| Marketing Description |
| The NETGEAR SOHO Ethernet Unmanaged Switches provide easy and affordable network connectivity to small offices and home/offices. They are easy to use, reliable, and rugged with metal enclosures. Power-over-Ethernet (PoE) support is also available for supplying both power and data across a single CAT-5 ethernet cable to devices such as IP security cameras, VoIP phones, wireless access points, etc. With these Plug-and-Play switches, you can quickly and easily expand your network connections to multiple devices, with no configuration required. |
| Product Features |
-
Robust performance
With a non-blocking bandwidth of 48 Gbps, packet buffer size of 192 KB, and forwarding performance of 1,448,000 pps, the NETGEAR GS324PP ensures efficient data flow and high-speed connectivity for all connected devices.
-
Enhanced connectivity
Featuring 24 PoE+ ports with a total PoE power budget of 380 W, this switch facilitates flexible installation of PoE devices such as IP cameras, VoIP phones, and wireless access points without the need for additional power supplies.
-
Durable and reliable
Designed for longevity and reliability, the GS324PP boasts an impressive MTBF of 667,762 hours, ensuring your network remains operational with minimal downtime.
-
Energy efficient
Incorporates Energy Efficient Ethernet (IEEE 802.3az) for reduced power consumption during low data activity, complemented by two fans for effective cooling, making it an eco-friendly addition to any network infrastructure.
-
Comprehensive network features
Supports advanced networking features such as auto-negotiation, full and half duplex mode, Class of Service (CoS), and DiffServ support, providing the flexibility to meet the needs of various network designs and traffic conditions.
|
| General |
| Device Type |
Switch - 24 ports - unmanaged |
| Enclosure Type |
Rack-mountable, desktop |
| Subtype |
Gigabit Ethernet |
| Ports |
24 x 10/100/1000 (PoE+) |
| Power Over Ethernet (PoE) |
PoE+ |
| PoE Budget |
380 W |
| Performance |
Non-blocking bandwidth: 48 Gbps
Packet buffer size: 192 KB
Forwarding performance (64-byte packet size): 1448000 pps
Latency (64-byte packets): 4 µs |
| MAC Address Table Size |
8K entries |
| Jumbo Frame Support |
10000 bytes |
| Features |
Auto-uplink (auto MDI/MDI-X), auto-negotiation, WRR, full duplex mode, half duplex mode, CoS, DiffServ support, Energy Efficient Ethernet, 2 fans |
| Compliant Standards |
IEEE 802.3at, IEEE 802.1p, IEEE 802.3az, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3i, IEEE 802.3 |
| Status Indicators |
Link/activity/speed, PoE, power, fan |
| Expansion / Connectivity |
| Interfaces |
24 x 1000Base-T RJ-45 PoE+ - 30 W |
| Power |
| Power Device |
Internal power supply |
| Installed Qty |
1 |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Power Consumption Operational |
400 Watt |
| Power Consumption Stand by |
10 Watt |
| Miscellaneous |
| Included Accessories |
Rubber feet |
| Rack Mounting Kit |
Included |
| MTBF |
667,762 hours |
| Compliant Standards |
FCC Part 15 A, IC Class A, RCM, VCCI, KC, CB, LVD, UL |
| Localisation |
Europe |
| Dimensions & Weight |
| Width |
44 cm |
| Depth |
20.4 cm |
| Height |
4.3 cm |
| Weight |
3.3 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 3 years
Limited warranty - phone consulting - 90 days |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
45 °C |
| Humidity Range Operating |
10 - 90% (non-condensing) |
| Min Storage Temperature |
-20 °C |
| Max Storage Temperature |
70 °C |
| Humidity Range Storage |
10 - 95% (non-condensing) |
