| General |
| Device Type |
Switch - 24 ports - 2+/L3 Lite - smart |
| Enclosure Type |
Rack-mountable, desktop |
| Ports |
24 x 100/1000/2.5G (PoE++) + 4 x 10 Gigabit SFP+ (uplink) |
| Power Over Ethernet (PoE) |
PoE++ |
| PoE Budget |
720 W |
| Performance |
Fabric throughput: 200 Gbps
1 Gbps copper latency (64-byte packets): 5.32 µs
2.5 Gbps copper latency (64-byte packets): 8.03 µs
2.5 Gbps copper latency (1518-byte packets): 8.19 µs
2.5 Gbps copper latency (9216-byte packets): 8.22 µs
10 Gbps fibre latency (64-byte packets): 1.14 μs
10 Gbps fibre latency (1518-byte packets): 1.228 μs
10 Gbps fibre latency (9216-byte packets): 1.236 μs
1 Gbps copper latency (1518-byte packets): 5.67 µs
1 Gbps copper latency (9216-byte packets): 5.67 µs
Forwarding rate (64‑byte packets): 148.8 Mpps |
| Capacity |
ARP table (IPv4): 512
Packet buffer size: 2 MB
VLANs supported: 256
ACL entries (ingress): 100
IGMP groups: 512
Priority queues: 8
DHCP snooping entries: 256
Multicast groups: 512
IPv4 routes (static): 32
IPv6 routes (static): 32
VLAN routing interfaces: 15 |
| MAC Address Table Size |
32000 entries |
| Jumbo Frame Support |
10KB |
| Routing Protocol |
IGMP, IGMPv2, IGMPv3, MLD, MLDv2, STP |
| Remote Management Protocol |
HTTP, HTTPS, SNMP 1, SNMP 2c, SNMP 3, IPv6, IPv4, RADIUS, RMON 1, RMON 2, RMON 3, RMON 9, TACACS+, Syslog |
| Encryption Algorithm |
TLS 1.2 |
| Authentication Method |
RADIUS, TACACS+, Extensible Authentication Protocol (EAP) |
| Features |
Uninterrupted PoE, GVRP, MLD snooping, static route, EEE, DoS attack prevention, 3 fans, PoE scheduling, IGMP snooping, IGMP querier, Voice VLAN, VoIP support, LLDP-MED, LACP, cloud managed, Link Aggregation, ZTP, ACL support, 802.1x authentication, QoS, DSCP based QoS, protected ports, DHCP snooping, PoE timer, dual firmware images, firmware upgradable, port mirroring, loop prevention, dual core CPU, PoE self-healing, advanced per-port PoE scheduling/timers, VLAN Tagging, MAC based VLAN, Protocol-based VLANs support, Auto VoIP, auto voice VLAN, auto video VLAN, auto camera VLAN, auto Wi-Fi VLAN, GARP, Private VLAN, MVR, DHCP client, ICMP Router Discovery Protocol (IRDP), DHCP server, DHCP relay, DHCP IPv6 server, DHCP IPv6 relay, Guest VLAN, MAC lockdown, DAI, port-based QoS, CoS, DiffServ support, ToS, WRR, SPQ, DNS client, loop detection, Radius Centralized Password Management, cable test |
| Compliant Standards |
IEEE 802.3bt, IEEE 802.3az, IEEE 802.1x, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1ab (LLDP) |
| Processor |
: 1 GHz |
| RAM |
1 GB |
| Flash Memory |
64 MB |
| Status Indicators |
Power, fan, PoE max, link/activity/speed |
| Expansion / Connectivity |
| Interfaces |
24 x 100/1000/2.5G RJ-45 PoE++ - 60 W
4 x 10GBase-X SFP+ |
| Power |
| Power Device |
Internal power supply |
| Installed Qty |
1 |
| Miscellaneous |
| Included Accessories |
Power cable (EU), rubber feet |
| Rack Mounting Kit |
Included |
| MTBF |
1,017,939 hours |
| Localisation |
Europe |
| Software / System Requirements |
| Software Included |
NETGEAR Insight (1 year subscription) |
| Dimensions & Weight |
| Width |
44 cm |
| Depth |
31 cm |
| Height |
4.32 cm |
| Weight |
4.435 kg |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - replacement - 5 years - response time: next business day |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
50 °C |
| Humidity Range Operating |
0 - 95% RH (non-condensing) |
| Min Storage Temperature |
-20 °C |
| Max Storage Temperature |
70 °C |
| Humidity Range Storage |
0 - 95% RH (non-condensing) |
