| Marketing Description |
The Cisco Business 140AC Access Point multi-pack of five access points deliver enterprise-grade MU-MIMO (2x2) wireless for a small business to get up and running quickly. Ideal for indoor Wi-Fi coverage, the Cisco Business 140AC bundle delivers highly secure and reliable wireless that can be set up in minutes.
Compatible with Cisco Business 100 Series Mesh Extenders to rapidly expand your Wi-Fi network. |
| Product Features |
-
PERFORMANCE
Enterprise-grade MU-MIMO (2x2) performance of five access points delivers a highly secured and reliable wireless connectivity
-
DEPLOYMENT
Flexible deployment wall or celling mount (brackets included) with Power over Ethernet (PoE) support
-
FLEXIBILITY
Mix and match Cisco Business Wireless access points and mesh extenders to increase your Wi-Fi coverage
-
SET UP IN MINUTES
Simplify management and monitor your network from the Cisco Business Mobile app or Web browser
-
ADVANCED SECURITY
Enterprise-class security prevent malware, phishing, and other threats from compromising your network via Cisco Umbrella integration
|
| General |
| Packaged Quantity |
5 (specifications are for single item) |
| Device Type |
Radio access point |
| Width |
15.08 cm |
| Depth |
15.08 cm |
| Height |
3.3 cm |
| Weight |
400 g |
| Processor / Memory / Storage |
| Processors Installed |
710 MHz |
| RAM |
1 GB |
| Flash Memory |
256 MB |
| Networking |
| Form Factor |
External |
| Connectivity Technology |
Wireless |
| Data Transfer Rate |
1 Gbps |
| Data Link Protocol |
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2 |
| Frequency Band |
2.4 GHz, 5 GHz |
| Performance |
Maximum data rate (2.4 GHz): 300 Mbps
Maximum data rate (5 GHz): 867 Mbps |
| Capacity |
Wireless clients per Wi-Fi radio: 200
Wireless clients: 400
VLANs supported: 16 |
| Status Indicators |
Status |
| Features |
VLAN support, manageable, DFS support, wall mountable, Mesh networking, Wi-Fi Multimedia (WMM) support, RADIUS support, ceiling mountable, 802.1x authentication, MU-MIMO technology, SU-MIMO technology, Authentication, Authorization and Accounting (AAA) |
| Encryption Algorithm |
AES, TLS, PEAP, TTLS, WPA2, WPA3 |
| Authentication Method |
RADIUS, MS-CHAP v.2, Extensible Authentication Protocol (EAP), EAP-FAST |
| Compliant Standards |
IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11d, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11n, IEEE 802.11r, IEEE 802.11ac Wave 2 |
| Aerial |
| Antenna |
Internal |
| Expansion / Connectivity |
| Interfaces |
1 x 1000Base-T (PoE) - RJ-45 |
| Miscellaneous |
| Included Accessories |
Torx security screw, ceiling rail mount clip, mounting bracket |
| Compliant Standards |
VCCI, ICES-003, FCC Part 15.247, RSS-102, UL 2043, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15.107, FCC Part 15.109, FCC Part 15.407, ARIB STD-T66, ARIB STD-T71, EN 300 328, EN 50385, FCC OET Bulletin 65c, EN 301 489-1, RSS-247, EN 301 893, CAN/CSA-C22.2 No. 60950-1, EMI Class B, EN 301 489-17 |
| Power |
| Power Over Ethernet (PoE) Supported |
PoE |
| Power Consumption Operational |
8.3 Watt |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - replacement - lifetime |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
50 °C |
| Humidity Range Operating |
10 - 90% (non-condensing) |
