| Marketing Description |
| The Emulex Fiber Channel (FC) host bus adapter (HBAs) is an ideal solution for servers requiring high-speed data transfer in storage connectivity for virtualized environments, data backup, and mission-critical applications. It is designed to meet the needs of modern networked storage systems that utilize high-performance and low-latency solid-state storage drives for caching and persistent storage as well as hard disk drive arrays. The Emulex FC HBA features ExpressLane, which prioritizes mission-critical traffic in congested networks ensuring maximum application performance on flash storage arrays. |
| Product Features |
-
Plenty of input / output operations
Maximum performance with up to 1.6 million input / output operations per second (IOPS) to support larger server virtualization deployments and scalable cloud initiatives, and performance to match multicore processors, SSDs / flash storage, and faster server host bus architectures.
-
ExpressLane technology
Offer end-to-end Quality of Service (QoS) application prioritization with ExpressLane technology, which allows customers to prioritize faster storage traffic (such as SSDs) ahead of slower traffic (such as spinning hard drives), alleviating potential bottlenecks from slow storage.
-
Increased link efficiency
Frame-level multiplexing and out-of-order frame reassembly increases link efficiency and maximizes HBA performance.
|
| General |
| Device Type |
Host bus adapter |
| Form Factor |
Plug-in card - low profile |
| Interface (Bus) Type |
PCI Express 3.0 x8 |
| Networking |
| Ports |
16Gb Fibre Channel |
| Connectivity Technology |
Wired |
| Data Link Protocol |
4Gb Fibre Channel, 8Gb Fibre Channel, 16Gb Fibre Channel |
| Fibre Channel |
FC-DA, FC-FS, FC-GS-2, FC-GS-3, FC-GS-4, FC-MI, FC-PH, FC-PH-2, FC-PH-3, FC-PI, FC-Tape, FCP-4, FCP-2, FC-PI-2, FC-GS-5, FCP-3, FC-PI-4, FC-FS-3, FC-GS-6, FC-PI-3, FC-HBA, FC-PI-5, FC-LS-2, FC-DA-2, SSC-2, SBC-2, SPC-3, FC-PI-6, SBC-3, SPC-4, SSC-4 |
| Data Transfer Rate |
14.025 Gbps |
| Performance |
Maximum IOPS: 1600000 |
| Features |
QoS, SR-IOV, FEC, MSI-X |
| Processor / Memory |
| Processor |
1 x Emulex |
| Expansion / Connectivity |
| Interfaces |
1 x 16Gb Fibre Channel - SFP+ |
| Miscellaneous |
| Included Accessories |
Low-profile bracket, full-height bracket, 16 Gb shortwave Fibre Channel SFP+ LC transceiver |
| MTBF |
10,000,000 hour(s) |
| Compliant Standards |
ICES-003 Class A, UL 60950-1 Second Edition, CSA C22.2 No. 60950-1-07, FCC Part 15 A, BSMI Class A, VCCI Class A, MSIP Class A, China RoHS, RCM, RoHS 2011/65/EU, EN55022:2010 Class A, AS/NZS CISPR22:2009+A1 Class A, EN 55024:2010, EN 55032:2012, EN60950-1+A11+A1+A12+A2 |
| Software / System Requirements |
| OS Required |
Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, SuSE Linux Enterprise Server 12, VMware vSphere 5.5 update 2, SuSE Linux Enterprise Server 12 SP1, SuSE Linux Enterprise Server 11 SP4 for AMD64/EM64T, SuSE Linux Enterprise Server 11 SP3 for AMD64/EM64T, VMware vSphere 5.5 update 3, VMware vSphere 6.0 update 1, VMware vSphere 6.0 update 2, Red Hat Enterprise Linux 7 Update 2, Red Hat Enterprise Linux 7 Update 1, Red Hat Linux Enterprise Server 6 Update 7 x64 Edition |
| Dimensions & Weight |
| Depth |
16.8 cm |
| Height |
6.9 cm |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 1 year |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
55 °C |
| Humidity Range Operating |
5 - 95% (non-condensing) |
| Compatibility Information |
| Designed For |
Lenovo NeXtScale nx360 M5 5465
Lenovo System x3500 M5 5464
Lenovo System x3550 M5 5463, 8869
Lenovo System x3650 M5 5462, 8871
Lenovo System x3750 M4 8753
Lenovo System x3850 X6 6241
Lenovo System x3950 X6 6241
Lenovo ThinkSystem SR250
Lenovo ThinkSystem SR530 7X08
Lenovo ThinkSystem SR590
Lenovo ThinkSystem SR630 7X02
Lenovo ThinkSystem SR630 V2 7Z71
Lenovo ThinkSystem SR645 7D2X
Lenovo ThinkSystem SR650 7X06
Lenovo ThinkSystem SR650 V2 7D15, 7Z73
Lenovo ThinkSystem SR665 7D2V, 7D2W
Lenovo ThinkSystem SR850 V2 7D32
Lenovo ThinkSystem ST250
Lenovo ThinkSystem ST550 7X10
Lenovo ThinkSystem ST650 V2 7Z74, 7Z75 |
