| Marketing Description |
ExSiteIP Series is an explosionproof camera system with a built-in 100Base-TX network interface for live streaming to any network application. ExSite IP Series has all of the features and functions of the original ExSite Series, while allowing you to control and monitor video over an IP network from virtually anywhere in the world.
ExSite IP Series supports two simultaneous video streams. The two streams can be compressed in MJPEG, MPEG-4, and H.264 formats across several resolution configurations. The streams can be configured in a variety of frame rates, bit rates, and group of pictures (GOP) structures for additional bandwidth administration. The H.264 compression video files are up to 20 times smaller than MJPEG, making network video storage more affordable.
ExSite IP Series includes a day/night camera with a removable infrared cut filter and 36X zoom lens (36X optical, 12X digital). The electropolished 316L stainless steel construction makes the ExSite Series ideal for all kinds of environmental conditions including marine applications. The system has an absolute operating temperature range of - 60° to 60°C (- 76° to 140°F). Within two hours after power-up, the entire unit can de-ice and be operational from a temperature of - 25°C (- 13°F). |
| Product Features |
- For use in a variety of harsh and/or hazardous environments, including marine environments
- Ability to control and monitor video over IPv4 and IPv6 networks
- Electropolished 316L stainless steel construction
- Upright or inverted operation
- Both fixed and pan/tilt options
- Autofocus, high resolution Integrated Optics Package (IOP) with 36X day/night, motion detection, and 540 TVL horizontal resolution
- Multilingual on-screen menus
- Password protection
- Web interface for camera configuration
- H.264, MPEG-4, and MJPEG compression
- Supported protocols: TCP/IP, UDP/IP (Unicast, Multicast IGMP), UPnP, DNS, DHCP, RTP, RTSP, NTP, IPv4, SNMP, QoS, HTTP, HTTPS, LDAP (client), SSH, SSL, SMTP, FTP, mDNS (Bonjour), and 802.1x (EAP)
- Up to 2 simultaneous video streams
|
| General |
| Device Type |
Network surveillance camera |
| Form Factor |
Dome |
| Connectivity Technology |
Wired |
| Weight |
11.33 kg |
| Camera |
| Type |
Colour - Day&Night - fixed - explosionproof |
| Video Format |
PAL |
| Digital Video Format |
MPEG-4, MJPEG, H.264 |
| Horizontal Resolution (TV Lines) |
540 |
| Max Digital Video Resolution |
704 x 576 |
| Digital Zoom |
12 |
| Exposure Range |
1/5 sec - 1/30000 sec |
| Minimum Illumination |
0.45 lux - colour - shutter 1/2 sec |
| Frame Rate (max) |
25 frames per second |
| Features |
Heater/blower, sunshield, defroster, window wiper, defogger |
| Image Sensor |
| Type |
CCD 1/4" |
| Effective Pixels |
752 x 582 |
| Lens Construction |
| Type |
Motorized zoom |
| Optical Zoom |
36 x |
| Focal Length |
3.3 mm - 119 mm |
| Lens Iris |
F/1.4 auto and manual iris |
| Focus Adjustment |
Automatic, manual |
| Horizontal Field of View (degree) |
2.5 - 82.8 |
| Panning |
| Range (degree) |
200 |
| Tilting |
| Range (degree) |
180 |
| Interfaces |
| Video |
Composite video |
| Network Interface |
Ethernet 10Base-T/100Base-TX |
| Network Protocols |
DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, SNMP, RTSP, RTP, HTTPS, UPnP, IPv4, IPv6, Bonjour, IGMP, SSH, LDAP, SSL, QOS, EAP |
| Alarm Inputs Qty |
7 |
| Expansion / Connectivity |
| Ports |
LAN - RJ-45 |
| Miscellaneous |
| Compliant Standards |
UL, C-Tick, cUL, DEMKO, FCC, NEMA Type 4X, S Mark, IECEx |
| Colour |
Stainless steel |
| Power |
| Power Requirements |
AC 120/230 V - AC 24 V |
| Power Device |
60 Watt |
| Software / System Requirements |
| OS Required |
Microsoft Windows XP or later, Apple MacOS X 10.4 or later |
| System Requirements Details |
Pentium 4 - 1.6 GHz - RAM 512 MB |
| Dimensions & Weight (Shipping) |
| Shipping Weight |
18.14 kg |
| Environmental Parameters |
| Min Operating Temperature |
-60 °C |
| Max Operating Temperature |
60 °C |
