| Marketing Description |
| The ThinkSystem S4520 Mixed Use SATA SSDs are advanced data center SSDs optimized for mixed read-write performance, endurance and strong data protection. Compared with the Intel S4610 series, these new drives offer improved endurance. |
| Product Features |
-
Enhanced Durability
Built to withstand the rigors of any environment, the Lenovo ThinkSystem S4620 solid state drive boasts a shock acceleration (non-operating) of 1000 g and a vibration frequency range (operating) of 5-700 Hz, ensuring reliability and longevity under the most demanding conditions.
-
Exceptional Performance
Experience fast data access with the Lenovo ThinkSystem S4620, featuring an impressive 4KB random read of 85,000 IOPS and a 4KB random write of 56,000 IOPS, coupled with an average latency of just 36 μs. This performance is ideal for critical applications and high-demand systems.
-
High Capacity Storage
With a generous 960 GB capacity, the Lenovo ThinkSystem S4620 meets the growing demands for storage in modern data centers, supporting extensive data archives and dynamic workloads without compromising on speed or efficiency.
-
Advanced Data Protection
Ensure your data's safety with the Lenovo ThinkSystem S4620, featuring end-to-end data protection and power loss data protection. These features safeguard your data from unexpected events, providing peace of mind and reducing the risk of data loss.
-
Sustainable Compliance
The Lenovo ThinkSystem S4620 adheres to a comprehensive range of compliance standards, including RoHS, WEEE, and various EMC and safety standards. This commitment to environmental and safety standards makes it a responsible choice for your IT infrastructure.
|
| General |
| Device Type |
Solid state drive - hot-swap |
| Capacity |
960 GB |
| NAND Flash Memory Type |
3D triple-level cell (TLC) |
| Form Factor |
2.5" |
| Interface |
SATA 6Gb/s |
| Features |
End-to-end data protection, power loss data protection, S.M.A.R.T. |
| Width |
70 mm |
| Depth |
100 mm |
| Height |
7 mm |
| Weight |
70 g |
| Performance |
| Drive Writes Per Day (DWPD) |
4 |
| SSD Endurance |
7.1 PB |
| Drive Class |
Mixed Use |
| Drive Transfer Rate |
600 MBps (external) |
| Internal Data Rate |
550 MBps (read) / 510 MBps (write) |
| 4KB Random Read |
85000 IOPS |
| 4KB Random Write |
56000 IOPS |
| Average Latency |
36 μs |
| Reliability |
| MTBF |
2,000,000 hours |
| Non-Recoverable Errors |
1 per 10^17 |
| Expansion & Connectivity |
| Interfaces |
1 x SATA 6 Gb/s |
| Compatible Bay |
2.5" |
| Miscellaneous |
| Compliant Standards |
VCCI, ICES-003, UL 60950-1, CSA C22.2 No. 60950-1-07, CNS 13438, RoHS 2011/65/EU, EN55022:2006, AS/NZS CISPR22:2009+A1:2010, WEEE 2012/19/EU, EMC 2014/30/EU, LVD 2014/35/EU, EN 55032:2012, KCC Article 11.1, AS/NZS CISPR 32:2015, EN 55035:2017, FCC Title 47 |
| Dimensions & Weight (Shipping) |
| Shipping Width |
17.4 cm |
| Shipping Depth |
13.3 cm |
| Shipping Height |
6.3 cm |
| Shipping Weight |
434 g |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - replacement - 1 year |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
70 °C |
| Humidity Range Operating |
5 - 95% (non-condensing) |
| Shock Tolerance (non-operating) |
1000 g @ 0.5 ms |
| Vibration Tolerance (operating) |
5-700 Hz |
| Compatibility Information |
| Designed For |
Lenovo ThinkAgile VX3530-G Appliance 7Z63 (2.5")
Lenovo ThinkAgile VX7530 Appliance 7Z63 (2.5")
Lenovo ThinkAgile VX7531 Certified Node 7Z63 (2.5")
Lenovo ThinkStation P920 Rack 7X06 (2.5")
Lenovo ThinkSystem SD530 7X21 (2.5")
Lenovo ThinkSystem SN550 7X16 (2.5")
Lenovo ThinkSystem SN850 7X15 (2.5")
Lenovo ThinkSystem SR250 7Y51, 7Y52 (2.5")
Lenovo ThinkSystem SR250 V2 7D7Q
Lenovo ThinkSystem SR530 7X07 (2.5"), 7X08
Lenovo ThinkSystem SR550 7X03 (2.5"), 7X04 (2.5")
Lenovo ThinkSystem SR570 7Y02 (2.5"), 7Y03 (2.5")
Lenovo ThinkSystem SR590 7X98 (2.5"), 7X99
Lenovo ThinkSystem SR630 7X01 (2.5"), 7X02
Lenovo ThinkSystem SR630 V2 7Z71
Lenovo ThinkSystem SR635 7Y98 (2.5"), 7Y99 (2.5")
Lenovo ThinkSystem SR645 7D2X, 7D2Y (2.5")
Lenovo ThinkSystem SR650 7X05 (2.5"), 7X06
Lenovo ThinkSystem SR650 V2 7D15 (2.5"), 7Z73
Lenovo ThinkSystem SR655 7Y00 (2.5"), 7Z01 (2.5")
Lenovo ThinkSystem SR665 7D2V, 7D2W (2.5")
Lenovo ThinkSystem SR850 7X18 (2.5"), 7X19 (2.5")
Lenovo ThinkSystem SR850 V2 7D31 (2.5"), 7D32 (2.5")
Lenovo ThinkSystem SR850P 7D2F (2.5")
Lenovo ThinkSystem SR860 7X69 (2.5"), 7X70 (2.5")
Lenovo ThinkSystem SR860 V2 7Z59 (2.5"), 7Z60 (2.5")
Lenovo ThinkSystem SR950 7X11 (2.5"), 7X12 (2.5")
Lenovo ThinkSystem ST250 7Y45 (2.5"), 7Y46 (2.5")
Lenovo ThinkSystem ST250 V2 7D8F
Lenovo ThinkSystem ST550 7X09 (2.5"), 7X10
Lenovo ThinkSystem ST650 V2 7Z74 |
