| Marketing Description |
Print multi-size projects automatically. Avoid waiting with high-speed printing as fast as 26 seconds per A1/D plot.
AEC, GIS, and MCAD professionals who want to print maps, technical drawings, posters, and renders with precise, accurate line quality and crisp text. |
| Product Features |
-
Extreme simplicity
Print multi-size A3/B and A1/D projects automatically, without manually switching the media source.
-
Fits the way you work
Avoid waiting by the printer with high-speed printing as fast as 26 seconds per A1/D plot. Be more productive - save time from job prep to final print by printing your projects up to 2x faster.
|
| General |
| Printer Type |
36" large-format printer - ink-jet - colour |
| Localisation |
English, German, Spanish, French, Italian / Europe |
| Printer |
| Inkjet Technology |
HP Thermal Inkjet |
| Ink Palette Supported (Colours) |
4-ink - cyan, magenta, yellow, pigment black |
| Nozzle Configuration |
1376 nozzles |
| Minimum Ink Droplet Size |
12 pl (black), 5.5 pl (colour) |
| Ink Cartridge Configuration |
4 cartridges (1 each: cyan, magenta, yellow, pigment black) |
| Print Speed |
Up to 0.45 min/page - black draft - ANSI D (559 x 864 mm)
Up to 0.45 min/page - colour draft - ANSI D (559 x 864 mm)
Up to 0.45 min/page - black draft - A1 (594 x 841 mm)
Up to 0.45 min/page - colour draft - A1 (594 x 841 mm) |
| Connectivity Technology |
Wireless |
| Interface |
USB 2.0, LAN, Wi-Fi |
| Max Resolution (B&W) |
2400 x 1200 dpi |
| Max Resolution (Colour) |
2400 x 1200 dpi |
| Language Simulation |
HP GL/2, HP RTL, CALS G4, JPEG, URF |
| Printer Features |
Print from mobile device, 6.2 kg max roll weight |
| RAM |
| RAM Installed (Max) |
1 GB / 1 GB (max) |
| Media Handling |
| Media Type |
Plain paper, photo paper, bond paper, recycled paper, film, glossy paper |
| Max Media Size |
A0 (841 x 1189 mm), ANSI D (559 x 864 mm), Roll (91.4 cm x 45.7 m) |
| Min Media Size (Custom) |
210 mm x 279 mm |
| Max Media Size (Custom) |
914 mm x 45.7 m |
| Media Sizes |
A4 (210 x 297 mm), A3 (297 x 420 mm), A2 (420 x 594 mm), A1 (594 x 841 mm), ANSI D (559 x 864 mm), Roll (91.4 cm x 45.7 m), A0 (841 x 1189 mm) |
| Media Thickness Range |
Up to 0.3 mm |
| Media Weight |
60 g/m² - 280 g/m² |
| Networking |
| Networking |
Print server |
| Expansion / Connectivity |
| Connections |
1 x USB 2.0 - 4 pin USB Type B
1 x LAN - RJ-45 |
| Miscellaneous |
| Compliant Standards |
FCC Class B certified, ICES Class B, WEEE, ERP |
| Power |
| Power Device |
Power supply - internal |
| Frequency Required |
50/60 Hz |
| Power Consumption Operational |
35 Watt |
| Power Consumption Stand by |
0.2 Watt |
| Power Consumption Sleep |
2.1 Watt |
| Software / System Requirements |
| Software Included |
HP Click, HP DesignJet Utility, HP Support Assistant |
| Environmental Standards |
| EPEAT Compliant |
EPEAT Gold |
| ENERGY STAR |
Yes |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 2 years |
| Environmental Parameters |
| Min Operating Temperature |
5 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
20 - 80% |
| Sound Emission (Idle) |
16 dBA |
| Sound Emission (Operating) |
42 dBA |
| Dimensions & Weight |
| Width |
131.7 cm |
| Depth |
60.5 cm |
| Height |
93.2 cm |
| Weight |
35.4 kg |
| Dimensions & Weight (Shipping) |
| Width (Shipping) |
147 cm |
| Depth (Shipping) |
57.5 cm |
| Height (Shipping) |
59 cm |
| Weight (Shipping) |
56 kg |
