| Marketing Description |
| This cost-effective fixed focal dome delivers excellent image quality under any light conditions. Built on ARTPEC-8, it offers support for advanced analytics based on deep learning on the edge. |
| Product Features |
-
High-quality images - every time
Do you need great image quality in any light - or no light at all? AXIS M3215-LVE offers excellent 2MP resolution and ensures high quality images around the clock and in any light conditions. It features Axis Lightfinder for sharp color images in low light and with Axis Forensic WDR you get clarity even when there's both dark and light areas in the scene. Plus, Axis OptimizedIR enables surveillance in total darkness up to 30 m (98 ft) or more depending on the scene. Furthermore, Axis Zipstream with support for H.264 and H.265 significantly reduces bandwidth and storage requirements without compromising image quality.
-
Advanced edge analytics
Built on ARTPEC-8, this high-performance camera includes a deep learning processing unit (DLPU). This enables improved processing and storage capabilities allowing you to collect and analyze even more data than before - on the edge. Plus, it delivers valuable metadata facilitating fast, easy, and efficient forensic search capabilities in live or recorded video. Thanks to AXIS Object Analytics, AXIS M3215-LVE can detect and classify humans, vehicles, and types of vehicles - all tailored to your specific needs. Furthermore, with support for ACAP version 4, you can add value to your system with tailor-made applications based on deep learning on the edge.
-
Great performance and built-in cybersecurity
Including a weathershield, this IK10-rated camera offers protection from rain, snow, and sun. It's easy to install with PoE and comes with a bracket for mounting on walls, ceilings, or junction boxes. With support for audio, you can listen in on what's happening in the scene and benefit from audio analytics - for example, for detecting aggressive behavior. Furthermore, this high-performance camera is packed with built-in cybersecurity features to prevent unauthorized access and safeguard your system. For instance, Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis devices on your network.
-
System-on-chip
Designed or selected by Axis for optimal cybersecurity and solutions.
-
Built-in cybersecurity features
Prevent unauthorized access and safeguard your system.
-
OptimizedIR
For advanced and powerful camera-integrated IR solutions.
|
| General |
| Device Type |
Network surveillance camera |
| Audio Support |
Yes: two-way audio via edge-to-edge technology, built-in microphone |
| Audio Formats |
AAC, G.711, G.726, LPCM, OPUS |
| Form Factor |
Dome |
| Connectivity Technology |
Wired |
| Width |
14.9 cm |
| Depth |
14.9 cm |
| Height |
10.2 cm |
| Weight |
783 g |
| Localisation |
English, German, French, Spanish, Italian, Russian, Chinese (simplified), Japanese, Korean, Portuguese, Polish, Chinese (traditional) / Argentina, Australia, United Kingdom, China, Europe, Japan, Brazil, United States |
| Camera |
| Type |
Colour - Day&Night - fixed - outdoor - vandal / waterproof |
| Digital Video Format |
H.264, MPEG-4 Part 10, H.265, MPEG-H Part 2, MJPEG, HEVC, AVC |
| Max Digital Video Resolution |
1920 x 1080 |
| Motion Detection |
Yes |
| Exposure Range |
1/37000 sec - 2 sec |
| Minimum Illumination |
0.14 lux - colour - F2.0 - 50 IRE - Forensic WDR and Lightfinder
0 lux - B&W - F2.0 - 50 IRE - Forensic WDR and Lightfinder
0 lux - IR |
| Infrared LEDs |
Yes |
| Infrared Distance |
30 m |
| Digital Video Capture Resolution |
1920 x 1080, 160 x 90 |
| Frame Rate (max) |
30 frames per second |
| RAM |
1024 MB |
| Flash Memory |
8192 MB |
| Features |
IR Corrected lens, infrared-cut filter, Forensic WDR, -190° / +190° rotation, deep learning processing unit (DLPU), Zipstream technology, Adaptive Bitrate (ABR), Variable Bitrate (VBR), Multi-Bitrate (MBR), low latency mode, digital PTZ function, saturation control, contrast control, brightness control, sharpness control, white balance, defogging, tone mapping, exposure mode, exposure zone, barrel distortion correction, compression, 180° image rotation, 270° image rotation, 90° image rotation, image mirror, dynamic text overlay, image overlay, polygon privacy mask, bit rate control, network speaker pairing, auto gain control, IP address filtering, HTTPs encryption, user access log, centralised certificate management, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, Axis device ID, Axis Edge Vault, night shift, VoIP support, day shift, video streaming indicator, text overlay, Pixel Counter Support, cross line detection, human detection, Vehicle Detection, plastic housing, OptimizedIR, secure boot, signed firmware |
| Image Sensor |
| Type |
2 MP PS RGB CMOS 1/2.9" |
| Lens Construction |
| Type |
Fixed focal |
| Focal Length |
3.1 mm |
| Lens Iris |
F/2.0 fixed iris |
| Min Focus Distance |
1 m |
| Horizontal Field of View (degree) |
101 |
| Vertical Field of View (degree) |
55 |
| Panning |
| Range (degree) |
-190 to +190 |
| Tilting |
| Range (degree) |
-10 to +80 |
| Interfaces |
| Network Interface |
Ethernet 10Base-T/100Base-TX |
| Network Protocols |
EAP, TLS, IPv4, IPv6, USGv6, ICMP, HTTP, HTTPS, QOS, FTP, SFTP, CIFS, SMB, SMTP, Bonjour, UPnP, SNMP 1, SNMP 2c, SNMP 3, DNS, DDNS, NTP, RTSP, RTCP, RTP, SRTP, TCP/IP, UDP/IP, IGMP, IGMPv2, IGMPv3, DHCP, ARP, SOCKS, SSH, SIP, LLDP, CDP, MQTT, Syslog, Zeroconf |
| Alarm Inputs Qty |
1 |
| Alarm Outputs Qty |
1 |
| Expansion / Connectivity |
| Ports |
LAN/power - RJ-45
Audio line-in/microphone - 3.5 mm jack
Digital input/output - terminal block |
| Supported Memory Cards |
microSD Card, microSDHC Card, microSDXC Card |
| Miscellaneous |
| Included Accessories |
Mounting bracket, drill hole template, Resitorx TR20 screw bit, terminal block connectors, cable gaskets, connector guard, weathershield, sunshield |
| Compliant Standards |
IEEE 802.1x, BFR-free, CFR free, IEEE 802.3af, IEEE 802.3at, EN 55032 Class A, EN 61000-6-1, EN 61000-6-2, FCC Part 15 B Class A, ICES-3(A)/NMB-3(A), KCC KN35, KN32 Class A, AS/NZS CISPR 32 Class A, RCM, VCCI Class A, IEC/EN/UL 62368-1, IEC/EN/UL 60950-22, IEC 62471, IS 13252, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, NEMA Type 4X, IEC/EN 62262 IK10, NEMA TS-2 (2.2.7-2.2.9), NIST SP500-267, EAL 4, PVC-free |
| Colour |
White, NCS S 1002-B |
| Power |
| Power Requirements |
DC 12 V / PoE Class 3 |
| Power Device |
4.8 Watt |
| Software / System Requirements |
| Software Included |
Windows decoder 1-user licence, AXIS Companion, AXIS Camera Station |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 5 years |
| Environmental Parameters |
| Min Operating Temperature |
-40 °C |
| Max Operating Temperature |
50 °C |
| Relative Humidity (operating) |
10 - 100% RH (condensing) |
