| Marketing Description |
| Upgrade to blazing-fast 5.4Gbps of Wi-Fi 6 on up to 75 devices simultaneously across more space: 7 rooms or up to 7,500 sq. ft. Protected by award-winning NETGEAR security services, the RBK763S includes a dedicated connection for instant router-satellite communication and 7 Gigabit ports to give your most demanding tech products their own wired connection. |
| Product Features |
-
Engineered for blazing fast Wi-Fi
Orbi is engineered for more efficient data transmission through the exclusive Tri-Band technology. The result is faster Wi-Fi performance that doesn't degrade across the house.
-
Unstoppable streaming
Orbi keeps everyone in your house streaming Netflix shows, video calls, and gaming, all at the same time with no buffering or drop offs.
-
The best coverage, period
Orbi's unique shape and height encase ultra-premium, high-power components to deliver significantly better coverage and overall performance than the competition.
-
Your peace of mind is the priority
Create an automatic protective bubble around all your devices. Keep sensitive information from being stolen and ensure all your Internet activity remains private.
-
Connected kids are protected too
Easily manage kids' time and accessibility online across all connected devices. Promote healthy Internet habits, foster responsibility and build trust with your kids.
|
| General |
| Device Type |
Wi-Fi system - mesh - 3-port switch (integrated) |
| Wi-Fi System Components |
Router, 2 extenders |
| Wi-Fi System Coverage |
Up to 7,500 sq.ft |
| Enclosure Type |
Desktop |
| Connectivity Technology |
Wireless, wired |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6) |
| Frequency Band |
2.4 GHz (1 band) / 5 GHz (2 bands) |
| Data Transfer Rate |
5.4 Gbps |
| Performance |
Maximum data rate (2.4 GHz): 600 Mbps
Maximum data rate (5 GHz fronthaul): 2400 Mbps
Maximum data rate (5 GHz backhaul): 2400 Mbps |
| Capacity |
Concurrent devices: up to 75 |
| Network / Transport Protocol |
TCP/IP, PPTP, PPPoE, DHCP, SMB, DDNS, Bigpond |
| Routing Protocol |
RIP-1, RIP-2 |
| Encryption Algorithm |
TKIP, WPA-PSK, 128-bit AES, WPA2-PSK, WPA3-Personal |
| Wi-Fi Rating |
AX5400 |
| Mesh Networking |
Yes |
| Features |
Sync button, MU-MIMO technology, Tri-Band, PSK, guest access, coloured LED status, Explicit Beamforming, Implicit Beamforming, 4K/8K UHD video streaming, NETGEAR Smart Parental Controls, dual core CPU |
| Compliant Standards |
IEEE 802.11i, UPnP, ICES-003 Class B, AS/NZS CISPR 32 Class B, EN 55032, FCC Part 15 Subpart B Class B, EN 55035 Class B |
| Processor |
1 GHz |
| RAM |
1 GB |
| Flash Memory |
4 GB |
| Line Properties |
| Line Coding Format |
1024 QAM |
| Internet of Things (IoT) |
| Internet of Things (IoT) Compatible |
Yes |
| Intelligent Assistant |
Google Assistant, Alexa |
| Expansion / Connectivity |
| Interfaces |
WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45
LAN: 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45
LAN: 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45 - on extender |
| Aerial |
| Aerial |
Internal |
| Antenna Qty |
6 |
| Power |
| Power Device |
External power adapter |
| Installed Qty |
3 |
| Voltage Required |
AC 230 V (50 Hz) |
| Miscellaneous |
| Cables Included |
1 x network cable - 2 m |
| Localisation |
Europe |
| Software / System Requirements |
| Software Included |
NETGEAR Armor (1-year subscription) |
| Dimensions & Weight |
| Width |
16.764 cm |
| Depth |
6.35 cm |
| Height |
21.082 cm |
| Weight |
725.75 g |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 1 year |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
0 - 90% (non-condensing) |
