motion Detection 3 |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 3 years |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Relative Humidity (operating) |
10 - 85% (non-condensing) |
