| Marketing Description |
| The Lenovo ThinkSystem SR665 delivers performance and TCO optimization for software-defined workloads, database, big data & analytics, virtualization, virtualized desktop infrastructure (VDI), and HPC/AI workloads. Lenovo's lauded system reliability, management capabilities, and security infrastructure layer on to the exceptional value that the ThinkSystem SR665 brings to the data center. |
| Product Features |
-
Adaptive design
The ThinkSystem SR665 is an all-purpose workhorse, adaptable to numerous enterprise workloads to address a wide range of data management solutions in hybrid data center environments. The ThinkSystem SR665 provides the expandability, networking scalability, and speed necessary to ensure that I/O-intensive workloads such as software defined networking, and grid computing do not encounter bottlenecks that reduce full enterprise efficiency.
-
Innovative management
Trust Lenovo ThinkShield to protect and defend your data center infrastructure from attacks, with a comprehensive end-to-end approach to security that begins with development and continues through supply chain and the full life cycle of the device.
|
| General |
| Type |
Server |
| Product Form Factor |
Rack-mountable - 2U |
| Built-in Devices |
Led panel |
| Embedded Security |
Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability |
2-way |
| Hot-Swap Bays Qty |
8 |
| Localisation |
Region: EMEA |
| Processor / Chipset |
| CPU |
AMD EPYC 7302 |
| Clock Speed |
3 GHz |
| Max Turbo Speed |
3.3 GHz |
| Number of Cores |
16-core |
| CPU Qty |
1 |
| Max CPU Qty |
2 |
| Cache Memory |
| Installed Size |
L3 Cache - 128 MB |
| Cache Per Processor |
128 MB |
| RAM |
| Installed Size |
32 GB |
| Technology |
DDR4 SDRAM - ECC |
| Effective Memory Speed |
3200 MHz |
| Rated Memory Speed |
3200 MHz |
| Form Factor |
DIMM 288-pin |
| Slots |
32 (Total) / 31 (empty) |
| Features |
Registered, 8-channel memory architecture, TruDDR4, Patrol Scrubbing, Demand Scrubbing, slots 17 - 32 are available in two-processor configuration only, Performance+ Memory Mode |
| Configuration Features |
1 x 32 GB |
| RAM Supported |
4 TB 3DS registered |
| Hard Drive |
| Type |
No HDD |
| Storage Controller |
| Type |
1 x RAID - PCIe 4.0 x8 |
| Controller Interface Type |
SAS 12Gb/s |
| Storage Controller Name |
ThinkSystem RAID 940-8i |
| Channel Qty |
8 |
| RAID Level |
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
| Optical Storage |
| Type |
No optical drive |
| Monitor |
| Monitor Type |
None. |
| Graphics Controller |
| Video Memory |
16 MB |
| Networking |
| Remote Management Protocol |
SNMP 3, IPMI 2.0 |
| Remote Management Controller |
XClarity Controller (XCC) Enterprise |
| Expansion / Connectivity |
| Bays |
8 (total) / 8 (free) x hot-swap 2.5" |
| Slots |
1 (total) / 1 (free) x PCIe 4.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (open ended)
1 PCIe 4.0 x16
2 PCIe 4.0 x8 |
| Interfaces |
5 x USB 3.1 Gen 1 (1 front, 3 rear, 1 internal)
1 x USB 2.0 (1 in front)
1 x VGA
1 x management - RJ-45 |
| Miscellaneous |
| Included Accessories |
Slide tool-less rail kit, 5 hot plug performance fans |
| Theft/Intrusion Protection |
Chassis intrusion switch |
| Compliant Standards |
TUV GS, BSMI CNS 13438 Class A, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, CCC, EN 60950-1, FCC Part 15 A, GB 17625.1, GB 9254 Class A, VCCI Class A, GB 4943.1, BSMI CNS 14336-1, BIS, NOM-019, EK1-ITB2000, KN35, ICES-003 issue 6 Class A, AS/NZS CISPR 32 Class A, KN32 Class A, EN 62368-1, IEC 62368-1, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 62368-1, UL 62368-1, EN 55035, TP TC 004/2011, TP TC 020/2011, Redfish API, IEC 60950-1 (CB Certificate and CB Test Report), CNS 15663 section 5, TP EAC 037/2016, EN 50581-1 |
| Power |
| Device Type |
Power supply - hot-plug |
| Power Redundancy |
Optional |
| Power Redundancy Scheme |
1+1 (with optional power supply) |
| Installed Qty |
1 |
| Max Supported Qty |
2 |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Power Provided |
750 Watt |
| 80 PLUS Certification |
80 PLUS Platinum |
| Operating System / Software |
| OS Provided |
No operating system |
| Sustainability Information |
| ENERGY STAR Certified |
Yes |
| ENERGY STAR Version |
3.0 |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 3 years - on-site - response time: next business day |
| Dimensions & Weight |
| Width |
44.5 cm |
| Depth |
76.4 cm |
| Height |
8.7 cm |
| Weight |
38.8 kg |
