| Marketing Description |
| The Cisco 1000 series routers combine WAN and comprehensive security in a wired high-performance platform. They provide unparalleled visibility across your WAN, optimal connectivity for end users, and the most comprehensive security platform to protect your network. |
| Product Features |
-
Lightweight, compact size
Can be deployed in many different environments where space, heat dissipation, and low power consumption are critical factors.
-
High performance to run concurrent services
High performance allows customers to take advantage of broadband network speeds while running secure, concurrent data, voice, video, and wireless services.
-
High availability and business continuity
Redundant WAN connections for failover protection and load balancing.
|
| General |
| Device Type |
Router |
| Enclosure Type |
Desktop |
| Connectivity Technology |
Wired |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Network / Transport Protocol |
IPSec, PPPoE, DHCP, DNS, L2TPv3 |
| Routing Protocol |
OSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP, HSRP, DVMRP, VRRP, PIM-SM, static IP routing, IGMPv3, GRE, PIM-SSM, policy-based routing (PBR), MPLS, Bidirectional Forwarding Detection (BFD), RSVP |
| Remote Management Protocol |
SNMP, RMON, CLI |
| Encryption Algorithm |
IKE, PKI, 256-bit AES, 2048-bit RSA, ECDSA 256-bit, ECDSA 384-bit |
| Authentication Method |
RADIUS, TACACS+ |
| Features |
CBWFQ, WRED, ACL support, QoS, DMVPN, NetFlow, MRC, IPFIX, CSD, LISP, packet aggregation A-MPDU, packet aggregation A-MSDU, MIB II, AVC, AAA, DFS, ERSPAN, EEM |
| Compliant Standards |
IEEE 802.1Q, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, CISPR 22, CB, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, EN 61000-4-11, FCC CFR47 Part 15, UL 60950-1, EN 60950-1, VCCI V-3, IEC 60950-1 Second Edition, AS/NZS CISPR 22, CNS 13438, EN 301 489-7, EN 301 489-1, FCC CFR47 Part 22, FCC CFR47 Part 24, EN 300 386, AAA, IEC 60950-1 First Edition, CAN/CSA-C22.2 No. 60950-1, EN 301 489-24, EN 301 908-1, EN 301 908-2, EN 301 511, EN 301 908-13 |
| RAM |
4 GB DDR4 SDRAM |
| Flash Memory |
8 GB |
| Status Indicators |
Status |
| Communications |
| Type |
Wireless cellular modem |
| Mobile Communication Protocol |
UMTS, LTE, FDD LTE |
| Max Transfer Rate |
150 Mbps |
| Expansion / Connectivity |
| Interfaces |
WAN / LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45
USB 3.0: 1 x 9 pin USB Type A
Console: 1 x RJ-45
Antenna: 2 x SMA |
| Expansion Slots |
1 (total) / 1 (free) x SIM |
| Aerial |
| Aerial |
External |
| Antenna Qty |
2 |
| Power |
| Power Device |
External power adapter - 30 Watt |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Miscellaneous |
| Localisation |
Australia, Latin America, Middle East, Europe, South East Asia |
| Dimensions & Weight |
| Width |
25.9 cm |
| Depth |
17.8 cm |
| Height |
2.8 cm |
| Weight |
1.08 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - advance parts replacement - 1 year - response time: 10 days |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
0 - 95% (non-condensing) |
