| Marketing Description |
| Inform and enthrall with a Philips Q-Line Professional Ultra HD Display. This reliable solution can be up and running as quickly as you need. |
| Product Features |
-
CMND & Control
Run your display network over a local (LAN) connection. CMND & Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.
-
Integrated media player
Easily schedule content to play from USB. Your Philips Professional Display will wake from standby to play the content you want, and then return to standby once playback is done.
-
FailOver
From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs ensuring content keeps playing even if the primary source goes down. Simply set a list of alternate inputs to be sure your business is always on.
-
OPS slot
Integrate a full-power PC or Android-powered CRD50 module directly into your Philips Professional Display. The OPS slot contains all the connections you need to run your slot-in solution, including a power supply.
-
CMND & Create
Take control of your content with CMND & Create. A drag-and-drop interface makes it simple to publish your own content-whether it's a daily specials board or branded corporate information. Preloaded templates and integrated widgets ensure your stills, text, and video will be up and running in no time.
-
Powered by Android 8
Control your display via an Internet connection. Android-powered Philips Professional Displays are optimized for native Android apps, and you can install web apps directly to the display too. A new Android 8 ensures the software is kept secure and remain to the latest specification for longer.
-
SmartBrowser
Connect and control your content over the internet with the integrated HTML5 browser. Using the Chromium based browser, design your content online and connect a single display, or your complete network. Show content in both landscape and portrait mode, with fullHD resolution. Streaming content can also be shown in a PIP (picture-in-picture) window. Simply connect the display to the internet using Wi-Fi or with an RJ45 cable, and enjoy your own created playlist.
|
| General |
| Product Type |
LED-backlit LCD flat panel display |
| Energy Class |
Class G |
| Power Consumption Operational |
310 Watt |
| Power Consumption SDR (On mode) |
193 kWh/1000h |
| Diagonal Class |
75" |
| Diagonal Size |
74.5" |
| Commercial Use |
Yes - digital signage |
| Series |
Q-Line |
| Platform |
Android |
| Operating System |
Android OS 8.0 |
| TV Tuner |
No tuner |
| TV Tuner Presence |
No |
| Video Interface |
HDMI |
| HDMI Ports Qty |
3 ports |
| PC Interface |
DVI, VGA (HD-15) |
| Modes |
Landscape mode |
| Picture Enhancements |
3D Combfilter |
| Dimensions |
Without stand |
| Width |
168.35 cm |
| Depth |
6.628 cm |
| Height |
96.17 cm |
| Weight |
37.5 kg |
| Display |
| LCD Display Technology |
ADS |
| Resolution |
3840 x 2160 |
| Display Format |
4K UHD (2160p) |
| Image Aspect Ratio |
16:9 |
| LCD Backlight Technology |
Direct-lit LED |
| Image Contrast Ratio |
1200:1 |
| Dynamic Contrast Ratio |
500000:1 |
| Brightness |
400 cd/m² |
| Viewing Angle |
178 degrees |
| Viewing Angle (Vertical) |
178 degrees |
| Pull-Down Compensation |
3:2, 2:2 |
| Response Time |
8 ms |
| Display Menu Language |
Chinese (traditional), Chinese (simplified), English, German, French, Italian, Polish, Russian, Spanish, Turkish, Arabic, Japanese |
| Commercial Features |
HTML5 support, FailOver |
| Operation Hours / Days |
18 / 7 |
| Features |
3D MA deinterlacing, DICOM support, picture in picture (no tuner) |
| Video Wall |
| Max Number of Screens |
225 |
| Stands & Mounts |
| Flat Panel Mount Interface |
600 x 400 mm |
| VESA Compatibility |
Yes |
| Video Features |
| Input Video Formats |
1080/60i, 480/60p, 720/60p, 1080/50i, 720/50p, 576/50p, 1080/50p, 1080/60p, 480/60i, 576/50i |
| Supported Computer Resolutions |
1024 x 768 (XGA), 640 x 480 (VGA), 800 x 600 (SVGA), 832 x 624, 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1152 x 864, 1280 x 720, 720 x 400, 1152 x 870, 1680 x 1050 (WSXGA+), 1920 x 1080, 1440 x 900, 1280 x 800 |
| Media Player |
| Supported Video Formats |
H.264, H.263, MPEG, H.265, VP8 |
| Supported Audio Formats |
AAC, HE-AAC |
| Supported Pictures Formats |
BMP, PNG, JPEG |
| USB Port |
Yes |
| Configuration |
ARM Cortex-A73 Dual-Core + ARM Cortex-A53 Dual-Core - 2 GB - 8 GB |
| Remote Control |
| Type |
Remote control |
| Audio System |
| Speaker System |
2 speakers |
| Output Power / Total |
20 Watt |
| Speakers |
2 x speaker - 10 Watt |
| Network & Internet Multimedia |
| Functionality |
WEB browsing |
| Connectivity |
LAN |
| Connections |
| Connector Type |
3 x HDMI input
DVI-D input
USB 2.0
VGA input
Audio line-in
Audio line-out
Remote control
RS-232C input
RS-232C output
Infrared input
Infrared output |
| Miscellaneous |
| Included Accessories |
Batteries |
| Cables Included |
RS-232 cable
HDMI cable
IR sensor cable |
| Compliant Standards |
FCC Class A certified, VCCI, BSMI, CB, PSB, ETL, DICOM Part 14, EPA, CU |
| Power |
| Power Device |
Power supply |
| Input Voltage |
AC 120/230 V |
| Power Consumption Stand by |
0.5 Watt |
| Features |
Smart power |
| Manufacturer Warranty |
| Service & Support |
Limited warranty - 3 years |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
20 - 80% |
