| Marketing Description |
| An effective work environment encourages collaboration. That often means tearing down office walls to create open workspaces. With their quiet, fan-less design, the switches create many possibilities for designing workspaces. They can reside nearly anywhere outside your wiring closet. Install them in carpeted areas such as offices, conference rooms, classrooms, and retail stores for quick, flexible connections. Rearrange rooms and floors without changing your cabling infrastructure. Consolidate cabling for big savings. Rather than running multiple Ethernet cables from endpoints like IP phones and Wi-Fi access points to a wiring closet, you just connect devices over a few feet of cabling to a nearby 3560-CX switch. Then connect the compact switch to the wiring closet with a single Ethernet or fiber cable. Using this setup, a 200-room hotel using compact switches in guest rooms can eliminate up to 30 kilometers of cables. |
| Product Features |
-
Embrace amazing IoT possibilities with PoE
The Cisco Catalyst 3560-CX switches enable you to bring sensors, LED lights, building controllers, and other IoT devices onto the network using Power over Ethernet (PoE). The many features and controls offered by these PoE switches make them run more efficiently and reliably. For example, Cisco Perpetual PoE continues powering endpoints even during a switch boot, maximizing uptime. So there's no need for backup power. The switches provide up to 240 watts of power for PoE devices - twice the capacity of current switches.
-
Security and operational simplicity
For simplified management, these switches have the option to run in Cisco Instant Access mode. Instant Access provides a single point of operation and management for your campus networks. And they support Cisco Plug and Play (PnP) technology, which automates network device deployments.
|
| General |
| Device Type |
Switch - 12 ports - Managed |
| Enclosure Type |
Desktop, rack-mountable, DIN rail mountable, wall-mountable 1U |
| Subtype |
Gigabit Ethernet |
| Ports |
12 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP |
| Power Over Ethernet (PoE) |
PoE+ |
| PoE Budget |
240 W |
| Performance |
Forwarding performance: 16 Gbps
Forwarding performance (64-byte packet size): 23.8 Mpps |
| Capacity |
Virtual interfaces (VLANs): 1023 |
| Jumbo Frame Support |
9018 bytes |
| Routing Protocol |
RIP-1, RIP-2, static IP routing |
| Remote Management Protocol |
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, CLI |
| Authentication Method |
Kerberos, Secure Shell (SSH), RADIUS, TACACS+ |
| Features |
BOOTP support, ARP support, VLAN support, Syslog support, DiffServ support, IPv6 support, STP support, DHCP snooping, PAgP support, ACL support, QoS, fanless, SRR, MAC Address Notification, RSPAN, Energy Efficient Ethernet, MVR, CoS, WTD |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.3az |
| RAM |
512 MB |
| Flash Memory |
128 MB |
| Status Indicators |
Port status, port transmission speed, port duplex mode, system, link/activity |
| Expansion / Connectivity |
| Interfaces |
12 x 1000Base-T RJ-45 PoE+ - 30 W
1 x console RJ-45
1 x mini-USB Type B management
1 x USB Type A
2 x 1000Base-T RJ-45 uplink
2 x SFP uplink |
| Power |
| Power Device |
Internal power supply |
| Power Provided |
300 Watt |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Power Consumption Operational |
23.5 Watt |
| 80 PLUS Certification |
80 PLUS Silver |
| Miscellaneous |
| Rack Mounting Kit |
Optional |
| MTBF |
553,140 hours |
| Compliant Standards |
GOST, CISPR 24, EN55022, EN55024, CISPR 22, CCC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, ANATEL, GB 4943, KCC Class A, IEC 60825, KN22, KN24, VCCI V-3/2007.04 Class A, AS/NZS CISPR22:2004 Class A, CAN/CSA-C22.2 No. 60950-1 |
| Pricing Type |
Refurbished |
| Software / System Requirements |
| Software Included |
Cisco IOS IP Base |
| Dimensions & Weight |
| Width |
26.9 cm |
| Depth |
23.8 cm |
| Height |
4.44 cm |
| Weight |
2.31 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - advance parts replacement - lifetime - response time: next business day
Technical support - consulting - 90 days |
| Environmental Parameters |
| Min Operating Temperature |
-5 °C |
| Max Operating Temperature |
45 °C |
| Humidity Range Operating |
5 - 95% (non-condensing) |
| Min Storage Temperature |
-25 °C |
| Max Storage Temperature |
70 °C |
| Humidity Range Storage |
5 - 95% (non-condensing) |
