| Marketing Description |
| The XS508M come with Copper Ethernet ports that provide either Fast Ethernet, 1-Gigabit, 2.5-Gigabit, 5-Gigabit or 10-Gigabit connectivity, as well as 1 SFP+ Fiber port with 1-Gigabit or 10-Gigabit connectivity. Each port automatically detects which speed is needed by the connected device and provides the adequate speed. Also, the new NETGEAR Multi-speed switch ports can be connected with regular Cat5E Ethernet cables, without the need to upgrade to Cat6 wiring, therefore reducing wiring costs and hassle. |
| Product Features |
-
Robust performance
With a bandwidth capacity of 160 Gbps, the NETGEAR XS508M switch ensures efficient handling of large data across its network, making it ideal for businesses with high data demands.
-
Versatile connectivity
Equipped with 7 RJ-45 10GBase-T ports and an additional RJ-45/SFP+ 10Gbit LAN port, this switch offers flexible connection options to meet various networking requirements.
-
Durable design
The metal housing and a built-in fan contribute to the NETGEAR XS508M's durability and reliability, ensuring it operates efficiently even in demanding environments.
-
Energy efficient
Features like Energy-Efficient Ethernet (EEE) and a power consumption of only 39 W make the NETGEAR XS508M an eco-friendly choice for your networking needs.
-
Advanced networking features
Support for Quality of Service (QoS), Class of Service (CoS), and Weighted Round Robin (WRR) allows for prioritization of traffic, ensuring critical data is delivered swiftly and reliably.
|
| General |
| Device Type |
Switch - 8 ports - unmanaged |
| Enclosure Type |
Desktop, rack-mountable |
| Subtype |
10 Gigabit Ethernet |
| Ports |
7 x 10 Gigabit Ethernet + 1 x 10 Gigabit Ethernet / 10 Gigabit Ethernet SFP+ |
| Performance |
Bandwidth: 160 Gbps |
| Capacity |
Priority queues: 8 |
| MAC Address Table Size |
2K entries |
| Jumbo Frame Support |
9KB |
| Features |
DiffServ support, store and forward, QoS, 128KB packet buffer, CoS, metal housing, 1 fan, EEE, WRR |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3aq, IEEE 802.3az, IEEE 802.3bz |
| Status Indicators |
Power, fan, link/activity/speed |
| Expansion / Connectivity |
| Interfaces |
7 x 10GBase-T RJ-45
1 x 10Gbit LAN RJ-45/SFP+ |
| Power |
| Power Device |
Internal power supply |
| Voltage Required |
AC 120/230 V (50 - 60 Hz) |
| Power Consumption Operational |
39 Watt |
| Miscellaneous |
| Rack Mounting Kit |
Included |
| MTBF |
1145157 hours |
| Compliant Standards |
Plug and Play, VCCI, BSMI, ICES-003, EN55024, AS/NZS 60950-1, UL 60950-1, KCC, KC, CNS 13438, EN 55024:2010, FCC CFR47 Part 15 B Class B, AS/NZS CISPR 32 Class B, CNS 14336-1, VCCI V-4/2012.04, VCCI V-3/2015.04 Class B, ANSI C63.4-2014, CISPR 32, EN 55032, EN 55032:2012+AC:2013 Class B, ICES-003:2016 issue 6 Class B, EN 61000-3-2:2014 Class B, EN 6100-3-3:2013, sDoC, CB 60950-1, LVD 60950-1 |
| Localisation |
United Kingdom, Europe |
| Dimensions & Weight |
| Width |
32.8 cm |
| Depth |
16.9 cm |
| Height |
4.32 cm |
| Weight |
1.49 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - replacement - lifetime - response time: next business day
Technical support - lifetime |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
50 °C |
| Humidity Range Operating |
95% (non-condensing) |
| Min Storage Temperature |
-20 °C |
| Max Storage Temperature |
70 °C |
| Humidity Range Storage |
95% (non-condensing) |
