| Marketing Description |
| The QLogic Enhanced Generation 5 (Gen 5) 16Gb Fiber Channel (FC) Host Bus Adapters (HBAs) offer outstanding native FC performance with extremely low CPU usage with full hardware offloads. Enhanced Gen 5 FC technology provides advanced storage networking features capable of supporting highly demanding virtualized and private cloud environments, while fully leveraging the capabilities of high-performance 16Gb FC (16GFC) and all-flash arrays (AFAs). |
| General |
| Device Type |
Host bus adapter |
| Form Factor |
Plug-in card - low profile |
| Interface (Bus) Type |
PCI Express 3.0 x8 |
| Networking |
| Ports |
16Gb Fibre Channel |
| Connectivity Technology |
Wired |
| Data Link Protocol |
4Gb Fibre Channel, 8Gb Fibre Channel, 16Gb Fibre Channel |
| Fibre Channel |
FC-GS-2, FC-GS-3, FC-Tape, FCP-2, FC-PI-5, SCSI-FCP |
| Data Transfer Rate |
14.025 Gbps |
| Performance |
Maximum IOPS: 1300000 |
| Features |
QoS, FEC, MSI-X, FA-WWN, F-BLD, LCB |
| Expansion / Connectivity |
| Interfaces |
1 x 16Gb Fibre Channel |
| Miscellaneous |
| Included Accessories |
Low-profile bracket, full-height bracket, 16 Gb shortwave Fibre Channel SFP+ LC transceiver |
| Compliant Standards |
ICES-003 Class A, UL 60950-1 Second Edition, FCC Part 15 A, BSMI Class A, KCC Class A, VCCI Class A, EN55022:2010 Class A, AS/NZS CISPR22:2009+A1 Class A, EN 55024:2010, CAN/CSA C22.2 No. 60950-1-07 Second Edition 2011-12, EN60950-1:2006 +A11+A1+A12 (2nd Edition) |
| Software / System Requirements |
| OS Required |
Microsoft Windows Server 2012, Red Hat Enterprise Linux 6 x64 Edition, Microsoft Windows Server 2012 R2, Red Hat Enterprise Linux 7, SuSE Linux Enterprise Server 12, VMware vSphere 5.5 update 2, SuSE Linux Enterprise Server 12 SP1, SuSE Linux Enterprise Server 11 SP4 for AMD64/EM64T, SuSE Linux Enterprise Server 11 SP3 for AMD64/EM64T, VMware vSphere 5.5 update 3, VMware vSphere 6.0, VMware vSphere 6.0 update 1, VMware vSphere 6.0 update 2 |
| Dimensions & Weight |
| Depth |
16.8 cm |
| Height |
6.9 cm |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 1 year |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
55 °C |
| Humidity Range Operating |
10 - 90% (non-condensing) |
| Compatibility Information |
| Designed For |
Lenovo NeXtScale nx360 M5
Lenovo System x3500 M5
Lenovo System x3550 M5
Lenovo System x3650 M5
Lenovo System x3750 M4
Lenovo System x3850 X6
Lenovo System x3950 X6
Lenovo ThinkSystem SR250 7Y51
Lenovo ThinkSystem SR530 7X08
Lenovo ThinkSystem SR590
Lenovo ThinkSystem SR630 7X02
Lenovo ThinkSystem SR630 V2 7Z71
Lenovo ThinkSystem SR645 7D2X
Lenovo ThinkSystem SR650 7X06
Lenovo ThinkSystem SR650 V2 7D15, 7Z73
Lenovo ThinkSystem SR665 7D2V, 7D2W
Lenovo ThinkSystem SR850 V2 7D32
Lenovo ThinkSystem ST550 7X10
Lenovo ThinkSystem ST650 V2 7Z74, 7Z75 |
