| Marketing Description |
HPE 2530 switch series consists of four fully managed layer 2 edge switches, delivering cost-effective, reliable, and secure connectivity for business networks. Designed for entry-level to midsize enterprise networks, the Gigabit Ethernet switch delivers full layer 2 capabilities with enhanced access security, traffic prioritization, and IPv6 host support.
For customers implementing Power over Ethernet for voice, video, or wireless deployments, the HPE 2530-24G-PoE+ switch is IEEE 802.3af and IEEE 802.3at compliant with up to 30 W per port.
The HPE 2530 switch series is easy to use, deploy, and manage via SNMP, CLI, and web GUI. The series offers flexible wall, table, and rack mounting; quiet operation; and improved power savings, with features such as IEEE 802.3 az (Energy Efficient Ethernet). |
| Product Features |
-
Robust security
Equipped with RADIUS, Secure Shell v.2 (SSH2), and TACACS+ authentication methods, this switch ensures secure network access and management, safeguarding against unauthorized access and threats.
-
High performance
With a switching capacity of 12.8 Gbps and a forwarding rate of up to 9.5 Mpps, the HPE Aruba 2530-24-PoE+ delivers efficient handling of network traffic, ensuring smooth data transmission across the network.
-
Versatile connectivity
This switch offers 24 Fast Ethernet ports with PoE+ support, alongside 2 Gigabit SFP and 2 10/100/1000 ports, providing a wide range of connection options for various network devices and applications.
-
Advanced networking features
Supports a comprehensive set of networking features including VLAN support, Quality of Service (QoS), IPv6 support, and advanced access control lists (ACLs), enabling efficient network segmentation and prioritization of network traffic.
-
Flexible deployment
Designed to be desktop, rack-mountable, and wall-mountable, this switch offers flexible installation options to accommodate different spatial requirements and deployment scenarios.
|
| General |
| Device Type |
Switch - 24 ports - Managed |
| Enclosure Type |
Desktop, rack-mountable, wall-mountable 1U |
| Subtype |
Fast Ethernet |
| Ports |
24 x 10/100 + 2 x Gigabit SFP + 2 x 10/100/1000 |
| Power Over Ethernet (PoE) |
PoE+ |
| PoE Budget |
195 W |
| Performance |
Throughput: up to 9.5 Mpps
Switching capacity: 12.8 Gbps |
| MAC Address Table Size |
16000 entries |
| Jumbo Frame Support |
9220 bytes |
| Remote Management Protocol |
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH-2, CLI |
| Encryption Algorithm |
SSL |
| Authentication Method |
RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Features |
Flow control, DHCP support, BOOTP support, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), port mirroring, IPv6 support, half duplex mode, full duplex mode, SNTP support, sFlow, MSTP support, ACL support, QoS, STP Root Guard, LLDP support, CoS, GARP |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az |
| Processor |
1 x ARM: 800 MHz |
| RAM |
256 MB DDR3 SDRAM |
| Flash Memory |
128 MB |
| Expansion / Connectivity |
| Interfaces |
2 x 10Base-T/100Base-TX/1000Base-T - RJ-45
2 x SFP (mini-GBIC)
1 x management RJ-45
24 x 10Base-T/100Base-TX - RJ-45 PoE+ |
| Power |
| Power Device |
Internal power supply |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Miscellaneous |
| Compliant Standards |
FCC Class A certified, CISPR 22 Class A, CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, VCCI Class A ITE, EN 61000-3-3, EN55024, EN 55022 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825, CSA C22.2 No. 60950-1 |
| Dimensions & Weight |
| Width |
44.2 cm |
| Depth |
32.26 cm |
| Height |
4.45 cm |
| Weight |
3.81 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - lifetime |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
45 °C |
| Humidity Range Operating |
15 - 95% (non-condensing) |
| Min Storage Temperature |
-40 °C |
| Max Storage Temperature |
70 °C |
| Humidity Range Storage |
15 - 90% (non-condensing) |
