| Marketing Description |
| Perfect for engineering and visualization, HP's popular workstation delivers disruptive performance for a wide spectrum of applications. |
| Product Features |
-
Feature-rich functionality
The Z4 is ahead of its time with more standard features than any other single processor HP workstation.
-
All the power without the noise
Next-generation acoustic design delivers quiet performance. A high frequency processor with a multi-core count is fully capable of handling the demands of 3D CAD and rendering software, so you can visualize your idea anytime during the design process.
-
HP's secure workstations
Advanced security features come standard on every Z4. Rest assured your device, identity and data are safe with security software like HP Client Security Suite and HP Sure Start, the self-healing BIOS with intrusion detection.
|
| General |
| Platform Technology |
Intel vPro Platform |
| Type |
Workstation |
| Product Form Factor |
MT - 4U |
| Embedded Security |
Trusted Platform Module (TPM 2.0) Security Chip |
| Colour |
Black |
| Localisation |
Language: English / region: Europe |
| Processor / Chipset |
| CPU |
Intel Xeon W-2223 |
| Clock Speed |
3.6 GHz |
| Max Turbo Speed |
3.9 GHz |
| Number of Cores |
Quad-Core |
| CPU Qty |
1 |
| Max CPU Qty |
1 |
| CPU Upgradability |
Upgradable |
| Processor Main Features |
Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache |
| CPU Socket |
LGA2066 Socket |
| Chipset Type |
Intel C422 |
| Cache Memory |
| Installed Size |
8.25 MB |
| Cache Per Processor |
8.25 MB |
| RAM |
| Installed Size |
16 GB (installed) / 256 GB (max) |
| Technology |
DDR4 SDRAM - ECC |
| Effective Memory Speed |
2933 MHz |
| Rated Memory Speed |
2933 MHz |
| Form Factor |
DIMM 288-pin |
| Slots |
8 (Total) / 7 (empty) |
| Features |
Registered |
| Configuration Features |
1 x 16 GB |
| Hard Drive |
| Type |
SSD - 2.5" |
| Capacity |
1 x 512 GB |
| Interface Type |
SATA 6Gb/s |
| Features |
Triple-level cell (TLC) |
| Storage Controller |
| Type |
1 x SATA |
| Controller Interface Type |
SATA 6Gb/s |
| Channel Qty |
6 |
| RAID Level |
RAID 0, RAID 1, RAID 10 |
| Optical Storage |
| Type |
DVD-Writer - SATA |
| Monitor |
| Monitor Type |
None. |
| Graphics Controller |
| Graphics Processor |
No graphics |
| Audio Output |
| Compliant Standards |
High Definition Audio |
| Input Device |
| Type |
Mouse, keyboard |
| Keyboard |
| Keyboard Name |
HP Business Slim Keyboard |
| Interface |
USB |
| Localization & Layout |
International English |
| Mouse |
| Technology |
Optical |
| Interface |
USB |
| Networking |
| Ethernet Controller |
Intel I219-LM |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features |
Wake on LAN (WoL), PXE support |
| Expansion / Connectivity |
| Bays |
2 (total) / 1 (free) x external 5.25"
2 (total) / 1 (free) x internal 3.5" |
| Slots |
2 (total) / 2 (free) x PCIe 3.0 x16
2 (total) / 2 (free) x PCIe 3.0 x4
1 (total) / 1 (free) x PCIe 3.0 x8
2 (total) / 2 (free) x M.2 Card |
| Interfaces |
8 x USB 3.1 Gen 1 (2 front, 6 rear)
1 x headphones/microphone (1 in front)
2 x USB 2.0
1 x audio line-in
1 x audio line-out
2 x USB-C (2 in front)
1 x PS/2 keyboard
1 x PS/2 mouse
2 x LAN (Gigabit Ethernet) |
| Miscellaneous |
| Theft/Intrusion Protection |
Security lock slot (cable lock sold separately) |
| Security Slot Type |
Kensington security slot |
| Compliant Standards |
ACPI, RoHS, FIPS 140-2, Common Criteria EAL4+, WEEE 2002/96/EC, ISO 11469, ISO 1043 |
| Power |
| Device Type |
Power supply |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Power Provided |
1000 Watt |
| 80 PLUS Certification |
80 PLUS |
| Efficiency |
90% |
| Power Factor Correction |
Yes (active) |
| Operating System / Software |
| OS Provided |
Windows 10 Pro 64-bit Edition English |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - parts and labour - 3 years - on-site |
| Dimensions & Weight |
| Width |
16.9 cm |
| Depth |
44.5 cm |
| Height |
38.6 cm |
| Weight |
11.3 kg |
| Environmental Parameters |
| Min Operating Temperature |
5 °C |
| Max Operating Temperature |
35 °C |
| Humidity Range Operating |
10 - 85% (non-condensing) |
