| Marketing Description |
| Get powerful and reliable Wi-Fi 6 connectivity for all your devices, even in high-density environments. Simplified enterprise-grade security and networking for the smaller business. |
| Product Features |
-
High-performance business Wi-Fi
Faster and more reliable dual band Wi-Fi 6 with 8 streams and up to 4.8 Gbps in 5 GHz band and 0.6 Gbps in 2.4 GHz band.
-
Ideal for high density environments
Ultimate Wi-Fi performance for schools, hotels, restaurants, and conference centers.
-
Greater network capacity
Enjoy 4x more connection capacity than your current Wi-Fi and improved efficiency for longer battery life.
-
Multi-Gigabit speed
Includes a 2.5 Gbps Ethernet port with PoE for high speed wired network connectivity and easy wiring.
-
Easy setup
Set up, configure, and manage with NETGEAR insight.
-
Flexible mounting
Easy to securely install on the wall of a suspended ceiling with the hardware included.
-
Business-level security
WPA3 for the highest level of Wi-Fi connection security.
-
8 wireless networks (SSIDs)
Separate and secure networks for admin, guests, employees and IoT devices like cameras, locks and more.
-
Separate VLANs
Keep admin, employee, visitor, HR, Finance department networks safely separated from each other.
|
| General |
| Device Type |
Radio access point |
| Ruggedized Design |
Indoor |
| Width |
24.115 cm |
| Depth |
23.96 cm |
| Height |
5.138 cm |
| Weight |
819 g |
| Localisation |
Europe |
| Networking |
| Form Factor |
Wall / ceiling mountable |
| Connectivity Technology |
Wireless |
| Data Transfer Rate |
5.4 Gbps |
| Line Coding Format |
OFDM, OFDMA |
| Data Link Protocol |
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6) |
| Spread Spectrum Method |
OFDM, OFDMA |
| Frequency Band |
2.4 GHz, 5 GHz |
| Performance |
Maximum throughput (5 GHz): 4800 Mbps
Maximum throughput (2.4 GHz): 600 Mbps |
| Capacity |
Maximum number of users: 328
SSIDs total: 8 |
| Wi-Fi Rating |
AX5400 |
| Status Indicators |
Power, LAN, 5 GHz, 2.4 GHz |
| Features |
VLAN support, auto-uplink (auto MDI/MDI-X), MAC address filtering, Wireless Distribution System (WDS) support, Mesh networking, Wi-Fi Multimedia (WMM) support, bandwidth control, LLDP support, Captive Portal, Transmit Power Control (TPC), band steering, WDS bridge, dual band, MAC address authentication, Backhaul Technology, Advanced Beamforming+, 4x4 MU-MIMO technology, WDS PTMP (Point to Multipoint), WDS PTP (Point to Point), WDS repeater mode, Target Wait Time (TWT), BSS Coloring, Guest Network, Neighbor AP detection, Block SSID Broadcast |
| Encryption Algorithm |
SSL, TLS, PEAP, TTLS, WPA, WPA2, WPA2-Enterprise, WPA3 |
| Authentication Method |
RADIUS, Extensible Authentication Protocol (EAP) |
| Compliant Standards |
IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6 |
| Aerial |
| Antenna |
Internal |
| Internet of Things (IoT) |
| Internet of Things (IoT) Compatible |
Yes |
| Expansion / Connectivity |
| Interfaces |
1 x 1/2.5GBase-T (PoE+) - RJ-45
1 x 1000Base-T - RJ-45 |
| Miscellaneous |
| Included Accessories |
Wall/ceiling mounting kit |
| Power |
| Power Over Ethernet (PoE) Supported |
PoE+ |
| Power Consumption Operational |
21.2 Watt |
| Software / System Requirements |
| Software Included |
NETGEAR Insight (1 year subscription) |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - replacement - 5 years - response time: next business day
Technical support - 90 days |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
