| Marketing Description |
The QLogic QLE2692 dual-port Enhanced Gen 5 16Gb FC (16GFC) HBAs boast industry leading native FC performance with extremely low CPU usage with full hardware offloads.
Compared to Gen 5 FC, the QLogic Enhanced Gen 5 FC solution offers higher per-port performance (up to 650K IOPS) with low power consumption. In addition, QLogic StorFusion technology delivers streamlined provisioning, QoS, and improved resiliency while addressing the needs of IT organizations that require reliability, integrated management, and guaranteed network performance. Enhanced Gen 5 FC technology resolves data center complexities by enabling a storage network infrastructure that supports powerful virtualization features, application-aware services, and simplified management. The QLE2692 adapters provide advanced storage networking features capable of supporting the most demanding virtualized and private cloud environments while fully leveraging the capabilities of high-performance 16GFC and all-flash arrays (AFAs). Powerful management tools automate and simplify SAN provisioning to help reduce cost and complexity, while the unmatched 16GFC performance eliminates potential I/O bottlenecks in today's powerful multiprocessor, multicore servers.
The QLE2692 adapters can accelerate mission-critical enterprise applications by delivering up to 1.3million IOPS for physical, virtual, and private cloud environments. QLogic adapters deliver the best storage application performance in virtualized and non-virtualized environments with support for over 650K I/O transactions per-second per-port.
The QLE2692 adapters support standards-based virtualization features. Under VMware ESXi 6.0 and 6.5, I/O requests and responses can be tagged with the virtual machine-ID (VM-ID) of the appropriate virtual machine, providing end-to-end visibility at the VM level. Support for N Port ID virtualization (NPIV) enables a single FC adapter port to provide multiple virtual ports for increased network scalability. In addition, the 16Gbps line rate per physical port delivers unmatched storage performance to maximize the number of virtual machines (VMs) per physical server. |
| Product Features |
-
Enhanced connectivity
With dual 16 Gb Fiber Channel ports, the Cisco QLE2692 offers robust connectivity options for high-speed data transfer, ensuring efficient operations and improved system performance.
-
Optimal performance
Leveraging PCI Express 3.0 x8 interface, the adapter maximizes bandwidth and throughput, making it suitable for environments requiring high data transfer rates.
-
Advanced features
Features such as BIOS and UEFI support, along with QLogic StorFusion technology, provide seamless integration and improved management capabilities, enhancing the overall system reliability and user experience.
|
| General |
| Device Type |
Host bus adapter |
| Form Factor |
Plug-in card |
| Interface (Bus) Type |
PCI Express 3.0 x8 |
| PCI Specification Revision |
PCIe 3.0 |
| Networking |
| Ports |
16Gb Fibre Channel x 2 |
| Connectivity Technology |
Wired |
| Data Link Protocol |
16Gb Fibre Channel |
| Fibre Channel |
FC-Tape, FCP-2, SCSI-FCP, FC-GS-2, FC-GS-3, FC-PI-5 |
| Data Transfer Rate |
16 Gbps |
| Remote Management Protocol |
SMI-S |
| Features |
QoS, UEFI support, BIOS support, QLogic StorFusion |
| Expansion / Connectivity |
| Interfaces |
2 x 16Gb Fibre Channel |
| Miscellaneous |
| Compliant Standards |
EN61000-3-2, EN61000-3-3, EN55022, EN55024, BSMI CNS 13438, FCC CFR47, ICES-003 Class A, VCCI Class A |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
55 °C |
| Humidity Range Operating |
10 - 90% |
| Compatibility Information |
| Designed For |
Cisco UCS C220 M4S (Not sold Standalone), C220 M5 Server (Large Form Factor Disk Drive Model), C220 M5SN SFF, C240 M5 LFF Rack Server, C240 M5 LFF Rack Server (Tracer), C240 M5 Rack Server for Microsoft Azure Stack, C240 M5 SFF Rack Server, C480 M5 Standard Base Chassis, S3260 Storage Server, Smart Play C220 M4 SFF Performance, SmartPlay Select C220 M4S (Not sold Standalone ), SmartPlay Select C220 M5 High Core 1, SmartPlay Select C220 M5 Standard 1, SmartPlay Select C220 M5 Standard 2, SmartPlay Select C220 M5S Basic 1 (Tracer), SmartPlay Select C220 M5S Standard 1 (Tracer), SmartPlay Select C220 M5SX, SmartPlay Select C220 M5SX (Tracer), SmartPlay Select C220 M5SX Advanced 1 (Tracer), SmartPlay Select C220 M5SX Advanced 2, SmartPlay Select C220 M5SX Advanced 2 (Tracer), SmartPlay Select C220 M5SX Advanced 3, SmartPlay Select C220 M5SX Advanced 4, SmartPlay Select C220 M5SX Advanced 5, SmartPlay Select C220 M5SX Basic 1, SmartPlay Select C220 M5SX Basic 2, SmartPlay Select C220 M5SX Basic 3, SmartPlay Select C220 M5SX Basic 4, SmartPlay Select C220 M5SX Expansion Pack 2, SmartPlay Select C220 M5SX High Core 2, SmartPlay Select C220 M5SX Standard 2, SmartPlay Select C220 M5SX Standard 2 (Tracer), SmartPlay Select C220 M5SX Standard 3, SmartPlay Select C220 M5SX Standard 4, SmartPlay Select C240 M5 Advanced 2, SmartPlay Select C240 M5 Standard 1, SmartPlay Select C240 M5L High Frequency 1, SmartPlay Select C240 M5L High Frequency 2, SmartPlay Select C240 M5L Standard 1, SmartPlay Select C240 M5L Standard 2, SmartPlay Select C240 M5L Standard 3, SmartPlay Select C240 M5L Standard 4, SmartPlay Select C240 M5SX, SmartPlay Select C240 M5SX (Tracer), SmartPlay Select C240 M5SX Advanced 1, SmartPlay Select C240 M5SX High Frequency 2, SmartPlay Select C240 M5SX Standard 2, SmartPlay Select C240 M5SX Standard 3, SmartPlay Select C240 M5SX Standard 4, SmartPlay Select C240 M5SX Standard 5, SmartPlay Select C240 M5SX Standard 6 |
