| Marketing Description |
| The HP Z1 Tower G9, HP's most affordable entry desktop workstation, brings designers and editors ISV-certified hardware and industry-leading security for professional workflows. |
| Product Features |
-
Performance
The HP Z1 G9 is equipped with an Intel Core i7 processor, ensuring that users can execute demanding tasks efficiently. This processor enables faster processing speeds, allowing for smoother multitasking and responsiveness in various applications.
-
Upgrade options
With four DDR5 SDRAM slots, the system allows for significant memory upgrades to handle increased workloads. This feature facilitates personalized configurations, making it adaptable for a wide range of professional applications.
-
Connectivity
The workstation includes several connectivity options such as USB 2.0, USB-C 3.2 Gen 2x2, and audio interface for headphones/microphone, ensuring compatibility with a wide range of peripherals and enhancing user experience.
-
Networking capabilities
Featuring support for Fast Ethernet and Gigabit Ethernet, along with Wake on LAN (WoL) and PXE 2.1 support, the HP Z1 G9 provides reliable network connectivity, making it ideal for busy work environments.
-
Security
The inclusion of a Trusted Platform Module (TPM 2.0) security chip offers enhanced security measures, safeguarding sensitive data and ensuring secure operations for professional workloads.
|
| General |
| Type |
Workstation |
| Product Form Factor |
Tower |
| Sensors |
HP Tamper Lock |
| Embedded Security |
Trusted Platform Module (TPM 2.0) Security Chip |
| Localisation |
Language: English / region: Europe |
| Processor / Chipset |
| CPU |
Intel Core i7 (13th Gen) 13700 |
| Clock Speed |
2.1 GHz (P-core) / 1.5 GHz (E-core) |
| Max Turbo Speed |
5.2 GHz (P-core) / 4.1 GHz (E-core) |
| Number of Cores |
16-core |
| CPU Qty |
1 |
| Max CPU Qty |
1 |
| L2 cache |
24 MB |
| CPU Upgradability |
Upgradable |
| Processor Main Features |
Intel Turbo Boost Technology |
| Chipset Type |
Intel Q670 |
| Cache Memory |
| Installed Size |
L3 Cache - 30 MB |
| Cache Per Processor |
30 MB |
| RAM |
| Installed Size |
32 GB (installed) / 128 GB (max) |
| Technology |
DDR5 SDRAM |
| Effective Memory Speed |
2400 MHz |
| Rated Memory Speed |
2400 MHz |
| Form Factor |
DIMM 288-pin |
| Slots |
4 (Total) / 2 (empty) |
| Features |
Unbuffered |
| Configuration Features |
2 x 16 GB |
| Hard Drive |
| Type |
SSD - M.2 2280 |
| Capacity |
1 x 1 TB |
| Interface Type |
PCI Express |
| Features |
NVM Express (NVMe) |
| Storage Controller |
| Type |
1 x SATA/NVMe |
| Controller Interface Type |
SATA 6Gb/s / PCIe 4.0 x4 (NVMe) |
| Optical Storage |
| Type |
No optical drive |
| Card Reader |
| Type |
5 in 1 card reader |
| Supported Flash Memory Cards |
SD Memory Card, SDHC Memory Card, SDXC Memory Card, SDHC UHS-I Memory Card, SDXC UHS-I Memory Card, SDHC UHS-II Memory Card, SDXC UHS-II Memory Card |
| Monitor |
| Monitor Type |
None. |
| Graphics Controller |
| Graphics Processor |
Intel UHD Graphics 770 Dynamic Video Memory Technology |
| Video Interfaces |
HDMI, DisplayPort |
| HDCP Compatible |
Yes |
| Audio Output |
| Sound Output Mode |
Stereo |
| Max Sampling Rate |
192 kHz |
| Compliant Standards |
High Definition Audio |
| Input Device |
| Type |
Mouse, keyboard |
| Keyboard |
| Keyboard Name |
HP 125 |
| Localization & Layout |
International English |
| Mouse |
| Mouse Name |
HP 125 |
| Networking |
| Ethernet Controller |
Intel I219-LM |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol |
SNMP 2 |
| Features |
Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az |
| Expansion / Connectivity |
| Bays |
2 (total) / 2 (free) x external 5.25" Slim Line
2 (total) / 2 (free) x internal 3.5" |
| Slots |
1 (total) / 1 (free) x PCIe 4.0 x16
1 (total) / 1 (free) x PCIe 3.0 x16 (x4 mode)
2 (total) / 2 (free) x PCIe 3.0 x1
1 (total) / 1 (free) x M.2 Card - 2230 (x1 mode)
2 (total) / 1 (free) x M.2 Card - 2280 (x4 mode)
1 (total) / 1 (free) x Flex I/O |
| Interfaces |
1 x headphones/microphone (1 in front) (CTIA and OMTP headset support)
3 x USB 3.2 Gen 1 (3 rear)
4 x USB 3.2 Gen 2 (4 in front) (one of them is fast-charging)
1 x USB-C 3.2 Gen 2x2 (1 in front) (charging)
1 x audio line-out/line-in (1 rear)
2 x DisplayPort 1.4 (2 rear)
3 x USB 2.0 (3 rear)
1 x LAN (Gigabit Ethernet) - RJ-45 (1 rear)
1 x HDMI |
| Miscellaneous |
| Theft/Intrusion Protection |
Security lock slot (cable lock sold separately), padlock loop, chassis intrusion sensor |
| Security Slot Type |
Kensington security slot |
| Compliant Standards |
FCC Class B certified, ICES-003, FIPS 140-2 Level 2, RoHS, UL 60950-1, CCC Class B, KCC Class B, Common Criteria EAL4+, CECP, VCCI Class B, SEPA, low halogen, UL 62368-1, CAN/CSA-C22.2 No. 62368-1-14, CAN/CSA-C22.2 No. 60950-1-07, TCO Certified Edge |
| Manufacturer Selling Program |
HP Smart Buy |
| Power |
| Device Type |
Power supply |
| Voltage Required |
AC 90-264 V (50/60 Hz) |
| Power Provided |
550 Watt |
| 80 PLUS Certification |
80 PLUS Platinum |
| Efficiency |
92% |
| Power Factor Correction |
Yes (active) |
| Operating System / Software |
| OS Provided |
Windows 11 Pro English |
| Software |
HP Support Assistant, HP BIOS Configuration Utility (free download), HP Client Catalogue (free download), HP Driver Packs, HP Setup Integrated OOBE, HP Image Assistant (free download), HP JumpStart, HP System Software Manager (free download), HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Client Management Script Library (free download), Ivanti Management Suite (free download), HP Desktop Support Utilities, HP Tamper Lock, HP Noise Cancellation Software, HP Client Security Manager Gen7, HP SureRun Gen4, HP Sure Recover Gen4, HP Management Integration Kit for Microsoft System Center Configuration Manager Gen 4, HP Sure Start Gen7 |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - parts and labour - 3 years - on-site |
| Dimensions & Weight |
| Width |
15.5 cm |
| Depth |
30.8 cm |
| Height |
33.7 cm |
| Weight |
5.7 kg |
| Dimensions & Weight (Shipping) |
| Shipping Width |
28.7 cm |
| Shipping Depth |
40 cm |
| Shipping Height |
49.9 cm |
| Shipping Weight |
9.24 kg |
| Environmental Parameters |
| Min Operating Temperature |
10 °C |
| Max Operating Temperature |
35 °C |
| Humidity Range Operating |
10 - 90% (non-condensing) |
