| Marketing Description |
| IT M4350 switch, engineered and certified for audio/video over IP with dedicated service and support. The M4350 brings all the simplicity from the M4250 AV Line packed in more Enterprise-class hardware with redundant power supplies and larger fabrics. The revolutionary NETGEAR AV user interface and Engage Controller contain pre-configured profiles for all major audio, video, and lighting protocols. |
| Product Features |
-
AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.
-
Multicast in an instant
NETGEAR IGMP Plus provides multicast functionality right out of the box for most AV over IP applications.
-
Sleek, quiet design
Less fan noise, and mounting ears included for rack mounting.
-
Automatic configuration
Auto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.
|
| General |
| Device Type |
Switch - 28 ports - L3 - Managed - stackable |
| Enclosure Type |
Front to back airflow rack-mountable 1U |
| Subtype |
10 Gigabit Ethernet / 25 Gigabit Ethernet |
| Ports |
24 x 100/1000/2.5G/5G/10GBase-T (PoE+) + 4 x 1/10/25 Gigabit SFP28 |
| Power Over Ethernet (PoE) |
PoE+ |
| PoE Budget |
576 W |
| Performance |
Routing/switching capacity: 680 Gbps |
| Capacity |
Packet buffer size: 32 MB
Multicast entries (IPv4): 256
Multicast entries (IPv6): 16
VLANs supported: 4000
Jumbo frame size: up to 12000
IGMP multicast groups: 2000
DHCP users: 2000
ARP entries: 4000
NDP entries: 512 |
| MAC Address Table Size |
16K entries |
| Jumbo Frame Support |
12000 bytes |
| Routing Protocol |
Policy-based routing (PBR), RIP, VRRP, OSPF, PIM-DM, PIM-SM, PIM-SSM, IGMP, IGMPv3, MLDv2, RSTP |
| Remote Management Protocol |
SNMP, HTTPS, CLI, Telnet, SSH, MIB, RSTP, DHCP, RMON |
| Encryption Algorithm |
SSL 3.0, TLS 2.0, 2048-bit RSA, 256-bit SHA-2, 512-bit SHA-2, MD5 |
| Authentication Method |
Secure Shell (SSH), RADIUS, TACACS+ |
| Features |
Jumbo Frames support, LLDP-MED, RSPAN, PTPv2 TC support, MMRP, MVRP, BPDU, STRG, GMRP, GVRP, DAI, IP source guard, DHCPv4 server, DHCPv6 server, proxy ARP, sFlow, BOOTP support, ARP support, DoS attack prevention, DiffServ support, NSF, LACP, Quad-core CPU |
| Compliant Standards |
IEEE 802.1as, IEEE 802.1Qav, IEEE 802.1Qat, IEEE 802.1ak |
| Processor |
X ARM Cortex-A57: 1.8 GHz |
| RAM |
2 GB DDR4 SDRAM |
| Flash Memory |
512 MB |
| Status Indicators |
Link/activity/speed, PoE, power |
| Expansion / Connectivity |
| Interfaces |
24 x 10GBase-T RJ-45 PoE+
4 x 25GBase-X SFP28
1 x management (Gigabit LAN) RJ-45
2 x USB Type A
1 x console (USB) Type C |
| Power |
| Power Device |
Internal power supply |
| Power Provided |
880 Watt |
| Power Consumption Operational |
119.4 Watt |
| Power Consumption Stand by |
53.6 Watt |
| Miscellaneous |
| Included Accessories |
Rubber caps, rubber feet, mounting brackets |
| Cables Included |
1 x console cable |
| Rack Mounting Kit |
Included |
| MTBF |
486,832 hours |
| Compliant Standards |
EN 55032:2012+AC:2013 Class A, CISPR 32:2012, EN 61000-3-2:2014, EN 61000-3-3:2013, AN/NZS 60950.1:2015, ANSI C63.4:2014, AS/NZS CISPR32:2013 Class A, BSMI CNS 13438 Class A, BSMI CNS 14336-1, CCC, cUL 950, EN 55024:2010, EN 60950, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013, FCC CFR 47 Part 15 Class A, GB/T9254-2008 Class A, GB4943.1-2001, ICES-003:2016 issue 6 Class A, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, RCM, UL 1950, VCCI-CISPR 32:2016 Class A, YD/T993-1998 |
| Localisation |
Europe, North America, United Kingdom |
| Dimensions & Weight |
| Width |
44 cm |
| Depth |
40 cm |
| Height |
4.32 cm |
| Weight |
6.58 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - lifetime |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
45 °C |
| Humidity Range Operating |
90% (non-condensing) |
| Min Storage Temperature |
-20 °C |
| Max Storage Temperature |
70 °C |
| Humidity Range Storage |
95% (non-condensing) |
