| General |
| Device Type |
Network surveillance camera |
| Camera Mount Type |
Ceiling mount |
| Connectivity Technology |
Wired |
| Width |
18.8 cm |
| Depth |
18.8 cm |
| Height |
21.7 cm |
| Weight |
2.5 kg |
| Localisation |
Argentina, Australia, China, India, United Kingdom, Europe |
| Camera |
| Type |
Colour - Day&Night - pan / tilt / zoom - outdoor |
| Digital Video Format |
MJPEG, H.264, H.265, MPEG-4 Part 10, MPEG-H Part 2, AVC, HEVC |
| Max Digital Video Resolution |
1920 x 1080 |
| Motion Detection |
Yes |
| Video Modes |
1080p |
| Digital Zoom |
12 |
| Exposure Range |
2 sec - 1/66500 sec |
| Minimum Illumination |
0.1 lux - colour - F1.6 - 30 IRE
0.01 lux - B&W - F1.6 - 30 IRE
0.11 lux - colour - F1.6 - 50 IRE
0.03 lux - B&W - F1.6 - 50 IRE |
| Digital Video Capture Resolution |
1920 x 1080, 320 x 180 |
| Frame Rate (max) |
50 frames per second |
| RAM |
1024 MB |
| Flash Memory |
512 MB |
| Features |
256 preset positions, e-Flip, guard tour, control queue, on-screen directional indicator, set new pan 0°, focus window, focus recall, Machine learning processing unit (MLPU), Adaptive Bitrate (ABR), Multi-Bitrate (MBR), Variable Bitrate (VBR), low latency mode, Forensic WDR, 180° image rotation, 20 individual polygon and mosaic privacy masks, brightness control, compression, contrast control, day/night shift level, defogging, electronic image stabilisation, exposure control, exposure zone, fine tuning of behavior at low light, image freeze, image overlay, Lightfinder 2.0 technology, saturation control, sharpness control, text overlay, tone mapping, white balance, Zipstream technology, AXIS Object Analytics, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, Pixel Counter Support, signed firmware, brute force delay protection, digest authentication, password protection, Axis Edge Vault, secure keystore, signed video, secure boot, aluminium housing, polycarbonate bubble, NAS-Ready, DORI coverage |
| Image Sensor |
| Type |
PS RGB CMOS 1/2.8" |
| Lens Construction |
| Type |
Vari-focal |
| Optical Zoom |
21 x |
| Focal Length |
4 mm - 84.6 mm |
| Lens Iris |
F/1.6-4.5 auto iris |
| Focus Adjustment |
Automatic |
| Horizontal Field of View (degree) |
3.6 - 77 |
| Vertical Field of View (degree) |
2 - 43.1 |
| Panning |
| Range (degree) |
360 |
| Speed (degree/sec) |
Up to 350 |
| Tilting |
| Range (degree) |
180 |
| Speed (degree/sec) |
Up to 350 |
| Interfaces |
| Network Interface |
Ethernet 10Base-T/100Base-TX |
| Network Protocols |
IPv4, IPv6, USGv6, ICMPv4, ICMPv6, HTTP, HTTPS, TLS, QOS, FTP, SFTP, CIFS, SMB, SMTP, Bonjour, UPnP, SNMP 1, SNMP 2c, SNMP 3, DNS, DDNS, NTP, NTS, RTSP, RTP, SRTP, RTSPS, TCP/IP, UDP/IP, IGMP, RTCP, DHCP, ARP, SSH, NTCIP, LLDP, CDP, MQTT, Syslog, Zeroconf |
| Expansion / Connectivity |
| Supported Memory Cards |
microSD Card, microSDHC Card, microSDXC Card |
| Encryption Algorithm |
EAP-TLS, TLS 1.2, TLS 1.3, 256-bit AES-XTS |
| Miscellaneous |
| Included Accessories |
Smoked dome cover, RJ45 push-pull connector, ceiling mount bracket, spring pipe adapter, U-profile pipe adapter, AXIS PoE+ Midspan (1 port) |
| TAA Compliant |
Yes |
| Compliant Standards |
IEEE 802.1x, IEEE 802.1ar, UL/cUL, UKCA, KC, EAC, RCM, CISPR 35, CISPR 32 Class A, EN 50121-4, EN 55035, EN 55032 Class A, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, AS/NZS CISPR 32 Class A, ICES-3(A)/NMB-3(A), VCCI Class A, KS C 9832 Class A, KS C 9835, FCC Part 15 B Class A, IEC 62236-4, CAN/CSA C22.2 No. 62368-1 ThirdEdition, IEC/EN/UL 62368-1, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 62262 IK10, NEMA 250 Type 4X, NIST SP500-267, ETSI EN 303 645, EAL 6+, IEEE 802.3at, PVC-free, EN 63000:2018, REACH 1907/2006/CE, ROHS Directive 2011/65/EU |
| Colour |
White, NCS S 1002-B |
| Power |
| Power Requirements |
PoE Plus Class 4 |
| Power Device |
Power injector - external AC 100-240 V 8 Watt |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 5 years |
| Environmental Parameters |
| Min Operating Temperature |
-30 °C |
| Max Operating Temperature |
50 °C |
| Relative Humidity (operating) |
10 - 100% RH (condensing) |
