| Marketing Description |
| As a leading provider of network equipment for SMBs, NETGEAR understands the importance of providing great choice of PoE port counts and power budgets that can adapt to the business's needs, whether in the hospitality, catering, education or retail domains. Temperature- and load-based fan-speed control combines accurate monitoring with minimized system acoustic noise: unlike other high power PoE switches on the market, the GS510TPP supports quiet desktop operation or rack mounting with a maximum of 32 dB at full power and 25°C (77°F) ambient. |
| Product Features |
-
Enhanced connectivity
With 16 RJ-45 connectors for 1000Base-T and 2 SFP slots for 1000Base-X, the NETGEAR Smart GS418TPP offers versatile connectivity options for a variety of network needs, ensuring high-speed and reliable connections for all connected devices.
-
Robust security features
The GS418TPP comes equipped with advanced security features such as 802.1x authentication, Access Control List (ACL) support, and DoS attack prevention, providing a secure network environment by protecting against unauthorized access and various types of cyber threats.
-
Efficient power management
Featuring a generous PoE budget of 240 W and support for PoE+, this switch enables the deployment of power-dependent devices such as wireless access points and IP cameras without the need for additional power supplies, while promoting energy efficiency with its ENERGY STAR feature.
-
Advanced network performance
With a fabric throughput of 36 Gbps and a MAC Address Table Size of 16,000 entries, the GS418TPP delivers exceptional performance, ensuring smooth data transmission and efficient handling of high network traffic volumes.
-
Comprehensive network management
Manageable via HTTP and HTTPS, this smart switch supports various remote management protocols, allowing for easy configuration and monitoring of the network. Its Layer 3 Lite capabilities provide enhanced routing features, further extending its functionality.
|
| General |
| Device Type |
Switch - 16 ports - L3 Lite - smart |
| Enclosure Type |
Desktop, rack-mountable |
| Subtype |
Gigabit Ethernet |
| Ports |
16 x 10/100/1000 (PoE+) + 2 x SFP |
| Power Over Ethernet (PoE) |
PoE+ |
| PoE Budget |
240 W |
| Performance |
Fabric throughput: 36 Gbps
Packet forwarding rate: 26.78 Mpps |
| Capacity |
Virtual interfaces (VLANs): 256
ACL: 100
IPv4 routes (static): 32
IPv6 routes (static): 32
IGMP snooping groups: 512
Priority queues: 8
Layer 3 multicast groups: 512 |
| MAC Address Table Size |
16000 entries |
| Jumbo Frame Support |
9KB |
| Routing Protocol |
IGMPv2, IGMP, IGMPv3, MLDv2, MLD |
| Remote Management Protocol |
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP |
| Encryption Algorithm |
TLS 1.0, SSL 3.0 |
| Authentication Method |
RADIUS, TACACS+ |
| Features |
Flow control, ARP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, WRR queuing, store and forward, Broadcast Storm Control, full duplex mode, Multicast Storm Control, Unicast Storm Control, STP support, RSTP support, MSTP support, ACL support, QoS, MLD snooping, LLDP support, DHCP relay, LACP, DHCP client, Energy Efficient Ethernet, MVR, dual firmware images, NAC, 802.1x authentication, DSCP support, 1.5MB packet buffer, ICMP Router Discovery Protocol (IRDP), IGMP querier, 1 fan |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az |
| Processor |
Cortex-A9: 400 MHz |
| RAM |
512 MB |
| Flash Memory |
256 MB |
| Status Indicators |
Port transmission speed, power, link/activity, fan |
| Expansion / Connectivity |
| Interfaces |
16 x 1000Base-T RJ-45 PoE+
2 x 1000Base-X SFP |
| Power |
| Power Device |
Internal power supply |
| Voltage Required |
AC 120/230 V (50 - 60 Hz) |
| Power Consumption Operational |
282.3 Watt |
| Miscellaneous |
| Included Accessories |
4 foot pads |
| Rack Mounting Kit |
Included |
| MTBF |
1,364,013 hours |
| Compliant Standards |
CISPR 22 Class A, EN 60950, UL 1950, EN55024, CSA 22.2 No. 950, AS/NZS 60950-1, CCC, FCC Part 15 A, C-Tick Class A, SCC, VCCI Class A, AS/NZS CISPR22:2009+A1:2010, IEC 60950-1:2005 + A1:2009 + A2:2013, EN 55022 Class A, FCC CFR47 Part 15 B Class A, ICES-003 issue 6 Class A, IEC 950, ANSI C63.4-2014, cUL 950, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 |
| Localisation |
Europe |
| Dimensions & Weight |
| Width |
44 cm |
| Depth |
10 cm |
| Height |
43 cm |
| Weight |
2.14 kg |
| Manufacturer Warranty |
| Service & Support |
NETGEAR lifetime warranty |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
50 °C |
| Humidity Range Operating |
90% (non-condensing) |
| Min Storage Temperature |
-20 °C |
| Max Storage Temperature |
70 °C |
