| Marketing Description |
| The Catalyst 9200 series delivers the superior features. It's highly secure and always on, and it provides IT simplicity, resulting in a great experience every time. |
| Product Features |
-
Super secure
Get advanced security features that protect the integrity of your hardware, software, and all data that flows through the switch.
-
Always on
Catalyst 9200 series switches provide enterprise-level resiliency, analytics, and assurance to keep your business up and running seamlessly.
|
| General |
| Device Type |
Switch - 48 ports - L3 - stackable |
| Enclosure Type |
Rack-mountable |
| Subtype |
Gigabit Ethernet |
| Ports |
48 x 10/100/1000 (PoE+) |
| Power Over Ethernet (PoE) |
PoE+ |
| Performance |
Stacking bandwidth: 160 Gbps
Switching capacity: 176 Gbps
Switching capacity with stacking: 336 Gbps
Forwarding rate: 130.95 Mpps
Forwarding rate with stacking: 250 Mpps |
| Capacity |
IPv4 routes: 14000
Indirect IPv4 routes: 4000
Direct IPv4 routes: 10000
IPv4 routing table entries: 4000
IPv6 routing table entries: 2000
Multicast scale: 1000
ACL scale entries: 16000
Packet buffer size: 6 MB
Flexible NetFlow entries: 16000
VLAN IDs: 1000 |
| MAC Address Table Size |
32000 entries |
| Jumbo Frame Support |
9198 bytes |
| Routing Protocol |
OSPF, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, PIM-SSM, policy-based routing (PBR), RIPng, MSTP |
| Remote Management Protocol |
SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF |
| Encryption Algorithm |
128-bit AES |
| Features |
QoS, Cisco StackWise Technology, Rapid PVST+, SRR, PXE support, RSPAN, NetFlow, Energy Efficient Ethernet, MIB, CoS, FNF, 802.1x authentication, DSCP support, MACsec support, 6MB packet buffer, CoPP, SPAN, EEM, PIM, FHS, PVLAN support, CIR |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bz |
| RAM |
4 GB |
| Flash Memory |
4 GB |
| Built-in Devices |
RFID tag |
| Expansion / Connectivity |
| Interfaces |
48 x 1000Base-T RJ-45 partial PoE+ |
| Power |
| Power Device |
Internal power supply - hot-plug |
| Max Supported Qty |
2 |
| Power Redundancy |
Optional |
| Voltage Required |
AC 100-240 V (50/60 Hz) |
| Miscellaneous |
| MTBF |
375,570 hours |
| Compliant Standards |
Plug and Play, CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, EN 55022 Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, CISPR 35 |
| Software / System Requirements |
| Software Included |
Cisco Network Essentials |
| Dimensions & Weight |
| Width |
44.5 cm |
| Depth |
4.4 cm |
| Height |
35 cm |
| Weight |
5.5 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - replacement - lifetime - response time: next business day
Technical support - consulting - 90 days |
| Environmental Parameters |
| Min Operating Temperature |
-5 °C |
| Max Operating Temperature |
45 °C |
| Humidity Range Operating |
5 - 90% (non-condensing) |
| Min Storage Temperature |
-40 °C |
| Max Storage Temperature |
70 °C |
| Humidity Range Storage |
5 - 90% (non-condensing) |
