| Marketing Description |
| HPE ProLiant MicroServer Gen10 Plus v2 delivers an affordable compact yet powerful entry level server that you can customize for on-premises, hybrid cloud, or even workloads demanding datacenter performance. It has the same design as the previous version and can be placed flat or vertically depending on customer environment. The powerful processors deliver compute performance as well as security and remote management into the server with HPE iLO silicon root of trust. Along with other enhancements such onboard NICs and USB 3.2 Gen2 Type-A, whether you want a general-purpose server, NAS or even a virtualization server, you will be surprised at how much you can get out of this small and affordable server. |
| Product Features |
-
Efficient performance
Equipped with an Intel Xeon E-2314 quad-core processor that reaches up to 4.5 GHz, this server delivers reliable and efficient performance for demanding business applications.
-
Robust storage options
With four internal 3.5" LFF bays and support for RAID 0, 1, 10, and 5 configurations, the server offers flexible and secure storage solutions to meet diverse data requirements.
-
Advanced connectivity
Featuring a comprehensive set of interfaces including VGA, DisplayPort, USB 3.2 Gen 1 and Gen 2, and Gigabit Ethernet ports, this server ensures high-speed connectivity and easy integration into existing networks.
-
Enhanced security
The server is equipped with a Trusted Platform Module (TPM 2.0) security chip, providing hardware-based encryption keys to protect against data breaches and cyber threats.
-
Expandable and scalable
Thanks to its upgradable RAM, low-profile PCIe 4.0 x16 expansion slot, and additional iLO Enablement Kit slot, the server offers ample room for growth and scalability to accommodate future business needs.
|
| General |
| Type |
Server |
| Product Form Factor |
Ultra micro tower |
| Embedded Security |
Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability |
1-way |
| Internal Bays Qty |
4 |
| Localisation |
Region: EMEA |
| Processor / Chipset |
| CPU |
Intel Xeon E-2314 |
| Clock Speed |
2.8 GHz |
| Max Turbo Speed |
4.5 GHz |
| Number of Cores |
Quad-Core |
| CPU Qty |
1 |
| Max CPU Qty |
1 |
| CPU Upgradability |
Upgradable |
| Processor Main Features |
Intel Turbo Boost Technology 2, Intel Smart Cache |
| CPU Socket |
LGA1200 Socket |
| Chipset Type |
Intel C252 |
| Cache Memory |
| Installed Size |
L3 Cache - 8 MB |
| Cache Per Processor |
8 MB |
| RAM |
| Installed Size |
16 GB (installed) / 64 GB (max) |
| Technology |
DDR4 SDRAM - ECC |
| Effective Memory Speed |
3200 MHz |
| Rated Memory Speed |
3200 MHz |
| Form Factor |
DIMM 288-pin |
| Slots |
2 (Total) / 1 (empty) |
| Features |
Unbuffered |
| Configuration Features |
1 x 16 GB |
| Hard Drive |
| Type |
No HDD |
| Storage Controller |
| Type |
1 x RAID |
| Controller Interface Type |
SATA 6Gb/s |
| Storage Controller Name |
Intel VROC SATA Software RAID |
| RAID Level |
RAID 0, RAID 1, RAID 5, RAID 10 |
| Optical Storage |
| Type |
No optical drive |
| Monitor |
| Monitor Type |
None. |
| Graphics Controller |
| Graphics Processor |
No graphics |
| Video Interfaces |
DisplayPort, VGA |
| Networking |
| Ethernet Ports |
4 x Gigabit Ethernet |
| Ethernet Controller |
Intel I350-AM4 |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol |
SNMP 3, IPMI 2.0, SMASH CLP |
| Features |
ACPI support, PXE support, Wake on LAN (WoL) |
| Expansion / Connectivity |
| Bays |
4 (total) / 4 (free) x internal 3.5" LFF |
| Slots |
1 (total) / 1 (free) x PCIe 4.0 x16 - low-profile
1 (total) / 1 (free) x expansion slot (iLO Enablement Kit slot) |
| Interfaces |
1 x VGA
1 x DisplayPort
4 x USB 3.2 Gen 1 - Type A (3 rear, 1 internal)
2 x USB 3.2 Gen 2 - Type A (2 in front)
1 x USB 2.0 - Type A (1 rear)
4 x LAN (Gigabit Ethernet) |
| Miscellaneous |
| Theft/Intrusion Protection |
Security lock slot (cable lock sold separately), padlock loop |
| Security Slot Type |
Kensington security slot |
| Compliant Standards |
FCC Class B certified, CISPR 32, EN 55032, EN55024, FCC CFR47 Part 15, ICES-003, CNS 13438, GB 9254, K32, K24, EN 61000-3-2, EN 61000-3-3 |
| Power |
| Device Type |
Power adapter |
| Voltage Required |
AC 100-240 V (50/60 Hz) |
| Power Provided |
180 Watt |
| Operating System / Software |
| OS Provided |
No operating system |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - parts and labour - 1 year - on-site - response time: next business day |
| Dimensions & Weight |
| Width |
24.5 cm |
| Depth |
24.5 cm |
| Height |
11.89 cm |
| Weight |
4.23 kg |
| Environmental Parameters |
| Humidity Range Operating |
8 - 90% RH (non-condensing) |
| Sound Emission |
24 dBA |
