| General |
| Device Type |
NAS server |
| Host Connectivity |
Gigabit Ethernet / 2.5 Gigabit Ethernet |
| Total Storage Capacity |
0 GB |
| Installed Devices / Modules Qty |
0 (installed) / 4 (max) |
| Width |
18 cm |
| Depth |
25.4 cm |
| Height |
6 cm |
| Weight |
2.64 kg () |
| Built-in Devices |
Led panel |
| Localisation |
Chinese (traditional), Chinese (simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Romanian, Brazilian Portuguese, Russian, Spanish, Swedish, Thai, Turkish |
| Processor / Memory |
| Processors Installed |
1 x Intel Celeron J6412 2 GHz |
| Number of Cores |
Quad-Core |
| Max Turbo Speed |
2.6 GHz |
| RAM |
8 GB (installed) / 8 GB (supported) |
| Flash Memory Installed |
4 GB |
| Storage Controller |
| Type |
RAID |
| Interface Type |
SATA 6Gb/s |
| RAID Level |
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, JBOD |
| Networking |
| Data Link Protocol |
2.5GbE, 1GbE, 100Mb LAN |
| Network / Transport Protocol |
TCP/IP, DDNS, FTP, SFTP, PPTP, L2TP, IPSec |
| Remote Management Protocol |
HTTP, HTTPS, SSH, Telnet, SNMP 2, SNMP 3, TFTP |
| Network Services Compatibility |
Web-based Distributed Authoring and Versioning (WebDAV), Microsoft CIFS, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS, FTP, DHCP, Network File System (NFS), DDNS, FTPS |
| Performance |
Maximum volume size: 250 TB
Maximum pool size: 308 TB
Maximum number of storage pool: 128
Maximum shared folder size: 250 TB
Maximum number of shared folder: 512
Maximum number of volume: 128
Maximum LUN size: 250 TB
Maximum number of targets LUN: 256
Minimum snapshot interval: 5 min
Maximum FTP connection: 1024
Local user account: 4096
Local group account: 512
Domain user/group account: 200000
System log & notification centre: 3000 events per second
Virtual hosts: 32
Concurrent connections (CIFS): 1500 |
| Features |
Floating point unit, built-in hardware transcoding, SSD cache acceleration support, Jumbo Frames support, wake on LAN (WOL), Storage Pool, SED Storage Pool, JBOD Expansion, VJBOD Cloud, iSCSI service, fibre channel service, file-based iSCSI LUN, block-based iSCSI LUN, LUN mapping, LUN masking, WWPN Aliases Import/Export, FC Port Group, FC Port Binding, multipath IO (MPIO), online LUN capacity expansion, LUN snapshot, LUN snapshot replication and clone, auto tiering, RAID Group, RAID Level Migration, RAID Expansion, RAID Hot Spare, RAID Sync/Rebuild/Scrubbing, Storage Pool Expansion, EXT4 file system, Disk, Enclosure Locate, Disk S.M.A.R.T. Scan, Disk S.M.A.R.T. Data Migration, Secure Erase, SSD trim, SSD life estimation, Disk Roaming, Disk Standby, Volume Snapshot, Snapshot Retention Policy, Self-serve Snapshot Recovery, Application Consisted Snapshot, Snapshot Full Clone, Snapshot Replica / Vault, SSD read-only Cache, SSD read-write cache, SSD write-only cache, SSD Cache RAID, SSD profiling tool, External Device Management, Mount Smart Phone (MTP), External RAID Device Management, domain security, Domain Controller, user quota, group quota, folder quota, Windows ACL, home folder, Resource Monitor, Smart Fan, schedule on/off, Virtual Switch, port trunking, DHCP server, VLAN support, security counselor, malware remover, 2-step verification, Allow/Deny List, Access Protection, Service binding, firewall protection, Windows ODX, Qsync, HybridMount, hybrid backup sync, Hyper Data Protector, Boxafe, Qsirch, QuMagie, QVPN Service, antivirus analysis, LDAP server, SQL Server, Qfiling, QmailAgent, QuWAN, DA Driver Analyzer |
| Encryption Algorithm |
AES-NI, SSL, TLS, 256-bit AES, FIPS 140-2, TLS 1.0, TLS 1.1, TLS 1.2, TLS 1.3 |
| Compliant Standards |
UPnP |
| Expansion / Connectivity |
| Expansion Bays |
4 (total) / 4 (free) x hot-swap - 2.5" |
| Interfaces |
HDMI output
2 x 2.5 Gigabit Ethernet - RJ-45
4 x USB 3.2 Gen 2 |
| Miscellaneous |
| Cables Included |
1 x network cable
1 x power cable |
| Features |
Security lock slot (cable lock sold separately), reset button, on/off switch, alarm buzzer |
| Security Slot Type |
Kensington security slot |
| Included Accessories |
16 x flat head screws (for 2.5" HDD) |
| Power |
| Power Device |
External power adapter |
| Voltage Required |
AC 100-240 V |
| Power Provided |
90 Watt |
| Software / System Requirements |
| Storage Operating System |
QNAP QTS 5.0.1 |
| Software Included |
IronWolf Health Management |
| OS Required |
Apple OS X 10.10 Yosemite or later, Ubuntu 14.04, CentOS 7.0, IBM AIX 7, Oracle Solaris 10 or later, Red Hat Enterprise Linux 6.6, SuSE Linux 12 or later, Microsoft Windows 7 / 8 / 10 / 11, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2019 |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 3 years |
| Dimensions & Weight (Shipping) |
| Shipping Weight |
3.83 kg |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
5 - 95% RH (non-condensing) |
