| Marketing Description |
| Get high-end performance in a compact device. Designed to pack more graphics and processing power into less space, you can easily take on 2D and 3D CAD projects. And with near endless configuration options, it's the ideal hardware option for custom solutions. |
| Product Features |
-
Performance that defies space constraints
Seamlessly render, design and run multiple apps with professional graphics and a powerful processor. Designed for unthrottled performance, you can render and visualize projects faster.
-
Highly customizable to fit your needs
Build a system matched exactly to your needs with over a million possible configurations. And with customizable I/O ports, you can support next-generation and legacy technologies, dynamic displays and even a second LAN - without messy dongles or adapters.
-
Security and durability you can trust
Backed by 360K hours of rigorous testing and military-standard testing, every component is put to the test. And with hardened security features, your Z2 SFF is protected from the BIOS to the browser, above and below the OS.
-
Intel Core i7 processor
Run several heavy programs simultaneously without sacrificing performance with an Intel Core i7 processor.
-
Smaller, functional design
The stunning design features front and rear ledges, so you can easily move your system from location to location.
|
| General |
| Platform Technology |
Intel vPro Platform |
| Type |
Workstation |
| Product Form Factor |
Tower - 5U |
| Embedded Security |
Trusted Platform Module (TPM 2.0) Security Chip |
| Colour |
Black |
| Localisation |
Language: English / region: Europe |
| Processor / Chipset |
| CPU |
Intel Core i7 (11th Gen) 11700 |
| Clock Speed |
2.5 GHz |
| Max Turbo Speed |
4.9 GHz |
| Number of Cores |
8-core |
| CPU Qty |
1 |
| Max CPU Qty |
1 |
| CPU Upgradability |
Upgradable |
| Processor Main Features |
Hyper-Threading Technology, Intel Turbo Boost Max 3.0 |
| CPU Socket |
FCLGA1200 Socket |
| Chipset Type |
Intel W580 |
| Cache Memory |
| Installed Size |
16 MB |
| Cache Per Processor |
16 MB |
| RAM |
| Installed Size |
16 GB (installed) / 128 GB (max) |
| Technology |
DDR4 SDRAM - non-ECC |
| Effective Memory Speed |
3200 MHz |
| Rated Memory Speed |
3200 MHz |
| Form Factor |
DIMM 288-pin |
| Slots |
4 (Total) / 3 (empty) |
| Features |
Unbuffered, dual channel memory architecture |
| Configuration Features |
1 x 16 GB |
| Hard Drive |
| Type |
SSD - M.2 2280 |
| Capacity |
1 x 512 GB |
| Interface Type |
PCI Express 3.0 x4 |
| SSD Endurance |
300 TB |
| Features |
NVM Express (NVMe), triple-level cell (TLC), 3D NAND Technology |
| Storage Controller |
| Type |
1 x SATA |
| Controller Interface Type |
SATA 6Gb/s |
| Channel Qty |
4 |
| RAID Level |
RAID 0, RAID 1 |
| Optical Storage |
| Type |
No optical drive |
| Monitor |
| Monitor Type |
None. |
| Graphics Controller |
| Graphics Processor |
NVIDIA T1000 / Intel UHD Graphics 750 |
| Video Memory |
4 GB GDDR6 SDRAM |
| Video Interfaces |
DisplayPort |
| Audio Output |
| Compliant Standards |
High Definition Audio |
| Input Device |
| Type |
Mouse, keyboard |
| Keyboard |
| Keyboard Name |
HP 320K |
| Interface |
USB |
| Localization & Layout |
International English |
| Mouse |
| Mouse Name |
HP 320M |
| Networking |
| Ethernet Controller |
Intel I219-LM |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features |
Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support, Intel Active Management Technology (AMT) 15 |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az |
| Expansion / Connectivity |
| Bays |
1 (total) / 1 (free) x external 5.25"
1 (total) / 1 (free) x external 5.25" Slim Line
2 (total) / 2 (free) x internal 3.5"
1 (total) / 1 (free) x internal 2.5" |
| Slots |
1 (total) / 0 (free) x PCIe 4.0 x16 - full-length, full-height
1 (total) / 1 (free) x PCIe 3.0 x4 - full-length, full-height (x1 mode, open ended)
1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height (x4 mode)
1 (total) / 1 (free) x PCIe 3.0 x4 - full-length, full-height (open ended)
1 (total) / 1 (free) x M.2 Card - 2280 (PCIe 4.0 x4 mode)
1 (total) / 0 (free) x M.2 Card - 2280 (PCIe 3.0 x4 mode)
1 (total) / 1 (free) x M.2 Card - 2230 (PCIe 3.0 x1 mode and Intel CNVi wireless module) |
| Interfaces |
1 x headphones/microphone (1 in front) (CTIA and OMTP headset support)
2 x USB 3.2 Gen 1 (2 in front) (one of them is charging)
4 x USB 3.2 Gen 2 (2 front, 2 rear)
1 x audio line-out
2 x DisplayPort 1.4
3 x USB 2.0
1 x LAN (Gigabit Ethernet)
1 x USB 3.2 Gen 1
1 x audio line-in
4 x Mini DisplayPort 1.4 |
| Miscellaneous |
| Included Accessories |
HP Tower Card Holder/Blower Kit |
| Theft/Intrusion Protection |
Security lock slot (cable lock sold separately) |
| Security Slot Type |
Kensington security slot |
| Compliant Standards |
RoHS, WEEE, CECP, SEPA, low halogen |
| Power |
| Device Type |
Power supply |
| Voltage Required |
AC 90-269 V (50/60 Hz) |
| Power Provided |
700 Watt |
| 80 PLUS Certification |
80 PLUS |
| Efficiency |
92% |
| Power Factor Correction |
Yes (active) |
| Operating System / Software |
| OS Provided |
Windows 10 Pro 64-bit Edition + Windows 11 License (may come preloaded with Windows 11) - English |
| Software |
HP Support Assistant, Windows Defender, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP BIOS Config Utility, HP Image Assistant, HP Documentation, HP PC Hardware Diagnostics, HP System Software Manager, HP Notifications, HP Performance Advisor (free download), HP ZCentral Remote Boost 2020, HP QuickDrop, HP Manageability Integration Kit Gen4 (free download), HP BIOSphere Gen6, HP Wake on WLAN, HP Desktop Support Utility, myHP, HP Client Security Manager Gen7, HP Smart Support (free download) |
| Sustainability Information |
| EPEAT Compliant |
EPEAT Gold |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - parts and labour - 3 years - on-site |
| Dimensions & Weight |
| Width |
16.9 cm |
| Depth |
38.5 cm |
| Height |
35.6 cm |
| Weight |
7 kg |
| Dimensions & Weight (Shipping) |
| Shipping Width |
29.5 cm |
| Shipping Depth |
49 cm |
| Shipping Height |
51.8 cm |
| Environmental Parameters |
| Min Operating Temperature |
5 °C |
| Max Operating Temperature |
35 °C |
| Humidity Range Operating |
10 - 85% (non-condensing) |
