| Marketing Description |
| The Cisco Meraki MS225-24 is a 24-port cloud-managed stackable L2 enterprise-class access switch with four SFP+ uplinks and support for Cisco's Redundant Power System (RPS) for mission critical environments. The MS225 family includes integrated client and layer 7 application visibility, remote troubleshooting tools like live packet capture and cable test. The MS225 family is 100% cloud-managed via the intuitive, browser-based Meraki dashboard, and includes a rich, out-of-the-box feature set without additional cost and complexity. |
| Product Features |
-
Centrally managed from the cloud
The Cisco Meraki Cloud Networking architecture enables Plug and Play branch deployments and provides centralized visibility and control across any number of distributed locations. The Cisco Meraki MS is the industry's cloud managed switch, combining the benefits of cloud-based centralized management with a powerful, reliable access platform. With cloud management, thousands of switch ports can be configured and monitored instantly, over the web. Provision remote sites without on-site IT, deploy network-wide configuration changes, and easily manage campus and distributed networks without training or dedicated staff.
-
Layer 7 application and client visibility
Cisco Meraki MS Switches are the industry's only switches featuring integrated Layer 7 application and client fingerprinting and analysis. Hundreds of applications are automatically identified and reported, from business apps to BitTorrent and YouTube, so administrators can see where resources are spent.
-
QoS for voice and video
Deploy latency-sensitive applications such as voice and video by guaranteeing network performance. Voice and QoS features such as per-VLAN and protocol-based prioritization, as well as flexible QoS assignments, give intuitive, granular control.
-
Enterprise security
Extending security down to the port level has never been easier. MS Switches integrate seamlessly with enterprise-grade security systems using 802.1x. Define access policies, segregate guest devices, and quarantine entire environments right from the dashboard.
|
| General |
| Device Type |
Switch - 48 ports - Managed - stackable |
| Enclosure Type |
Rack-mountable 1U |
| Subtype |
Gigabit Ethernet |
| Ports |
48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+ (uplink) |
| Power Over Ethernet (PoE) |
PoE+ |
| PoE Budget |
370 W |
| Max Units In A Stack |
8 |
| Remote Management Protocol |
SNMP |
| Authentication Method |
RADIUS |
| Features |
Syslog support, DHCP support, cloud managed, E-mail alert, SMS alert, firmware upgradable, VLAN support, Broadcast Storm Control, RSTP support, STP support, IGMP snooping, LACP, Jumbo Frames support, auto-negotiation, crossover detection, DHCP relay, static routing, IPv4 support, BPDU, Root Guard, RBAC, flow control, auto-uplink (auto MDI/MDI-X), QoS, Cisco Discovery Protocol, LLDP support |
| Compliant Standards |
IEEE 802.3af, IEEE 802.3at, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1D, IEEE 802.1w, IEEE 802.1ab (LLDP), IEEE 802.1x, IEEE 802.3ad (LACP) |
| Expansion / Connectivity |
| Interfaces |
48 x 1000Base-T RJ-45 PoE+
4 x 10Gbit LAN SFP+ uplink |
| Power |
| Power Device |
Internal power supply |
| Power Redundancy |
Optional |
| Voltage Required |
AC 120/230 V (47 - 63 Hz) |
| Features |
Redundant Power System (RPS) connector |
| Miscellaneous |
| MTBF |
381,015 hours |
| Compliant Standards |
CSA, IC, RoHS, FCC, RCM |
| Dimensions & Weight |
| Width |
48.46 cm |
| Depth |
34 cm |
| Height |
4.38 cm |
| Weight |
4.37 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - lifetime |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
5 - 95% (non-condensing) |
