| Marketing Description |
| Lenovo ThinkSystem SR530 is an ideal rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as cost-optimized performance and flexibility for future growth. Designed to handle a wide range of workloads, such as IT infrastructure, collaboration, and entry cloud, it can be the foundation of your online business. ThinkSystem SR530 offers numerous features to increase performance and flexibility. SR530 offers a balance of performance, capacity and value. |
| Product Features |
-
Essential and priced within reach
Lenovo ThinkSystem SR530 is an ideal rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as cost-optimized performance and flexibility for future growth. Designed to handle a wide range of workloads, such as IT infrastructure, collaboration, and entry cloud, it can be the foundation of your online business.
-
Flexible to grow with your business
ThinkSystem SR530 offers numerous features to increase performance and flexibility. SR530 offers a balance of performance, capacity and value.
|
| General |
| Type |
Server |
| Product Form Factor |
Rack-mountable - 1U |
| Embedded Security |
Trusted Platform Module (TPM 1.2 and TPM 2.0) |
| Server Scalability |
2-way |
| Hot-Swap Bays Qty |
8 |
| Localisation |
Region: EMEA |
| Processor / Chipset |
| CPU |
Intel Xeon Silver 4208 |
| Clock Speed |
2.1 GHz |
| Max Turbo Speed |
3.2 GHz |
| Number of Cores |
8-core |
| CPU Qty |
1 |
| Max CPU Qty |
2 |
| Processor Main Features |
Hyper-Threading Technology, Intel Virtualization Technology, Intel Turbo Boost Technology 2 |
| Chipset Type |
Intel C622 |
| Cache Memory |
| Installed Size |
11 MB |
| Cache Per Processor |
11 MB |
| RAM |
| Installed Size |
16 GB (installed) / 768 GB (max) |
| Technology |
DDR4 SDRAM - ECC |
| Effective Memory Speed |
2400 MHz |
| Rated Memory Speed |
2933 MHz |
| Form Factor |
DIMM 288-pin |
| Slots |
12 (Total) / 11 (empty) |
| Features |
Registered, Memory Mirroring, Memory Sparing, mixing of different types of memory modules is not supported, Patrol Scrubbing, Demand Scrubbing |
| Configuration Features |
1 x 16 GB |
| Hard Drive |
| Type |
No HDD |
| Storage Controller |
| Type |
1 x RAID - PCIe 3.0 x8 |
| Controller Interface Type |
SATA 6Gb/s / SAS 12Gb/s |
| Storage Controller Name |
ThinkSystem RAID 530-8i |
| Channel Qty |
8 |
| RAID Level |
RAID 0, RAID 1, RAID 5, RAID 10, RAID 50, JBOD |
| Optical Storage |
| Type |
No optical drive |
| Monitor |
| Monitor Type |
None. |
| Graphics Controller |
| Graphics Processor |
Matrox G200 |
| Video Memory |
16 MB |
| Video Interfaces |
VGA |
| Networking |
| Ethernet Ports |
2 x Gigabit Ethernet |
| Data Link Protocol |
Gigabit Ethernet |
| Remote Management Controller |
XClarity Controller (XCC) Advanced |
| Expansion / Connectivity |
| Bays |
8 (total) / 8 (free) x hot-swap 2.5" |
| Slots |
1 (total) / 1 (free) x LAN-on-Motherboard (LOM)
1 (total) / 1 (free) x PCIe 3.0 x16 - low-profile
1 (total) / 0 (free) x PCIe 3.0 x8 - low-profile |
| Interfaces |
3 x USB 3.0 (1 front, 2 rear)
1 x USB 2.0 (1 in front)
1 x VGA
1 x management - RJ-45
2 x LAN (Gigabit Ethernet) - RJ-45 |
| Miscellaneous |
| Included Accessories |
Tool-less rail kit, C13-C14 rack power cable (2.8 m) |
| Compliant Standards |
TUV GS, BSMI, CISPR 22 Class A, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, CCC, RoHS, UL 60950-1, IEC 60950-1, FCC Part 15 A, GB 17625.1, GB 9254 Class A, VCCI Class A, KN24, EAC, KN22 Class A, NMB-3 Class A, GB 4943.1, BIS, EK1-ITB2000, EN 55022 Class A, CNS 13438 Class A, CNS 14336-1, IEC/EN 60950-1, TR CU 020/2011, TR CU 004/2011, CAN/CSA-C22.2 No. 60950-1 |
| Power |
| Device Type |
Power supply - hot-plug |
| Power Redundancy |
Optional |
| Power Redundancy Scheme |
1+1 (with optional power supply) |
| Installed Qty |
1 |
| Max Supported Qty |
2 |
| Voltage Required |
AC 120/230 V (50/60 Hz) |
| Power Provided |
750 Watt |
| 80 PLUS Certification |
80 PLUS Platinum |
| Operating System / Software |
| OS Provided |
No operating system |
| Sustainability Information |
| ENERGY STAR Certified |
Yes |
| ENERGY STAR Version |
3.0 |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 3 years - on-site - response time: next business day |
| Dimensions & Weight |
| Width |
43.4 cm |
| Depth |
71.5 cm |
| Height |
4.3 cm |
| Weight |
10.2 kg |
