| Marketing Description |
| Data center decisions are driven by TCO. The Ultrastar DC HC550 play a leading role in reducing TCO. |
| Product Features |
-
Total cost of ownership (TCO) drives the data center architecture
Data center decisions are driven by TCO. Higher capacity hard drives play a leading role in reducing TCO. Higher capacity HDDs enable data centers to lower CapEx by reducing supporting hardware and system level costs when compared to lower capacity drives. Helium-sealed, low power, high reliability drives reduce energy and maintenance costs, contributing to OpEx savings.
-
Raising the capacity bar with advanced technologies
Ultrastar DC HC550 integrates a suite of technologies on a 9-disk platform to create a different class of HDDs.
|
| General |
| Device Type |
Hard drive - internal |
| Capacity |
14 TB |
| Form Factor |
3.5" |
| Interface |
SATA 6Gb/s |
| Buffer Size |
512 MB |
| Features |
Energy-Assisted Magnetic Recording (EAMR), Media Cache Plus, Rotational Vibration Safeguard (RVS), Triple State Actuator (TSA), Two-Dimensional Magnetic Recording (TDMR), Conventional magnetic recording (CMR), HelioSeal, Sanitise Cryptographic Erase support, Sanitise Cryptographic Scramble support |
| Width |
101.6 mm |
| Depth |
147 mm |
| Height |
26.1 mm |
| Weight |
690 g |
| Performance |
| Drive Transfer Rate |
1.2 GBps (external) |
| Internal Data Rate |
262 MBps |
| Average Latency |
4.16 ms |
| Spindle Speed |
7200 rpm |
| Reliability |
| MTBF |
2,500,000 hours |
| 24x7 Operation |
Yes |
| Non-Recoverable Errors |
1 per 10^15 |
| Load / Unload Cycles |
600,000 |
| Expansion & Connectivity |
| Interfaces |
1 x SATA 6 Gb/s |
| Compatible Bay |
3.5" |
| Power |
| Power Consumption |
8.8 Watt (operating)
5.8 Watt (idle) |
| Software & System Requirements |
| OS Required |
Microsoft Windows, Linux, Microsoft Windows Server |
| Miscellaneous |
| Compliant Standards |
BSMI, ICES-003, FCC, KC, RCM, UKCA, VCCI, CB Scheme, TUV, UL, Maghreb |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 5 years |
| Environmental Parameters |
| Min Operating Temperature |
5 °C |
| Max Operating Temperature |
60 °C |
| Min Storage Temperature |
-40 °C |
| Max Storage Temperature |
70 °C |
| Shock Tolerance (operating) |
50 g @ 2 ms half-sine wave |
| Shock Tolerance (non-operating) |
250 g @ 2 ms half-sine wave |
| Vibration Tolerance (operating) |
0.67 g @ 5-500 Hz |
| Vibration Tolerance (non-operating) |
1.04 g @ 2-200 Hz |
