| Marketing Description |
| Perfect for engineering and visualization, HP's popular workstation delivers disruptive performance for a wide spectrum of applications. |
| Product Features |
-
Feature-rich functionality
The Z4 is ahead of its time with more standard features than any other single processor HP workstation.
-
All the power without the noise
Next-generation acoustic design delivers quiet performance. A high frequency processor with a multi-core count is fully capable of handling the demands of 3D CAD and rendering software, so you can visualize your idea anytime during the design process.
-
HP's secure workstations
Advanced security features come standard on every Z4. Rest assured your device, identity and data are safe with security software like HP Client Security Suite and HP Sure Start, the self-healing BIOS with intrusion detection.
|
| General |
| Platform Technology |
Intel vPro Platform |
| Type |
Workstation |
| Bundled Services |
HP Advance Operations Service |
| Product Form Factor |
MT - 4U |
| Embedded Security |
Trusted Platform Module (TPM 2.0) Security Chip |
| Colour |
Black |
| Localisation |
Language: Bulgarian / region: Bulgaria |
| Processor / Chipset |
| CPU |
Intel Xeon W-2235 |
| Clock Speed |
3.8 GHz |
| Max Turbo Speed |
4.6 GHz |
| Number of Cores |
6-core |
| CPU Qty |
1 |
| Max CPU Qty |
1 |
| CPU Upgradability |
Upgradable |
| Processor Main Features |
Hyper-Threading Technology, Intel Turbo Boost Technology 2 |
| CPU Socket |
LGA2066 Socket |
| Chipset Type |
Intel C422 |
| Cache Memory |
| Installed Size |
8.25 MB |
| Cache Per Processor |
8.25 MB |
| RAM |
| Installed Size |
32 GB (installed) / 512 GB (max) |
| Technology |
DDR4 SDRAM - ECC |
| Effective Memory Speed |
2933 MHz |
| Rated Memory Speed |
2933 MHz |
| Memory Specification Compliance |
PC4-23466 |
| Form Factor |
DIMM 288-pin |
| Slots |
8 (Total) / 4 (empty) |
| Features |
Registered |
| Configuration Features |
4 x 8 GB |
| Hard Drive |
| Type |
SSD - M.2 2280 |
| Capacity |
1 x 512 GB |
| Interface Type |
PCI Express 3.0 x4 |
| Features |
HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC) |
| Storage Controller |
| Type |
1 x RAID |
| Controller Interface Type |
SATA 6Gb/s |
| Channel Qty |
6 |
| RAID Level |
RAID 0, RAID 1, RAID 5, RAID 10 |
| Optical Storage |
| Type |
No optical drive |
| Monitor |
| Monitor Type |
None. |
| Graphics Controller |
| Interface Type |
PCIe 3.0 x16 |
| Graphics Processor |
NVIDIA Quadro RTX 4000 |
| Video Memory |
8 GB GDDR6 SDRAM |
| CUDA Cores Qty |
2304 |
| Video Interfaces |
DisplayPort, USB-C |
| Max Monitors Supported |
4 |
| Audio Output |
| Compliant Standards |
High Definition Audio |
| Input Device |
| Type |
Mouse |
| Mouse |
| Technology |
Optical |
| Interface |
USB |
| Networking |
| Ethernet Ports |
2 x Gigabit Ethernet |
| Ethernet Controller |
Intel I219-LM, I210-AT |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features |
Wake on LAN (WoL), PXE support, Intel Active Management Technology (AMT) |
| Expansion / Connectivity |
| Bays |
2 (total) / 2 (free) x external 5.25"
2 (total) / 2 (free) x internal 3.5" |
| Slots |
2 (total) / 1 (free) x PCIe 3.0 x16
2 (total) / 2 (free) x PCIe 3.0 x4 (open ended)
1 (total) / 1 (free) x PCIe 3.0 x8 (open ended)
2 (total) / 2 (free) x M.2 Card - 2280 (x4 mode) |
| Interfaces |
10 x USB 3.1 Gen 1 (4 front, 6 rear) (one of them is charging)
1 x headphones/microphone (1 in front)
1 x audio line-in
1 x audio line-out
1 x PS/2 keyboard
1 x PS/2 mouse
2 x LAN (Gigabit Ethernet)
3 x DisplayPort
1 x DVI-D (with adapter)
1 x USB-C (VirtualLink) |
| Miscellaneous |
| Included Accessories |
HP Z4 CPU Cooling Solution, HP Z4 G4 Fan and Front Card Guide Kit, 6 to 8 pin Graphics Power Cable |
| Cables Included |
DisplayPort-DVI-D adapter |
| Theft/Intrusion Protection |
Security lock slot (cable lock sold separately), padlock loop |
| Security Slot Type |
Kensington security slot |
| Compliant Standards |
RoHS, WEEE, Common Criteria EAL4+, ACPI 5.0, low halogen |
| Power |
| Device Type |
Power supply |
| Voltage Required |
AC 90-269 V (50/60 Hz) |
| Power Provided |
750 Watt |
| 80 PLUS Certification |
80 PLUS |
| Efficiency |
90% |
| Power Factor Correction |
Yes (active) |
| Operating System / Software |
| OS Provided |
Windows 10 Pro for Workstations Plus 64-bit Edition Bulgarian / English |
| Software |
HP Remote Graphics Software |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - parts and labour - 3 years - on-site |
| Dimensions & Weight |
| Width |
16.9 cm |
| Depth |
44.5 cm |
| Height |
38.6 cm |
| Weight |
10.2 kg |
| Dimensions & Weight (Shipping) |
| Shipping Width |
31.4 cm |
| Shipping Depth |
56.3 cm |
| Shipping Height |
57.2 cm |
| Environmental Parameters |
| Min Operating Temperature |
5 °C |
| Max Operating Temperature |
35 °C |
| Humidity Range Operating |
10 - 85% (non-condensing) |
