| Marketing Description |
| The ThinkSystem ST50 V2 offers enterprise-class reliability features such as error correcting code (ECC) memory, the onboard RAID controller, and enterprise-class hard drives and network adapters. The server has Intel Active Management Technology (AMT) built-in, along with support for industry-standard management tools. The ST50 V2 runs a wide range of server operating systems and is quiet enough and small enough to fit under or beside an office desk. |
| Product Features |
-
Robust security
Equipped with a Trusted Platform Module (TPM 2.0) security chip, the Lenovo ThinkSystem ST50 V2 ensures your data is protected from external threats, making it a reliable choice for sensitive information handling.
-
Powerful performance
Powered by an Intel Xeon processor and integrated Intel UHD Graphics P750, this server delivers exceptional performance and graphics capabilities, suitable for a variety of business applications.
-
Expandable design
With multiple expansion slots, including PCIe 4.0 x16 and room for additional RAM, the Lenovo ThinkSystem ST50 V2 is designed to grow with your business needs, offering a scalable solution for future upgrades.
-
Efficient networking
Featuring Intel Active Management Technology (AMT) 15, teaming support, and Wake on LAN (WoL), this server provides efficient management and connectivity options to maintain high levels of productivity.
-
Reliable under pressure
Designed to operate within a wide range of temperatures and humidity, the Lenovo ThinkSystem ST50 V2 ensures reliable performance in diverse operating environments, making it a versatile choice for any business.
|
| General |
| Type |
Server |
| Product Form Factor |
Tower - 5U |
| Embedded Security |
Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability |
1-way |
| Internal Bays Qty |
2 |
| Localisation |
Region: EMEA |
| Processor / Chipset |
| CPU |
Intel Xeon E-2324G |
| Clock Speed |
3.1 GHz |
| Max Turbo Speed |
4.6 GHz |
| Number of Cores |
Quad-Core |
| CPU Qty |
1 |
| Max CPU Qty |
1 |
| CPU Socket |
LGA1200 Socket |
| Chipset Type |
Intel C256 |
| Cache Memory |
| Installed Size |
8 MB |
| Cache Per Processor |
8 MB |
| RAM |
| Installed Size |
16 GB (installed) / 128 GB (max) |
| Technology |
DDR4 SDRAM - ECC |
| Effective Memory Speed |
3200 MHz |
| Rated Memory Speed |
3200 MHz |
| Form Factor |
DIMM 288-pin |
| Slots |
4 (Total) / 3 (empty) |
| Features |
Unbuffered |
| Configuration Features |
1 x 16 GB |
| Hard Drive |
| Type |
SSD |
| Capacity |
2 x 960 GB |
| Interface Type |
SATA 6Gb/s |
| Storage Controller |
| Type |
1 x SATA |
| Controller Interface Type |
SATA 6Gb/s |
| Channel Qty |
3 |
| Optical Storage |
| Type |
No optical drive |
| Monitor |
| Monitor Type |
None. |
| Graphics Controller |
| Graphics Processor |
Intel UHD Graphics P750 Shared Video Memory (UMA) |
| Video Interfaces |
DisplayPort |
| Networking |
| Ethernet Controller |
Intel I219-LM |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features |
Wake on LAN (WoL), Teaming support, Intel Active Management Technology (AMT) 15 |
| Compliant Standards |
DASH 1.1 |
| Expansion / Connectivity |
| Bays |
1 (total) / 1 (free) x external 5.25"
2 (total) / 0 (free) x internal 3.5" |
| Slots |
1 (total) / 1 (free) x PCIe 4.0 x16 - half-length, full-height
1 (total) / 1 (free) x PCIe 3.0 x1 - half-length, full-height
1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height (x4 mode) |
| Interfaces |
1 x USB-C 3.2 Gen 2 (1 in front)
2 x USB 3.2 Gen 2 (2 in front)
6 x USB 3.2 Gen 1 (2 front, 4 rear)
2 x DisplayPort
1 x LAN (Gigabit Ethernet)
1 x serial
1 x audio line-out
1 x VGA (on supplied cable) |
| Miscellaneous |
| Theft/Intrusion Protection |
Security lock slot (cable lock sold separately), padlock loop |
| Security Slot Type |
Kensington security slot |
| Compliant Standards |
TUV GS, BSMI, IEC 60950-1, GB 17625.1, VCCI Class A, GB 4943.1, INMETRO, NOM-019, EK1-ITB2000, UL 2819, AS/NZS CISPR 32 Class A, KN32 Class A, EN 62368-1, IEC 62368-1, EN 55032 Class A, CISPR 32 Class A, TP TC 004/2011, HJ 2507-2011, Energy-Related Products (ErP) Lot 9, TP EAC 037/2016, ANSI/UL 62368-1, ICES-003 issue 7 Class A, GB/T9254, CQC3135, CSA C22.2 No. 62368-1, CMIM |
| Power |
| Device Type |
Power supply |
| Voltage Required |
AC 100-240 V (50/60 Hz) |
| Power Provided |
500 Watt |
| 80 PLUS Certification |
80 PLUS Platinum |
| Efficiency |
92% |
| Operating System / Software |
| OS Provided |
No operating system |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 3 years - on-site - response time: next business day |
| Dimensions & Weight |
| Width |
17 cm |
| Depth |
31.6 cm |
| Height |
37.6 cm |
| Weight |
9.4 kg |
| Dimensions & Weight (Shipping) |
| Shipping Width |
28 cm |
| Shipping Depth |
42 cm |
| Shipping Height |
54 cm |
| Environmental Parameters |
| Min Operating Temperature |
10 °C |
| Max Operating Temperature |
35 °C |
| Humidity Range Operating |
8 - 80% |
